Toshiba IK-HR1CD Instruction Manual

Camera control unit.
Hide thumbs

Advertisement

CAMERA CONTROL UNIT
IK-HR1CD
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class A digital device, pursu-
ant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
USER-INSTALLER CAUTION: Your authority to operate this FCC verified equipment could be voided if
you make changes or modifications not expressly approved by the party responsible for compliance to
Part 15 of the FCC Rules.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est comforme à la norme NMB-003 du Canada.
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as household waste.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about the take-
back and recycling of this product, please contact your supplier where you purchased the
product or consult.
This manual is made from recycled paper.
INSTRUCTION MANUAL
For Customer Use
Enter below the Serial #
w h i c h i s l o c a t e d o n t h e
bottom of the cabinet. Retain
this information for future ref-
erence.
Model #
IK-HR1CD
Serial #

Advertisement

   Related Manuals for Toshiba IK-HR1CD

   Summary of Contents for Toshiba IK-HR1CD

  • Page 1

    CAMERA CONTROL UNIT INSTRUCTION MANUAL IK-HR1CD For Customer Use Enter below the Serial # w h i c h i s l o c a t e d o n t h e bottom of the cabinet. Retain this information for future ref- erence.

  • Page 2

    SAFETY PRECAUTIONS Safety icons This manual contains safety instructions that must be observed in order to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and the icons highlight these instructions as follows: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 3: Copyright And Right Of Portrait

    5. Repairs or modifications made by the user or caused to be made by the user and carried out by an unauthorized third party. 6. Notwithstanding the foregoing, Toshiba’s liabilities shall not, in any circumstances, exceed the purchase price of the product.

  • Page 4: Table Of Contents

    Accordingly, [Toshiba/TAIS] disclaims any and all liability arising out of the use of the product in any critical applications.

  • Page 5

    (6) OPTION........................(6.1) Changing a type of output monitors ..............(6.2) Changing RS 232C baud rate ................24 (7) Returning to factory settings ..................24 8 BEFORE MAKING SERVICE CALL............9 SPECIFICATIONS .................. 10 EXTERNAL APPEARANCE DIAGRAM..........

  • Page 6: Cautions On Use And Installation

    Followings are the descriptions about the camera head and this camera. • • Handling the unit. Do not shoot intense light. When intense light enters, vertical stripes or Do not drop, jolt, or vibrate, as this may result in damage to the unit. This may cause problems. transverse band may appear on the screen.

  • Page 7: Names And Functions

    1080 59.94 P 720 50...

  • Page 8: Connection

    1080 59.94 P 720 50...

  • Page 11: Gain

    5 2 Gain When the image is dark even if the lens iris is open, change the gain (video gain) to get the desired video level. For gain adjustment of the unit, MANUAL (Manual), OFF (0 dB) modes are provided. Select the mode on the GAIN menu.

  • Page 12: Switching Video Signal Output

    certain characteristics of the CMOS sensor becoming more visible. 5 3 Switching video signal output A FORMAT switch on the front of the camera can switch the video signal output. Settings Video output Switch status Effective Vertical Scan mode scanning lines frequency 1920×1080/59.94Hz (Progressive) 1080...

  • Page 13: Mode Setting By The On Screen Display

    7 MODE SETTING BY THE ON SCREEN DISPLAY Various settings can be controlled on the unit by using the on screen menu displayed on the monitor. The contents once set are memorized in the scene files (A, B, C, D, E) selected, so if the power turns off, it is unnecessary to set the values again when using the unit next time.

  • Page 14: Menus

    7 3 Menus Select the menu to change the setting by referring to the item “7.1 Using the Menus”. When the [MENU UP], [MENU DOWN] buttons are pressed, the “ ” on the screen moves up and down. Move the “ ” to the item whose setting you wish to change. SHUTTER Electronic shutter The electronic shutter has three modes;...

  • Page 15: (1.1) Changing The Setting In Auto Mode

    1 1 Changing the setting in AUTO mode Move up and down Select the desired by pressing value by pressing MENU UP,DOWN DATA UP,DOWN Shutter mode AUTO, MANUAL, SS Video level adjustment -100 to 100 -- 1 SHUTTER -- (FILE A) Peak and average ratio adjustment 00 10 to 10 00 MODE AUTO...

  • Page 16: (1.2) Changing The Setting In Manual Mode

    (d) Changing the automatic shutter zone area Move the “ ” to AREA by pressing [MENU UP], [MENU DOWN] buttons. Select the measurement light area by pressing [DATA UP], [DATA DOWN] buttons. DATA UP PRESET A PRESET B PRESET C PRESET D PRESET E DATA DOWN...

