Summary of Contents for MAXDATA M-Book 6000 G4

  • Page 1 V15.1.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Erp Off Mode Power Consumption Statement

    Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.

  • Page 5: Energy Star

    Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

  • Page 8: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 9: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 11: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer.  • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.

  • Page 12: Polymer Battery Precautions

    Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.

  • Page 13: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 14: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 15: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 16 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 17 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 18: Lcd Screen Care

    Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 19: Table Of Contents

    Preface Contents Notice ................................I ErP Off Mode Power Consumption Statement: ................... II Energy Star© ..............................III FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Power Safety ...............................IX Polymer Battery Precautions ........................X Battery Precautions .............................XI Cleaning ..............................
  • Page 20 Preface Model Differences .............................1-5 System Map: LCD Panel Open ........................1-6 LED Indicators ............................1-7 Keyboard ..............................1-8 Keyboard Shortcuts ...........................1-9 Function/Hot Key Indicators ........................1-10 Control Center ............................1-11 System Map: Front & Top Views ......................1-12 System Map: Left View ...........................1-13 System Map: Right & Rear Views ......................1-14 System Map: Bottom View ........................1-16 3G/4G Module USIM Card Installation ....................1-17 Docking Port ............................1-18...
  • Page 21 Preface Features & Components Overview ..............................2-1 Hard Disk Drive ............................2-2 Optical (CD/DVD) Device ........................2-3 Loading Discs ............................2-3 Handling CDs or DVDs ..........................2-4 DVD Regional Codes ..........................2-5 Multi-In-1 Card Reader ..........................2-6 ExpressCard Slot ............................2-7 Inserting and Removing ExpressCards ......................2-7 Touchpad and Buttons/Mouse ........................2-7 Gestures and Device Settings ........................2-8 Audio Features ............................2-13 Setup for Audio Recording ........................2-14...
  • Page 22 Preface Power Plans ...............................3-5 Power-Saving States ..........................3-7 Sleep ................................3-7 Hibernate ..............................3-8 Shut down ..............................3-8 Configuring the Power Buttons .........................3-9 Resuming Operation ..........................3-11 Power Conservation Modes ........................3-12 Battery Information ..........................3-15 Battery Power ............................3-15 Conserving Battery Power ........................3-16 Battery Life ..............................3-17 New Battery .............................3-17 Recharging the Battery with the AC/DC Adapter ...................3-17 Proper handling of the Battery Pack ......................3-18 Battery FAQ .............................3-19...
  • Page 23 Preface User Account Control ..........................4-6 Windows Security Message ........................4-6 New Hardware Found ..........................4-6 Driver Installation Procedure ........................4-7 Chipset ...............................4-7 Video (VGA) .............................4-7 LAN ................................4-7 CardReader ..............................4-7 Touchpad ..............................4-7 Airplane ..............................4-7 Hot Key ..............................4-8 MEI Driver ..............................4-8 Audio .................................4-8 Optional Drivers ............................4-9 BIOS Utilities Overview ..............................5-1 The Setup Utility ............................5-2...
  • Page 24 Preface Main Menu ..............................5-5 System Time & Date (Main Menu) ......................5-5 SATA Port # (Main Menu) ........................5-6 System/Extended Memory: (Main Menu) ....................5-6 MB Series / BIOS Revision / KBC/EC firmware Revision ..............5-6 Advanced Menu ............................5-7 Advanced Chipset Control (Advanced Menu) ..................5-8 VT-d (Advanced Menu >...
  • Page 25 Preface Set Supervisor Password (Security Menu) ....................5-12 Set User Password (Security Menu) ......................5-13 Password on boot (Security Menu) ......................5-13 Secure Boot Support (Security Menu) .....................5-13 TPM Configuration (Security Menu) ......................5-14 TPM State (Security Menu > TPM Support Enabled) ................5-15 Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) .........5-16 Boot Menu ...............................5-17 Boot Option Priorities (Boot Menu) ......................5-18 UEFI Boot (Boot Menu) ..........................5-18...
  • Page 26 Preface PC Camera Module ............................7-3 PC Camera Audio Setup ..........................7-4 Camera App ...............................7-5 Camera Options ............................7-6 Taking Pictures/Capturing Video ......................7-7 Camera Roll ...............................7-8 Wireless LAN Module ..........................7-12 3rd Party 802.11b/g/n Driver Installation ....................7-13 Intel® WLAN Driver Installation ......................7-13 WLAN Configuration in Windows ......................7-14 Security Modules (Fingerprint &...
  • Page 27 Preface Infineon Security Platform Settings Tool ....................7-32 Intel Rapid Storage Technology ......................7-40 IRST Driver Installation ..........................7-40 Intel® vPro™ Technology ........................7-41 Accessing the Intel Management Engine ....................7-41 Intel® Management and Security Status ....................7-43 Intel® Rapid Start Technology Driver ....................7-47 Intel® Rapid Start Technology Configuration ..................7-48 Intel®...
  • Page 28 Preface Troubleshooting Overview ..............................8-1 Basic Hints and Tips ..........................8-2 Backup and General Maintenance ......................8-3 Viruses ...............................8-4 Upgrading and Adding New Hardware/Software ..................8-5 Problems and Possible Solutions .......................8-7 EM820W 3G Module PIN Code & Power-Saving ..................8-15 Resolving the “Insert a SIM” issue with the 3G Module (Windows 8.1) ..........8-17 Interface (Ports &...
  • Page 29 Preface Attaching Other Displays ........................C-15 Attaching Other Displays - Devices (Charms Bar) ................C-18 Configuring an External Display In Windows ..................C-19 HDMI Audio Configuration ........................C-21 Specifications Processors ..............................D-2 Core Logic ..............................D-2 Display ..............................D-2 Memory ..............................D-2 Video .................................D-2 BIOS .................................D-2 Storage ..............................D-3 Audio ................................D-3 Keyboard, Pointing Device &...
  • Page 30 Preface Power Management ..........................D-4 Power ................................D-4 Security ..............................D-4 LED Indicators ............................D-4 Operating System ............................D-4 Design Features ............................D-4 Environmental Spec ..........................D-4 Dimensions & Weight ..........................D-5 Docking Station Guide Overview ..............................E-1 Compatibility ............................E-1 Computer and Docking Station ........................ E-2 Docked System Power ..........................E-2 System Map: Front View ..........................
  • Page 31 Preface Power Button Configuration ........................E-17 Docking Station Ports & Jacks ....................... E-18 Multiple Displays ............................ E-21 BIOS Controls - USB ports, Card Reader & ExpressCard ..............E-21 One Button Hard Disk Backup ....................... E-22 Backup Procedure ........................... E-23 System Image Backup ..........................E-25 System Image Recovery .........................
  • Page 32 Preface Windows 10 Start Menu ........................... F-2 Right-Clicking the Windows Logo In Start Menu ................... F-3 Start Menu Apps & Tiles .......................... F-4 Pining/Unpinning Apps & Programs to/from the Start Menu ..............F-5 Windows 10 Control Panel ........................F-6 Settings ..............................F-7 Windows 10 Taskbar ..........................
  • Page 33 Preface MEI Driver .............................. F-18 Audio ..............................F-18 Optional Drivers ............................. F-18 Wireless LAN Module ..........................F-19 3rd Party WLAN Driver Installation ...................... F-20 Intel® WLAN Driver Installation ......................F-20 Fingerprint Reader Module ........................F-21 Fingerprint Reader Driver Installation ....................F-21 Fingerprint Module Configuration ......................
  • Page 34 Preface XXXII...

