- Page 1 Upper Arm Blood Pressure Monitor with wireless data transfer module User Manual Please read the user manual carefully before the first use. HMM Diagnostics GmbH D-69221 Dossenheim, Germany www.hmm.info...
-
Page 3: Table Of Contents
Inhalt I. Introduction Product description Normal variations of your blood pressure II. Your smartLAB®profi+ Display & functions Specifications Information: III. Setup & operating functions Making the device ready for operation Setting time, date and average Setting up the wireless data transfer Connecting the cuff to the monitor Applying the cuff Body posture during measurement... - Page 4 Guidance and manufacture’s declaration – electromagnetic immunity for ME EQUIPMENT DPA technology for a more accurate measurement Measure-during-inflation Warranty:...
-
Page 5: Introduction
® profi+ blood pressure monitor can also indicate the average of the measurements you did in the mornings/ evenings as well as the average for all results. * For more information on h or h Terminal go to www.hmm.info Line... -
Page 6: Normal Variations Of Your Blood Pressure
ANT+ wireless data transfer Thanks to the integrated ANT module all results can be transmitted to their receiver (laptop, personal computer, h ) in order to interpret your measured values. The smartLAB ® profi+ blood pressure monitor is an ANT+ Device, which supports the ANT+ protocoll (version 1.0) and is compatible with receive terminal s, which support the ANT+ protocoll. -
Page 7: Your Smartlab®Profi
II. Your smartLAB®profi+ Display & functions Measured data storage/ right arrow key Port for the blood pressure cuff Setting/ left arrow key On/off start Button to choose the user pro- External electricity supply file (A or B) (DC 6V) -
Page 8: Specifications
Time Day/month/ year Warning „wrong Systolic measurement because of movement of the arm“ Diastolic Memory mode User profile A / B Average Pulse values Data transfer Average in the morning, in the Low battery evening, total average Irregular heartbeat Specifications 10. - Page 9 Contents 1 smartLAB profi+ blood pressure monitor ® 1 comfort cuff (size: 22-42 cm) 1 User manual 1 smartLAB wallett ® 1 smartLAB blood pressure passport ® 4 „AAA“ batteries...
-
Page 10: Information
Information: 1. Please relax 5 minutes before measuring. 2. The arm cuff should be placed on top of the elbow (please refer to the indication on the cuff) 3. Do not move or speak when measuring. 4. Please always use the same arm. 5. -
Page 11: Setup & Operating Functions
III. Setup & operating functions Making the device ready for operation • Please open the cover of the battery case on the back side of the device. • Please insert the „AAA“ batteries according to the required polarity. • Then close the cover of the battery case. When the display shows the symbol for low batteries please change them... -
Page 12: Setting Time, Date And Average
The smartLAB profi+ blood pressure meter uses a special function ® to automatically set usersettings and function setup. A receiving device (z.B. HMM h ) that supports this function Fon® Fon® oder Collect is required. - Page 13 After that you can choose the month. The display shows the letter “M” (picture 2a). Use the arrow keys and confirm with the button „On/Off START“. pict. 2a Then you have to choose the right day (display shows „D“). Use the ar- row keys for your choice and confirm with the button „On/Off START“.
-
Page 14: Setting Up The Wireless Data Transfer
ANT+ ® module. It enables you to transmit your measured values to your personal computer, your laptop or your mobile phone (e.g. our HMM ). After that you can store, analyze and process your data with Fon* the correspondent software. - Page 15 The Advantage of ANT+ is that equipment with ANT+ technology can connect with other manufacturers receiving devices. smartLAB ® profi+ supports the ANT+ protocoll for blood pressure meters (Version 1.0). Please press „On/Off START” more than 5 seconds for the setting of your wireless transmission („ANT mode“).
- Page 16 data transfer was successful you can see the symbol (see pict. 3a). In case the value could not be transmitted the corresponding symbol appears on the display (see pict. 3b). pict. 3a pict. 3b Please proceed by pressing the button „On/Off START“. Data transfer of all measured values stored by the device (dc.A): You can start the data transfer by pressing the left or right arrow key.
- Page 17 When you start the transfer of all data the corresponding symbol in the display starts blinking. A successful data transfer is confirmed by the symbol you can see in picture 3d. In case the data transfer was not successful you will see the symbol of picture 3e. pict.
- Page 18 Automatic data transfer of all values stored by the device (dAU): Please make your choice: Do you want all unsent values stored on the device to be automatically transferred to the partner device, turn the option either ON or OFF with the arrow keys. If the mode is turned ON, the correspondent symbol appears with every data transfer (see pict.
-
Page 19: Connecting The Cuff To The Monitor
Abb. 3h Abb. 3i Connecting the cuff to the monitor Insert the cuff tubing connector into the socket of your smartLAB profi+ on the left ® side of the monitor (see pict. 5). Make sure that the connector is completely inserted pict. -
Page 20: Body Posture During Measurement
Note: • Use the same arm for each time you measure. • Do not move your arm, body or the monitor and do not move t h e rubber tube during measurement • Stay quiet and calm for 5 minutes before blood pressure measurement •... -
Page 21: Measurement
Measurement • After having applied the cuff, seat yourself comfortably and press the “On/Off START” button. A signal tone appears and all display symbols will be shown (see pict. 7) pict. 7 pict. 7a • After that, the last stored result with the correspondent user “A” or “B”... -
Page 22: Displaying Stored Values
pict. 7b pict. 7c • smartLAB ® profi+ will automatically turn off after 1 minute. You can manually shut down the monitor by pressing “On/Off START” after the measurement. • You can interrupt the measurement by pressing “On/Off START”. The cuff will then release air and the monitor will turn off. Displaying stored values •... - Page 23 pict. 8 • Press “On/Off START” to display the average values (see pict. 8a, next page). The figure below “AVG” on the display shows, how many of the last measurements are taken to calculate the average value. (Please refer to the chapter “Setting time, date and average” in this manual, to change this figure.) pict.
