Your Oven And Accessories - Sharp R-61FBSTM Operation Manual With Cookbook

R-61+62FBSTM Operation Manual

YOUR OVEN AND ACCESSORIES

9
8 7 6
15
14
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it
is not damaged.
• After cooking fatty foods without a cover, always clean the cavity and especially the grill heating
element thoroughly, these must be dry and free from grease. Built-up grease may overheat and begin
to smoke or catch fire.
• Always operate the oven with the turntable and roller stay fitted correctly. This promotes thorough,
even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage
to the oven.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you
start the oven. This does not affect cooking performance.
• When you order accessories, please quote both the PART NAME and MODEL NUMBER to
your dealer or SHARP approved service facility. The model number is located at the bottom of the
control panel.
WARNING:
The door, front trim, oven cavity, turntable, dishes, accessories and especially the grill
will become very hot during operation. To prevent burns, always use thick oven gloves.
24/07/2003
10 1
2
3
5 4
11
12
13
16
17
18
10:27 Page 2
OVEN:
1. Front trim
2. Oven lamp
3. Control panel
4. Waveguide cover (DO NOT REMOVE)
5. Seal packing
6. Oven cavity
7. Door seals and sealing surfaces
8. Door latches
9. Door opening handle
10. Grill heating element
11. Fixing ponts (4 points)
12. Ventilation openings
13. Outer cabinet
14. Power cord support clips
15. Power cord
ACCESSORIES:
Check to make sure the following accessories are
provided:
16. Turntable 17. Roller stay
18. Rack 19. 4 fixing screws (not shown)
• Place the roller stay in the seal packing on the
floor of the cavity, then place the turntable on
to the roller stay, ensuring it is located firmly.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
• For use of the rack, refer to the grilling and
dual grilling sections on pages 12 to 13.
Never touch the grill when it is hot.
2