  • Page 35: Quick Start Guide Overview

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 36: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 37: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows 8.1) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 38: System Startup

    Quick Start Guide System Startup Remove all packing materials and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 39: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 8.1 (64-bit) operating system is supported.

  • Page 40: System Map: Lcd Panel Open

    Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open  Built-In PC Camera (Optional) Wireless Device PC Camera LED Operation Aboard Aircraft Power Button The use of any portable LED Indicators electronic transmission Keyboard devices aboard aircraft is Built-In Microphone usually prohibited.

  • Page 41: Led Indicators

    Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Airplane Mode is ON (the WLAN, Orange AC/DC Power is Plugged In Green Bluetooth &...

  • Page 42: Keyboard

    Quick Start Guide Keyboard  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards function keys to change operational features instantly. If your keyboard is dam- Function Keys aged or you just want to make a change, you can use any standard USB keyboard.

  • Page 43: Keyboard Shortcuts

    Quick Start Guide Keyboard Shortcuts  The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi- gation/operation in Windows 8.1. Windows Logo Keyboard Shortcut Windows Logo Use the Windows logo Description Key + + D key com- bination switch Toggle between the Start screen and the foremost running app or the from the Start screen...

  • Page 44: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...

  • Page 45: Control Center

    Quick Start Guide Control Center When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Con- trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad on/off (see Appendix B...

  • Page 46: System Map: Front & Top Views

    Quick Start Guide System Map: Front & Top Views Figure 1 - 5 Front & Top Views (with Optional Docking Station) Touchpad Switch LED Indicators Docking Station (Optional)  Docking  .If your purchase in- cludes the docking sta- Touchpad Switch tion, open the docking port cover latch and Touchpad...

