Fitting of rain sensor
If the rain sensor has not already
been fi tted, fi t it as shown, see
instructions for rain sensor.
If the rain sensor gets wet, the win-
dow operator will automatically
close the window.
The mains supply must be
switched off when fi tting the

rain sensor!

Installation on top cover of
window (GGL/GGU)
Adhere the rain sensor to a dry,
clean surface. Lead cable into the
window as shown and connect it to
the connection box on the motor (A).
Installation on roller shutter (SML)
or awning blind (MML)
Adhere rain sensor to a dry, clean
surface. Lead cable under roller
shutter/awning blind so that the win-
dow can be opened when the roller
shutter/awning blind is rolled down.
Then lead the cable into the window
as shown and connect it to the con-
nection box on the motor (A).
54
GGL
GGU
SML
MML
A
Fitting of blinds, roller shutters etc
The window is prepared for fi tting of interior and
exterior decoration and sunscreening products as
well as frame lights. Product availability may dif-
fer in your country. For further information, please
refer to appropriate instructions or contact VELUX.
Products
SML/SMG
Electrically operated roller shutter
MML
Electrically operated awning blind
PML Electrically operated Venetian blind
RML Electrically operated roller blind
DML
Electrically operated blackout blind
FML
Electrically operated pleated blind
KRA
SML
SMG
MML KRA
PML
RML
DML
FML
SML
SMG
MML
PML
RML
DML
FML
KRA
Frame lights