-
Page 24: Deleting Measured Values
• By pressing “On/Off START” once more, you can display the average values of your measurements taken in the afternoon/ evening. This will be indicated by a little moon symbol on the display (see pict. 8 c) • By pressing “On/Off START” once more, the average value of all stored measurements will be displayed. - Page 25 • To delete all values from memory, now press the left arrow key. Afterwards, the display will show picture 9a and the monitor will power off. pict. 9a...
-
Page 26: Miscellaneous
IV. Miscellaneous Assessing high blood pressure for adults The following guidelines for assessing high blood pressure (without regard to age or gender) have been established by the World Health Organization (WHO). Please note that other factors (e.g. diabetes, obesity, smoking, etc.) need to be taken into consideration. Consult your physician for accurate assessment. - Page 27 Blood pressure fluctuates continually — day and night. The highest value usually appears in the daytime and the lowest one usually at midnight. Typically, the value begins to increase at around 3:00AM, and reaches to highest level in the daytime while most people are awake and active.
- Page 28 The blood pressure is influenced by a variety of different factors, such as bodily circumstances or a wrong operation of the monitor. Some people even get nervous when seeing a doctor and that will make their blood pressure rise. Single measurements can not indicate the whole blood level, so you need not to be anxious for isolated higher or lower blood pressure results.
- Page 29 Hypertension: Various cardiovascular or kidney diseases can cause hypertension. Long-term hypertension can also cause pathological changes in heart, brain and kidney. These changes can lead to hyperten- sion complications which are often diagnosed or treated too late. Low Blood Pressure: There are two kinds of minimum pressure: •...
- Page 30 BD Classifi- Color indi- Color chan- cation mmHg mmHg cator ging area Optimal < 120 < 80 GREEN GREEN Normal 120-129 80-84 GREEN GREEN High- 130-139 85-89 GREEN GREEN Stage 1 140-159 90-99 YELLOW YELLOW Hyperten- sion Stage 2 160-179 100-109 ORANGE Hyperten-...
-
Page 31: Troubleshooting
Troubleshooting Problem Cause Remedy LCD is dark / shows Battery too weak Insert new batteries „LO“ Display shows „E1“ Cuff too loose Reapply cuff and start the measurement again Display shows „E2“ Cuff too tight Loosen the cuff and repeat measurement Display shows „E3“... -
Page 32: Maintenance
Maintenance • Do not drop this monitor or subject it to strong impact. • Avoid high temperature and solarization. Do not immerse the monitor in water as this will cause damage to the monitor. • If this monitor is stored near freezing, allow it to acclimate to room temperature before use. -
Page 33: Guidance And Manufacture's Declaration - Electromagnetic Emission For All Equipment & Systems
Guidance and manufacture’s declaration – electromagnetic emission for all equipment & systems The smartLAB ® profi+ is intended for use in the electromagnetic en- vironment specified below. The customer of the user of the device should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment –... -
Page 34: Guidance And Manufacture's Declaration - Electromagnetic Immunity For All Equipment & Systems
Guidance and manufacture’s declaration – electromagnetic immunity for all equipment & systems The smartLAB ® profi+ is intended for use in the electromagnetic environment specified below. The customer of the user of the device should assure that it is used in such and environment. Immunity test IEC 60601 test level compliance level... - Page 35 Immunity test IEC 60601 test level compliance level Electromagnetic environment guidance Voltage dips, <5% U <5% U Mains power short interrup- (>95% dip in U (>95% dip in U quality should be tions and voltage for 0.5 cycle for 0.5 cycle that of a typical variations on po- commercial...
-
Page 36: Immunity For Me Equipment
Guidance and manufacture’s declaration – electromagnetic immunity for ME EQUIPMENT and ME SYSTEMS that are not LIFE-SUPPORTING I m m u n i t y 60601 compliance Electromagnetic environ- test test level level ment - guidance Portable and mobile RF commu- nications equipment should be used no closer to any part of the device, including cables, than... - Page 37 Note 1: At 80 MHz and 800 MHz, the higher frequency range applies. Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. Field strengths from fixed transmitters, such as base stations for radio (cellular/cord- less) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
-
Page 38: Dpa Technology For A More Accurate Measurement
Rated maximum output power of transmitter Separation distance according to frequency of trans- mitter 150 kHz - 80 80 MHz - 800 800 MHz - 2,5 d= 1,167 √P d= 1,167 √P d= 2,333 √P 0,01 0,167 0,167 0,233 0,369 0,369 0,738 1,167... -
Page 39: Measure-During-Inflation
Warranty: HMM Diagnostics GmbH products need to fulfill high quality require- ments. Because of this reason, HMM Diagnostics GmbH gives a 2-year war- ranty by purchasing this smartLAB product. You can even extend the ® warranty from 2 to 5 years without extra pay when you register your product. - Page 40 Manufacturer: HMM Diagnostics GmbH Friedrichstr. 89 D-69221 Dossenheim, Germany mail: info@hmm.info www.hmm.info Weitere Informationen zu den smartLAB Produkten / ® More information smartLAB products: ® www.smartlab.org...