  • Page 47: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 6 Left View DC-In Jack External Monitor Port RJ-45 LAN Jack  e-SATA Port  AC/DC Powered External Monitor Port & RJ- USB 3.0 Port Multi-In-1 Push-Push Card Reader 45 LAN Jack 2 * USB 3.0 Ports The card reader allows you to use the most popular dig- If you are using a VGA cable...

  • Page 48: System Map: Right & Rear Views

    Quick Start Guide System Map: Right & Rear Views Figure 1 - 7 Right & Rear Views Microphone-In Jack Headphone-Out / S/PDIF Out Combo Jack 1 * USB 2.0 Port 4. Optical Device Drive Bay (for CD/ DVD Device)  Security Lock Slot Headphone / S/PDIF Out Combo Jack...
  • Page 49 Quick Start Guide   Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.

  • Page 50: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 8 Bottom View  Battery Docking Port The CPU is not a user ser- Fan Intake/Vent viceable part. Component Bay Cover Overheating HDD Bay Cover To prevent your computer Speakers from overheating make...

  • Page 51: 3G/4G Module Usim Card Installation

    Quick Start Guide 3G/4G Module USIM Card Installation If you have included an optional 3G/4G module in your purchase option, follow the instructions below to install the USIM card (which will be provided by your service provider), and then use the Charms Bar Wireless icon to access the 3G/4G network in the same manner as the WLAN (see page 69).

  • Page 52: Docking Port

    Quick Start Guide Docking Port Follow the instructions below before connecting the computer to the docking station, if included in your pur- chase configuration. Failure to open the cover of the docking port before connecting the computer to the docking station may result in irreparable damage to the connector on the docking station.

  • Page 53: Windows 8.1 Control Panel

    Quick Start Guide Windows 8.1 Control Panel  Throughout this manual you will see an instruction to open the Control Panel. Windows Versions R ight-click the lower left hot corner to bring up the context menu (or use the Win- + X key combination) and select Control Panel in both the dows Logo Key Note that the informa-...
  • Page 54 Quick Start Guide The Control Panel can be accessed in a number of ways in Windows 8.1. • Click Search in the Windows Charms Bar (see previous page) and the search pane will pop out. Type Control Panel and select it from the results to the left. •...
  • Page 55 Quick Start Guide Right-click the Start button in the Desktop app (or use the Windows Logo Key  + X key combination) to bring up an advanced context menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Display Most Search, File Explorer, Command Prompt, Device Manager and Network Connec- Recently Used...

  • Page 56: Windows 8.1 Start Screen & Desktop

    Quick Start Guide Windows 8.1 Start Screen & Desktop The Apps, control panels, utilities and programs within Windows are accessed from the Start screen and/or Windows Desktop app. The Desktop (which runs as an app within the Start screen) can be accessed by clicking the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination).

  • Page 57: Apps & Tiles

    Quick Start Guide Apps & Tiles The Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary Apps.

  • Page 58: Desktop Application

    Quick Start Guide Desktop Application When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop app.

  • Page 59: The Charms Bar

    Quick Start Guide The Charms Bar The right side of the screen (Start or Desktop) displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.
  • Page 60 Quick Start Guide Charms Bar Items • Search : You can search for any file, application, Apps and control panel settings with instantaneous results. • Share : This button is used to share information with people via mail or social networks. •...

  • Page 61: Windows 8.1 Taskbar

    Quick Start Guide Windows 8.1 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar (system tray). In Windows 8.1 the taskbar can be directly accessed from the Desktop application; if you are in the Start screen you will need to move the cursor to the bottom of the screen to display the taskbar.

  • Page 62: Video Features

    Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows when running the Desktop app (see “Desktop Application” on page 1 - 24). It is possible to quickly configure external displays from the Devices menu item in the Charms Bar (see “The Charms Bar”...
  • Page 63 Quick Start Guide To access Display (Control Panel) and Screen Resolution in Windows 8: Go to the Control Panel. Click Display (icon) - In the Appearance and Personalization category. Adjust resolution.  Right-Click Desktop You can right-click the desktop and select Screen reso- lution (Figure 1 -...
  • Page 64 Quick Start Guide To access the Intel(R) HD Graphics Control Panel: Click Advanced settings (Figure 1 - 20 on page 1 - 29) in the Screen Resolution control panel in Win- dows. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 21 on page 1 - 30) .

  • Page 65: Power Options

    Quick Start Guide Power Options Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power Menu item in Set- tings in the Charms Bar in Windows 8.1 may be used to Shut down or Restart (you can also add Hibernate/ Sleep to the menu - see “Adding Hibernate/Sleep to the Power Menu”...

