Locating and operating a product
More than one window
With more electrical products
Three windows are each equipped with a window
operator, a roller shutter, a blind and frame lights.
The example shows how to locate and operate
blind No. 3.
1
Press "Locate".
2
Displays the list of product types in House.
Press to highlight "Blind".
Press "Enter".
3
Press to highlight blind "No. 3".
Press "Enter".
4
Press to start operation.
12
1 2
House
No. 1
Window
Menu
------------- HOUSE -------------
Window
Roller shutter
Blind
Lights
Enter
P1
------------- BLIND -------------
No. 1
No. 2
No. 3
Enter
P1

Choosing positions and luminous intensity

A product or a Group of products can be set
to travel to a certain position. The example shows
how to set a roller shutter to run 50% down.
1
Locate the product in question, see section
Locating and operating a product.
3
2
Product chosen is displayed.
The example shows roller shutter No. 2.
3
Press and hold key
Each black spot corresponds to the roller shutter
running 10% down. Five black spots thus corres-
pond to it running 50% down.
Release key and the roller shutter will travel to
Locate
the position chosen.
Note: A short key pressure will make the roller
shutter travel to maximum top or bottom position.
Lights or a Group of lights can be operated on
the same principle. The percentages correspond
to luminous intensity. Short key pressure: The lights
Back
are switched on or off completely.
P2
A Venetian blind can be operated in two ways.
It can be drawn up and down, as described for
the roller shutter, and its slats can be tilted. To tilt
the slats of the Venetian blind, choose Tilt
the navigation keys
Back
located.
P2
To obtain ventilation via the ventilation flap with-
out opening the window, release key
"Ventilation" is displayed.
Menu
and watch the display.
with
when the product has been
when
House
No. 2
Roller shutter
Locate
P1 P2
Run to position
50% down