  • Page 17: (1.3) Changing The Setting In Ss (synchro Scan) Mode

    DATA UP 1/100s 1/125s 1/250s 1/500s 1/1000s 1/2000s 1/4000s DATA DOWN Note: The shutter speed can be set in every effective scanning line (1080/720). The figures of shutter speed in the menu screen are approximate. The accurate shutter speed is calculated using the following mathematical formula.

  • Page 18: Gain (video Gain)

    2 GAIN (Video gain) GAIN has two modes; MANUAL, OFF. Move the “ ” to MODE, press the [DATA UP], [DATA DOWN], and select one of the two modes : MANUAL, OFF. In the OFF mode, gain is fixed to 0dB. 2 1 Changing gain in MANUAL mode Move up and down Select the desired...

  • Page 19: Wht Bal(white Balance)

    18dB DATA DOWN 3 WHT BAL(White Balance) The WHT BAL has three modes; AWB, ATW, MANUAL. Move the “ ” to MODE, press the [DATA UP], [DATA DOWN], and select one of the three modes : AWB, ATW, MANUAL. 3 1 Changing the setting in AWB(Automatic White Balance) mode Move up and down Select the desired by pressing...

  • Page 20: (3.2) Changing The Setting In Atw (automatic Tracking White Balance) Mode

    Move the “ ” to AREA DISP by pressing [MENU UP], [MENU DOWN] buttons. Select the desired area by pressing [DATA UP], [DATA DOWN] buttons. The available picture area is shown by the shading correction on the screen that is divided into 64. PRESET A PRESET B PRESET C...

  • Page 21: (3.3) Changing Gain In Manual Mode

    3 3 Changing gain in MANUAL mode Move up and down Select the desired by pressing value by pressing MENU UP,DOWN DATA UP,DOWN White balance mode AWB, ATW, MANUAL Red gain adjustment -100 to 100 -- 3 WHT BAL -- (FILE A) Blue gain adjustment -100 to 100 MODE MANUAL...

  • Page 22: Process

    4 PROCESS Move up and down Select the desired by pressing value by pressing MENU UP,DOWN DATA UP,DOWN Gamma correction ON, OFF Gamma correction level setting -10 to 10 -- 4 PROCESS -- (FILE A) Detail gain setting -7 to 7 GAMMA ON/OFF GAMMA Detail boost frequency...

  • Page 23: (4.4) Changing Dtl B. Freq (detail Boost Frequency)

    The detail decreases. [ DATA DOWN ] 4 4 Changing DTL B.FREQ (detail boost frequency) This is an item to set the thickness of the image outline. Move the “ ” to DTL B.FREQ by pressing [MENU UP], [MENU DOWN] buttons. Select the detail boost frequency by pressing [DATA UP], [DATA DOWN] buttons.

  • Page 24: (6.1) Changing A Type Of Output Monitors

    6 OPTION Move up and down Select the desired by pressing value by pressing MENU UP,DOWN DATA UP,DOWN -- 6 OPTION (FILE A) MONITOR PC, TV MONITOR RS232C baud rate 9600bps, 19200bps BAUD RATE 9600bps 6 1 Changing a type of output monitors Move the “...

  • Page 25: Before Making Service Call

    8. BEFORE MAKING SERVICE CALL Symptom Items to be checked “NO CAMERA HEAD Are the camera cable and the camera head connected correctly? DETECTED” displayed Isn’t the camera cable broken? Is power supplied correctly? No picture Is the lens iris adjusted correctly? Are the camera and video cables connected correctly? Is the shutter mode set correctly? Does the video output from the camera match with the input signals from the monitor?

  • Page 26: Specifications

    9. SPECIFICATIONS *Below are specifications when this camera control unit is combined with Toshiba full HD color camera head IK-HR1H. Image sensor 1/3 inch color CMOS sensor (Rolling shutter) Output pixels Horizontal : 1920, Vertical : 1080 (max.) Signal system 1080/59.94p 1080/50p 1080/59.94i 1080/50i 720/59.94p 720/50p...

  • Page 27: External Appearance Diagram

    10. EXTERNAL APPEARANCE DIAGRAM Unit : mm [inch] [0.31] 77.4 [3.05] 44 [1.73] 32.51[1.28] #4-40UNC 56 [2.2] 4-M2 Depth 3 [0.118] 4.5 [0.18] 4-M3 Depth 3 [0.118] 24.5 [0.96] 25 [0.98]...

  • Page 28

    Limited Warranty – TOSHIBA Camera Control Unit The Imaging Systems Division of Toshiba America Information Systems, Inc. ("ISD") makes the following limited warranties with regard to this Camera Control Unit ("Product"). These limited warranties extend to the Original End-User ("You[r]").