  • Page 66: Running Apps

    Quick Start Guide Running Apps To run apps in Windows 8.1 you will need to check that the Screen Resolution and User Account Control Set- tings are compatible with the system requirements. Screen Resolution Settings Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).
  • Page 67 Quick Start Guide User Account Control Settings If your computer meets the minimum screen resolution requirements, and still you can't run apps, then that you have to check the status of User Account Control (UAC). Apps may fail to open when the UAC is turned off. To check whether the UAC is on or off, follow the instructions below.
  • Page 68 Quick Start Guide 1 - 34...

  • Page 69: Features & Components Overview

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-In-1 Card Reader • ExpressCard Slot •...

  • Page 70: Hard Disk Drive

    Features & Components Hard Disk Drive  The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm or 7 mm.

  • Page 71: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page D - 3). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 72: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.

  • Page 73: Dvd Regional Codes

    Features & Components DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.

  • Page 74: Multi-In-1 Card Reader

    Features & Components Multi-In-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Push-Push Card card into the slot and it will appear as a removable device, and can be accessed in Reader the same way as your hard disk (s).

  • Page 75: Expresscard Slot

    Features & Components ExpressCard Slot  The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you install the Card Reader driver (see “CardReader”...

  • Page 76: Touchpad And Buttons/Mouse

    Features & Components Touchpad and Buttons/Mouse  The Touchpad is an alternative to the mouse; however, you can also add a mouse to Touchpad Scrolling your computer through one of the USB ports. The Touchpad buttons function in This computer model se- much the same way as a two-button mouse.

  • Page 77: Gestures And Device Settings

    Features & Components Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- tion) on the surface of the Touchpad to perform specific actions to manipulate doc- Show Video uments, objects and applications. You can get a clearer view of the gestures in- You can configure the settings from the Device Settings tab in Mouse Properties:...
  • Page 78 Features & Components Disabling the Touchpad If you need to disable the Touchpad for any reason (e.g. you may find that when us- ing the computer’s internal keyboard you accidentally trigger the Touchpad when resting your wrists or palms on it) you can do so by using Fn + F1 key combination. You can also set the system to automatically disable the internal Touchpad when an external USB point device (e.g.
  • Page 79 Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 9 tinuous motion).
  • Page 80 Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.

  • Page 81: Audio Features

    Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar The sound volume level notification area/control panel (right-click the taskbar notification area icon can be set using the vol- bring up an audio menu).

  • Page 82: Setup For Audio Recording

    Features & Components Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Go to the Control Panel. Click Realtek HD Audio Manager (Hardware and Sound), or right-click the taskbar icon and select Sound Manager.

  • Page 83: Power Management Overview

    Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 84: The Power Sources

    Power Management The Power Sources  The computer can be powered by either an AC/DC adapter or a battery pack. Forced Off AC/DC Adapter If the system “hangs”, Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ and the Ctrl + Alt + Del key combination doesn’t DC adapter will damage the computer and its components.

  • Page 85: Turning On The Computer

    Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- er button on the front panel. When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down).

  • Page 86: Shutting The Computer Down

    Power Management Shutting the Computer Down Note that you should always shut your computer down by choosing the Shut down command as this will help prevent hard disk or system problems. Use the Shut down or sign out item in the Context Menu (right-click the lower left corner of the screen to bring up the menu).

  • Page 87: Power Plans

    Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 88 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.

  • Page 89: Power-Saving States

    Power Management Power-Saving States  You can use power-saving states to stop the computer’s operation and restart where Wake On LAN you left off. Win 8.1 uses the Sleep, Hibernate and Shut Down power-saving Support states. (Windows 8) Wake-On-LAN is only Sleep supported from Sleep or In Sleep all of your work, settings and preferences are saved to memory before the...

  • Page 90: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 91: Configuring The Power Buttons

    Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
  • Page 92 Power Management Adding Hibernate/Sleep to the Power Menu Add Hibernate/Sleep to the Power Menu as follows. Go to the Power Options (Hardware and Sound) control panel. Click “Change settings that are currently unavailable” Click Choose what the power buttons do. Click to put a check in the Hibernate/Sleep box under Shutdown settings.

  • Page 93: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Power Status To Resume Icon Color Table 3 - 1 Power Off Press the Power Button Resuming Press the Power Button...

  • Page 94: Power Conservation Modes

    Power Management Power Conservation Modes  This system supports Energy Star power management features (see over) that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated Power Conservation period of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
  • Page 95 Power Management  Energy Star Notes Display Mode Off By factory default the Energy Star setting will put the display into sleep within 15 minutes of user inactivity in order to reduce power consumption. The display will wake up upon sensing a key press or mouse movement.
  • Page 96 Power Management Ctrl + Alt + Delete Key Combination You can use the CTRL + ALT + DEL key combination from almost any of the Win- dows 8 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Log off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.

  • Page 97: Battery Information

    Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.

  • Page 98: Conserving Battery Power

    Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 99: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.

