1.Mounting

1.1 Mounting cable sensor and magnet

Important: mount the sensor first, then mount the wired handlebar holder as described under 1.2
Check the following while mounting:
a. Distance between the sensor and magnet: 1 to 5 mm
b. When mounting the sensor on a suspension fork, don't forget to allow extra length for the cable.
step 1: Loosely attach the sensor on the fork leg with cable ties (do not tighten yet).
step 2: Mount the magnet on a spoke. Adjust the magnet to the marking on the sensor (distance 1-5 mm).
step 3: When adjustment has been done finalise mounting by tightening cable ties and clamping magnet.

1.2 Mounting wire and VDO "any-size" handlebar holder

step 1: Run the cable up the fork, pass it around the brake cable from the already fixed sensor to the handlebar.
Use the enclosed cable ties or duct tape. Spiral the wire around the brake cable (this has proven to be the best solution).
step 2: position the holder on the handlebar.
step 3: feed the fixing clamp through the slot below the holder socket, pass the clamp around the handlebar and tighten it with a small screw driver.
Do not overtighten, the plastic screw might be damaged. Readjust the cable so that it will not be stretched during steering.
Finally tighten the zip ties holding the sensor.
WATCH OUT: cable may tear
