Configuring A Basic Internet Access Profile Via Modem - Sitecom Wireless Router User Manual

profile.
Obtain IP Addresses Automatically: Some DSL-based ISPs use PPPoE
to establish communication with end-users.
ISP Account Name: the username of your ISP account
ISP Account Password: the password of your ISP account
(Optional) Service Name: the Service Name provided by your ISP, if one
is required, otherwise, leave it empty
(Optional) Access Concentrator Name: the Access Concentrator Name
provided by your ISP, if one is required, otherwise, leave it empty
Idle Timeout(0-3600 seconds): The default value of the idle timeout is
120 seconds. It represents the number of seconds of inactivity over the
connection: when this value is reached, the Wireless Router will
disconnect the call. You can change the idle timeout value to anything
between 0 to 3600 seconds. But if you select 0, the connection will never
time out.
(Optional) Host Name (System Name): the Host Name provided by your
system.
Note:
After configuring each item, please go to step 4.
Step 4
Click APPLY or APPLY and Test
Note:
When you click Apply or Apply and Test , the Wireless Router connects to
your Internet Service Provider. Watch the Message Window for any messages. If the
test is successful, your users will be ready to access the Internet. If not, the Wireless
Router will try to give you enough information to let you know why the connection is
not successful.
If Apply or Apply and Test is successful, users on your LAN can now start to
access the Internet. However, it is required that these devices have also been
configured to obtain IP addresses automatically, as described in Chapter 2. Users may
need to re-boot their computers in order to obtain the DNS information obtained
during the Apply or Apply and Test operation.
Configuring a Basic Internet Access Profile( via
Modem)
.The following screen show you the interface configuration via Modem.
3-9