  • Page 100: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances Caution • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 101: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 102 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 12 Change Plan Settings / Change Advanced Power Settings 3 - 20 Battery Information...
  • Page 103 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 13 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 104 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 105: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities  This chapter deals with installing the drivers and utilities essential to the operation or Driver Installation & improvement of some of the computer’s subsystems. The system takes advantage of Power some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.

  • Page 106: Driver Installation

    Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc into the computer’s DVD drive. Click the message “Tap to choose what happens with this disc.” Click Run autorun.exe. Click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Figure 4 - 1 - Drivers Installer Screen 1 4 - 2 Driver Installation...
  • Page 107 Drivers & Utilities Check the driver installation order from Table 4 - 1, on page 4 - 4 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below. Click to select the driver you wish to install, (you should note down the drivers as you install them). Follow the instructions for each individual driver installation procedure as listed on the following pages.
  • Page 108 Drivers & Utilities Win 8.1 (64 bit) Driver Page # Win 8.1 - Optional Items Page # Chipset Page 4 - 7 PC Camera Module (No driver required for Windows 8.1) Page 7 - 3 Video (VGA) Page 4 - 7 Wireless LAN Module Page 7 - 12 Page 4 - 7...

  • Page 109: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.

  • Page 110: User Account Control

    Drivers & Utilities User Account Control  If a User Account Control prompt appears as part of the driver installation procedure, click Continue or Driver Installation General Guidelines Allow, and follow the installation procedure as direct- The driver installation procedure outlined in this Chapter (and in Chapter 7 Options &...

  • Page 111: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure CardReader Insert the Device Drivers & Utilities + User’s Manual 1. Click 4.Install Cardreader Driver > Yes. disc and click Install Drivers (button). 2. Click Finish. Chipset Touchpad 1. Click 1.Install Chipset Driver > Yes. 1.

  • Page 112: Hot Key

    Drivers & Utilities Hot Key It is recommended you now also install the Intel Rap- id Storage Technology driver (see “Intel Rapid Stor- 1. Click 7.Install Hotkey AP > Yes. age Technology” on page 7 - 40 - required for AHCI 2.

  • Page 113: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 4 for the driver installation procedures for any modules in- cluded in your purchase option. Figure 4 - 3 - Option Drivers Note that you need to install both the WLAN &...
  • Page 114 Drivers & Utilities 4 - 10...

  • Page 115: Bios Utilities Overview

    BIOS Utilities Chapter 5: BIOS Utilities  BIOS Screens Overview Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- ting up your system’s system (e.g.

  • Page 116: The Setup Utility

    BIOS Utilities The Setup Utility  Each time you turn on the computer the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...

  • Page 117: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized distributor/supplier as soon as possible.

  • Page 118: Setup Screens

    BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.

  • Page 119: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.

  • Page 120: Sata Port # (Main Menu)

    BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.

  • Page 121: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Menu 5 - 7...

  • Page 122: Advanced Chipset Control (Advanced Menu)

    BIOS Utilities Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting and enable/ disable VT-d, Intel Virtualization Technology, Intel TXT(LT) Support, mSA- TA/3G Slot Support and USB 3.0 port power/ Card Reader/ PCI Express Card Power/ E-SATA Power.

  • Page 123: Msata/3G Slot Support (Advanced Menu > Advanced Chipset Control)

    BIOS Utilities mSATA/3G Slot Support  (Advanced Menu > Advanced Chipset Control) Select which device is installed in the mSATA/3G slot from this menu option. Select m/SATA/3G Slot the appropriate device installed in the slot from the menu, and then save the changed Support BIOS settings.

  • Page 124: Usb 3.0 Power/ Card Reader Power / Pci Express Card Power / E-Sata Power / (Advanced Menu > Advanced Chipset Control)

    BIOS Utilities USB 3.0 Power/ Card Reader Power / PCI Express Card Power /  E-SATA Power / (Advanced Menu > Advanced Chipset Control) These menu items allow you to enable/disable power to the card reader, Express Powered USB Port Card or USB ports when required to do so in order to save power.

  • Page 125: Sata Mode (Advanced Menu)

    BIOS Utilities SATA Mode (Advanced Menu) The SATA (Serial ATA) controller operates in AHCI (Advanced Host Controller Interface) mode. Install the Intel Rapid Storage Technology driver to support your drive in AHCI mode (see “Intel Rapid Storage Technology” on page 7 - 40).

  • Page 126: Security Menu

    BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...

  • Page 127: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Aptio Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to Password Warning set a Password on Boot (see below).

  • Page 128: Tpm Configuration (Security Menu)

    BIOS Utilities TPM Configuration (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select TPM Configuration and press En- ter to access the sub-menu. Press Enter to access the Security Device Support menu and select Enable to display the full TPM configuration menu (see “Trusted Plat- form Module”...

