Left-side View
1
1.
CD-ROM
The CD-ROM device was fixed inside the notebook.
2.
CD-ROM Eject Button
The eject button opens the CD-ROM tray.
3.
PC Card Slot
The slot is where PC Card (PCMCIA) is inserted.
A PC Card slot with connectors for two 3.3V/5V cards, and
both of them support CardBus technology.
4.
PC Card Eject Button
With this button, you may have the PCMCIA card ejected.
Note:
There are two kind of types of CD-ROM might be installed as shipped. One
is electrical and the other is mechnical. Basically, the mobile computor is
equipped to the electrical CD-ROM. With this device, you can do the CD-
ROM ejection only if the system is on. As for bundling the mechnical type,
the ejection button works all the time, even the system is powered off.
Please be also noted, the mechnical one is not avaliable to eject the CD-
Disk by performing Fn key under the running Windows 98 operating system.
2
3
4
1-9
