2 Operation

2.3 Switching on the display

CNS O
DECO STOP
LEVELSTOP
NO STOP
%
%
NO
CNS O %
2
%

2.4 Checking the battery capacity

Battery capacity

2.5 Selection and activation of user functions

Gauge mode ->26
Input microbubble level ->30
Input O mix ->18
2
Logbook ->39
Dive planner ->37
10
• automatically, on submerging in water or when adaptation to atmospheric
pressure is necessary;
• manually, by bridging contacts on housing (B-E).
• When TEC is in state of rest no information is displayed but
the atmospheric pressure is continuously monitored. If a
higher altitude range is detected, TEC switches on for 3 minu-
NO
tes automatically. -> 25
NO
%
2
• TEC switches on by bridging the contacts B and E. All
segments light up for 5 seconds.
Afterwards the display shows the selected O
temperature and in certain circumstances an altitude range
Temperature
->25.
O Mix
2
If the appertaining transmitter is switched on and located
within transmitting distance, the tank pressure is displayed,
otherwise <---> will be displayed. If no transmitter has been
Do not fly icon
paired yet, the display will be blank.
No-fly time
If there is a remaining saturation due to the last dive or
Oxygen toxicity
change of altitude, TEC also displays the remaining desatu-
ration time, the oxygen toxicity and the "no-fly time" ->24.
Desaturation time
After switching on TEC you can check the battery capacity by bridging the
contacts B and E. The remaining capacity is displayed for 3 seconds as a per-
centage. If the value reaches 0%, the battery warning gets activated (->17) and
the battery has to be replaced by an authorised SCUBAPRO UWATEC dealer.
For a 7-day diving vacation TEC uses between 2 – 5 % of its battery capacity.
At the surface you can select the dive planner, the logbook
and gauge mode as well as the functions to enter the O
mix and the microbubble levels by bridging the contacts +
and B or – and B.
After the selection of the desired function you can activate and deactivate it by
bridging the contacts B and E.
Details to the user functions are to be found on the pages mentioned above.
mix, the
2
%
2