  • Page 129: Tpm State (Security Menu > Tpm Support Enabled)

    BIOS Utilities TPM State (Security Menu > TPM Support Enabled) Select TPM State, press Enter and select Enable to change the TPM state to en- abled. You will then need to press F4 to save the changes and restart the computer. Figure 5 - 7 TPM State (Enabled) As the computer restarts press F2 to enter the BIOS again and go to the TPM Con-...

  • Page 130: Pending Tpm Operation (Security Menu > Tpm Support & Tpm State Enabled)

    BIOS Utilities Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) Select Pending operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer.

  • Page 131: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 9 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.

  • Page 132: Boot Option Priorities (Boot Menu)

    BIOS Utilities Boot Option Priorities (Boot Menu) Press Enter to access the menu, use the arrow keys to move up and down the menu, and press Enter to select a device from the Boot Option # list (the selected device will be highlighted in white).

  • Page 133: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 10 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
  • Page 134 BIOS Utilities 5 - 20...

  • Page 135: Upgrading The Computer Overview

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.

  • Page 136: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- dures, make sure that...

  • Page 137: Removing The Battery

    Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Slide the latch...

  • Page 138: Removing/Replacing The Component Bay Cover

    Upgrading The Computer Removing/Replacing the Component Bay Cover  Turn off the computer, and turn it over and remove the battery. Warranty Warning Remove screws and lift the component bay cover up at point remove cover Please check with your Replace the component bay cover by aligning the four cover pins with slots in the service representative...

  • Page 139: Upgrading The Optical (Dvd) Device

    Upgrading The Computer Upgrading the Optical (DVD) Device Turn off the computer, and turn it over and remove the battery and component bay cover (see page Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install any new optical device.

  • Page 140: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive  The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) / 7mm (h) (see “Storage” on page D - 3).
  • Page 141 Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws & Remove the hard disk bay cover Raise the HDD assembly up at point and then slide the assembly out by gripping the tab and sliding the assembly out of the bay in the direction of the arrow.
  • Page 142 Upgrading The Computer Remove the screw(s) & and the adhesive cover  Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers) Hard Disk Handling Do not press down on the center off the hard disk as this area houses the hard disk drive mo-...

  • Page 143: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR3L type memory modules (see “Memory” on page D - 2 for details of supported module types). Turn off the computer, and turn it over and remove the battery and component bay cover (see page The memory (RAM) slots will be visible at point...
  • Page 144 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - The RAM module will pop-up, and you can remove it. Figure 6 - 7 RAM Module Release Removal ...
  • Page 145 Upgrading The Computer Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it will go.
  • Page 146 Upgrading The Computer 6 - 12...

  • Page 147: Modules & Options Overview

    Modules & Options Chapter 7: Modules & Options  Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
  • Page 148 Modules & Options  Important Notice If your purchase option includes both Wireless LAN and 3G/4G modules, then the appro- priate antennas will be installed. Note that In order to comply with FCC RF exposure com- pliance requirements, the antenna must not be co-located or operate in conjunction with any other antenna or transmitter.

  • Page 149: Pc Camera Module

    Modules & Options PC Camera Module When the PC Camera application is run the LED indicator to the left of the camera will be illuminated in (see Figure 1 - 2 on page 1 - 6). Note that you need to use the Camera app in Windows to take pictures and capture video.

  • Page 150: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you want to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Control Panel. Click Sound (Hardware and Sound) and click Recording (tab). Right-click hold and release Microphone (Realtek High Definition Audio) and make sure the item is not disabled.

  • Page 151: Camera App

    Modules & Options Camera App Run the Camera app from the Start screen by clicking on the Camera app icon The camera interface will display two buttons on the right side of the screen. Figure 7 - 2 Camera App Buttons ...

  • Page 152: Camera Options

    Modules & Options Camera Options The Camera Options settings may be accessed as follows: Run the Camera app from the Start screen by clicking on the Camera app icon While the camera app is running access the Charms Bar (e.g. click Use the Windows logo key + C key combination).

  • Page 153: Taking Pictures/Capturing Video

    Modules & Options Taking Pictures/Capturing Video Run the Camera app from the Start screen by clicking on the Camera app icon Right-click the screen and select the timer if you require a countdown before capture. Click the appropriate icon to take a picture or start video capture (if video capture begins a timer will appear in the bottom corner of the screen).

