2 Operation

2.2 Switching on the display

DEPTH DIVE TIME
F
C
DEPTH
NO
CNS O
MAX.DEPTH DECO INFO S
L
O
W
DECO STOP
LEVELSTOP
NO STOP
MAX.DEPTH
%
C
DEPTH DIVE TIME
MAX.DEPTH DECO INFO
%
C
DEPTH DIVE TIME
NO
h
CNS O %
2
%
DESAT
h
MAX.DEPTH DECO INFO

2.3 Checking the battery capacity

%
DIVE TIME
Battery capacity

2.4 Selection and Activation of User Functions

Input Microbubble-Level (page 24)
Input O Mix (page 14)
2
Logbook (page 29)
Dive planner (page 27)
II Uwatec ® Smart dive computers
• automatically, on submerging in water or when adaptation to atmospheric
pressure is necessary.
• manually by manipulating contacts on housing (B-E).
• COM on opening the tank valve (if connected) (Tank pressure ≥ 8 bar / 116 psi).
• When the Smart is in state of rest; no information is dis-
%
played but the atmospheric pressure is continuously moni-
DIVE TIME
NO
tored. If a higher altitude is detected, it switches on for 3
h
%
2
minutes automatically. See also page 21.
LOG
%
SPEED
DESAT
ft
h • The Smart switches on by bridging the contacts B and E. To
m
DECO INFO
check the display, all signs light up for 5 seconds.
O Mix
2
Afterwards the display shows the selected O
perature and in certain circumstances an altitude section
(see page 21). The Smart Com displays the tank pressure
Temperature
also.
If there is a remaining saturation due to the last dive or
Do not fly
change of altitude, the Smart also displays the remaining
symbol
desaturation time, the Oxigen toxicity and the "No fly time"
No fly time
(see page 20).
Oxygen Toxicity
Desaturation time
After switching on the Smart you can check the battery capacity with the
contact E. The remaining capacity is displayed during 3 seconds as a percenta-
ge. If the value reaches 0%, the battery warning gets activated (see page 13)
and the battery has to be replaced by an authorised Scubapro-Uwatec dealer.
A battery capacity of 2 to 5 % is definitely enough energy for the dives of usual
dive vacations (20 to 50 dives).
With the contacts + and – you can select the Dive Planner,
the Logbook and the functions to enter the O
the Microbubble-Level.
After the selection of the desired function you can activate and deactivate it
with the contact E.
Details to the user functions are to be found on the pages mentioned above.
II
mix, the tem-
2
% Mix and
2
9
