Connecting the base station

In order to be able to make calls with your
phone via the fixed network and via VoIP,
you must connect the base station to
the fixed network and the Internet, see
Figure 1.
Figure 1 Connecting the phone to the fixed network and the Internet
1 Internet connection:
Router and modem (in picture) or
router with integrated modem
2 Aton CL700 IP base station
3 Aton CL300 V2 handset
4 PC in LAN
4
LAN
1
3
1
2
Follow the steps in the order given
below:
1. Connect the base station to the fixed
network phone connection
2. Connect the base station with the
mains power supply
3. Connect the base station with the
router
Important:
The connection sequence must be followed
exactly!
First steps
Internet
Fixed network
9