  • Page 154: Camera Roll

    Modules & Options Camera Roll Run the Camera app from the Start screen by clicking on the Camera app icon Right-click on the screen to bring up menu buttons at the bottom of the screen. Click Camera Roll. Click the arrows (on either side of the screen) to browse through the captured photos/video, and back to the Camera app.
  • Page 155 Modules & Options photo with the edited changes), Update original (which changes the original picture permanently) or Undo any changes. Click the Edit button to bring up a full suite of tools to edit the photo. 10. Click on the menu headings on the left, and then click on the tool on the right to edit the photo as required.
  • Page 156 Modules & Options Editing Videos Clicking on a captured video will bring up an app bar with a series of buttons. Figure 7 - 8 Edit Buttons (for Video) Click Delete to remove any video from the camera roll (you will be asked to click Delete again to confirm the deletion).
  • Page 157 Modules & Options Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).

  • Page 158: Wireless Lan Module

    Modules & Options Wireless LAN Module  If you have included an Intel® or 3rd Party WLAN module in your purchase option Wireless Device make sure that the module is on (i.e. the system is not in Airplane Mode) before in- Operation Aboard stalling the driver.

  • Page 159: 3Rd Party 802.11B/G/N Driver Installation

    Modules & Options 3rd Party 802.11b/g/n Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install WLAN Driver > Yes. 4.

  • Page 160: Wlan Configuration In Windows

    Modules & Options WLAN Configuration in Windows You can configure a wireless connection using one of the following options, how- ever make sure the Wireless LAN module is turned on (and not in Airplane Mode) before configuration begins. Charms Bar Go to the Charms Bar.
  • Page 161 Modules & Options Double-click an access point to connect to it (or click it and click Connect). Enter a network security key (password) if required, and click Next. You can choose to find other devices or not. When you are connected to the network access point it will display Connected Select any connected network and click Disconnect to disconnect from a connected access point.
  • Page 162 Modules & Options Desktop Mode Switch to the Windows Desktop (click the app or use the Windows logo key D key combination). Click the wireless icon in the notification area of the taskbar. A list of available access points will appear. Double-click an access point to connect to it (or click it and click Connect).

  • Page 163: Security Modules (Fingerprint & Tpm)

    Modules & Options Security Modules (Fingerprint & TPM)  The encrypted channel between the Trusted Platform Module security chip (see Password Warning “Trusted Platform Module” on page 7 - 26) and the fingerprint reader (see “Fin- gerprint Reader Module” on page 7 - 18) provides a high level of security for your If you set passwords for computer.

  • Page 164: Fingerprint Reader Module

    Modules & Options Fingerprint Reader Module The fingerprint reader module provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. Fingerprint Reader Driver Installation 1.

  • Page 165: Fingerprint Module Configuration

    Modules & Options Fingerprint Module Configuration Go to the Charms Bar. Select Settings and then click Change PC Settings. Click Accounts and then click Sign-in options. You will need to add a Windows password (click Add under Password). After you have added the password you will need to restart the computer and use your password to log on to the system.
  • Page 166 Modules & Options 10. Input the Windows password and click OK. 11. You will then be instructed to swipe the same finger across the reader a number of times. Figure 7 - 14 Add a Fingerprint 12. Click Finish. 13. You can choose to Add another finger (this is recommended) or Remove the current fingerprint reading.

  • Page 167: Bluetooth & Wlan Combo Module

    Modules & Options Bluetooth & WLAN Combo Module  If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed overleaf. Operation Aboard Aircraft Make sure that the module is on (i.e. the system is not in Airplane Mode) before in- stalling the driver.

  • Page 168: 3Rd Party Bluetooth (V4.0) Combo Driver Installation

    Modules & Options 3rd Party Bluetooth (V4.0) Combo Driver Installation  1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. High Speed Bluetooth Data Transfer 2.

  • Page 169: Bluetooth Configuration In Windows

    Modules & Options Bluetooth Configuration in Windows  You can configure a Bluetooth connection as below, however make sure the Blue- tooth module is on (or the system is not in Airplane Mode) before configuration. Bluetooth Headset Stereo Setup Desktop Mode To setup a Bluetooth Switch to the Windows Desktop (click the App or use the Windows logo key headset to support ste-...
  • Page 170 Modules & Options Make sure that Bluetooth is turned on and a list of discovered devices will appear. Double-click the device you want to pair with the computer and click Pair. Figure 7 - 16 PC and Devices - Bluetooth On first connection the computer will provide you with a pairing code to be entered onto the device.
  • Page 171 Modules & Options To Make your Computer Discoverable to Bluetooth Devices Switch to the Windows Desktop (click the app or use the Windows logo key D key combination). Click the notification area of the taskbar, click the Bluetooth icon and click Open Settings.

  • Page 172: Trusted Platform Module

    Modules & Options Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.

  • Page 173: Enabling & Activating Tpm

    Modules & Options Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu Select TPM Configuration and press Enter. Select Security Device Support and press Enter, select Enable and press Enter. Select TPM State, press Enter and select Enabled to change the TPM state to enabled.
  • Page 174 Modules & Options Select Pending operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership) and press Enter. You will then need to press F4 to save the changes and restart the computer. Figure 7 - 20 Pending Operation (Enable Take...

