1Wireless Router

1
What' s in the Box?
Overview of the Wireless Router

Wireless Router Applications

This chapter gives the introduction to the Wireless Router.
Your Wireless Router box should contain the items listed below
• 1 Wireless Router
• 1 AC Adapter, AC 9V 1A
• 1 RS-232 serial cable with DB-9 (9 pin) male connector and RJ45 plug to
connect the Wireless Router Console/COM port and external ISDN TA/Analog
Modem
• 1 female to female 9 pin adaptor to connect the Wireless Router Console port to a
PC COM port.
• 1 CAT5 UTP cross-over LAN cable to connect the Wireless Router EWAN port
to an external ADSL or Cable Modem
Note:
Some Cable Modems use straight LAN cable
• 1 CD-ROM containing the online documentation
• 1 Quick-Start Guide
The Wireless Router is a small desktop router that sits between your local Ethernet
network and a remote network (e.g., the Internet or a remote office). The Wireless
Router contains an EWAN port connecting to an external ADSL/Cable modem , a
Console/ COM port for connection to a console device(such as a PC COM port ), and
a four-port 10/100Mbps Ethernet switch for connection to PCs on your local network.
The Console/COM port can alsobe used to connect to the Internet(as a back-up such
as when the ADSL/Cable modem line is not operational) or a remote office via an
external ISDN TA or Analog Modem, and even allows a remote user(a tele-commuter
or a traveling sales person) to dial in and access your local network.
Data comes into the Wireless Router from the local LAN and then is "routed" to the
remote network, and vice versa.
The main functions of the Wireless Router
-to allow devices on your LAN to access the Internet,
-to allow access to the servers from the public network,
Introduction
1-1
