1. COMPONENTS

(1) Camera control unit .................................................................................. 1
(2) Accessories
(a) Instruction manual ............................................................................. 1

2. SPECIFICATIONS

Specification with camera head (IK-M51H) connected.
Power supply
Power consumption
Image sensor
Effective pixels
Effektiver image area
Scanning system
Scan frequency
Sync system
Resolution
Standard intensity of
illumination for objects
Minimum intensity of
illumination for objects
S/N ratio
Video output
Output impedance
Input
External
Adjustment
Sync
function
White balance
Gain switch (AGC)
Electronic shutter
Operating temperature/
humidity
Anti-vibration/
shock characteristics
Weight
Dimensions
(Without protrusion)
Design and specifications are subject to change without notice.
DC12V ± 0,5V
360 mA
1/2 inch IT-CCD
Horizontal: 752 Pixels, Vertical: 582 Pixels
Horizontal: 6.47 mm, Vertical: 4.83 mm (1/2 inch type)
2:1 interlace
Horizontal: 15.625 kHz, Vertical: 50 Hz
Internal/External (automatic switching)
Horizontal: More than 470 lines, Vertical: More than 420 lines
30 lx (F1.6, 3000K)
2.5 lx (F1.6, 3000K)
46 dB or more
VBS 1.0 V (p-p), (BNC terminal) PAL system
Y/C separation output (S terminal)
75 unbalanced
VBS 1.0 V (p-p), (BNC terminal) PAL 75
Subcarrier phase, H phase
Automatic/set/manual
SENS UP (+6 dB)/ON/OFF
Automatic, 1/50s, 1/100s, 1/250s, 1/500s, 1/1000s, 1/2000s,
1/4000s, 1/10000s, synchronized scan
14°F to 104°F (-10° C to + 40° C)/Less than 90 %
2
70 m/s (10 to 200 Hz) / 700 m/s
Control unit: 0.86lbs (390g)
Control unit: W: 3.35", H: 1.57", D: 6.14"
(B: 85 mm, H: 40 mm, T: 156 mm)