  • Page 175: Trusted Platform Module (Tpm) Driver Installation

    Modules & Options Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver. 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.

  • Page 176: Initializing Tpm

    Modules & Options Initializing TPM Switch to the Desktop app and click the TPM icon right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble). Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
  • Page 177 Modules & Options Choose the Security Platform Features you want to use by clicking the  appropriate check box. Enter a Basic User Password (and re-type to confirm it) and click Next. Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use the Security Platform Fea-...

  • Page 178: Infineon Security Platform Settings Tool

    Modules & Options Infineon Security Platform Settings Tool  The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
  • Page 179 Modules & Options User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
  • Page 180 Modules & Options Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion.
  • Page 181 Modules & Options Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 26 Infineon Security Platform Settings Tool (Migration) Trusted Platform Module 7 - 35...
  • Page 182 Modules & Options Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 27 Infineon Security Platform Settings Tool (Password Reset) 7 - 36 Trusted Platform Module...
  • Page 183 Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
  • Page 184 Modules & Options Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 29 BitLocker Drive Encryption 7 - 38 Trusted Platform Module...
  • Page 185 Modules & Options Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 30 Infineon Security Platform Settings Tool (Advanced) Trusted Platform Module 7 - 39...

  • Page 186: Intel Rapid Storage Technology

    Modules & Options Intel Rapid Storage Technology Install the Intel Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - 11). IRST Driver Installation 1.

  • Page 187: Intel® Vpro™ Technology

    Modules & Options Intel® vPro™ Technology Intel® vPro™ Technology is supported by Model B computers only. This set of technology features, built into the computer’s motherboard, allows Information Technology departments remote access to the computer. This allows the IT depart- ment to monitor, maintain and manage computers regardless of the state of the op- erating system or the computer’s power state.
  • Page 188 Modules & Options Figure 7 - 31 Intel(R) Management Engine (Password Creation) Select MEBx Login and press “Enter” to access the password screen. Enter the pass- word “admin” (without quotes) and you will then be prompted to enter your own password (note the password information on the previous page).

  • Page 189: Intel® Management And Security Status

    Modules & Options ® Intel Management and Security Status (Model B Only) Access the Intel Management and Security Status control panels from app from ® the Apps screen. These features allow users and IT Administrators to enhance and protect computing assets. Your system administrator will need to assist you in man- aging some of the information here.
  • Page 190 Modules & Options General The General tab provides basic information on the status of management and secu- rity technologies provided by the Intel Management Engine. ® Figure 7 - 33 ® Intel Management & Security Status General 7 - 44 Intel® Management and Security Status...
  • Page 191 Modules & Options Intel® Small Business Technology The Intel® SBT tab will be shown if you system is configured to support it. This al- lows your network’s IT professionals to keep PCs up-to-date and protected. Figure 7 - 34 ® Intel Management &...
  • Page 192 Modules & Options Advanced The Advanced tab provides additional information on the system. Figure 7 - 35 Intel® Management & Security Status Advanced For Intel PRO Wireless 2200BG 7 - 46 Intel® Management and Security Status...

  • Page 193: Intel® Rapid Start Technology Driver

    Modules & Options Intel Rapid Start Technology Driver ® Intel(R) Rapid Start Technology can resume power from Hibernation within 5 to 6 seconds and can remember your computer's previous state with zero power. System Requirements to support Intel® Rapid Start Technology: •...

  • Page 194: Intel® Rapid Start Technology Configuration

    Modules & Options Intel® Rapid Start Technology Configuration Enable/disable Intel(R) Rapid Start Technology from the BIOS (see “Intel(R) Rapid Start Technology (Advanced Menu)” on page 5 - 10). Go the Windows control panel and double-click Administrative Tools (System and Security)> Computer Management > Storage > Disk Management Right-click the SSD and select Shrink Volume from the menu.
  • Page 195 Modules & Options Enter the figure, which should be equal to amount of system memory (RAM) in your computer, in “Enter the amount of space to shrink in MB”. Figure 7 - 37 Shrink Volume Size Click Shrink (any unallocated file space may be formatted for storage use). ...
  • Page 196 Modules & Options Run the Desktop app and right-click the lower left hot corner (or use the Windows Logo Key + X key combination) and select Command Prompt (Admin). Figure 7 - 38 Search for CMD Prompt Type “DISKPART”. At the DISKPART command type “list disk”. Figure 7 - 39 Diskpart - List Disk 7 - 50 Intel®...
  • Page 197 Modules & Options Type “select disk #” (# is disk number where you want to create the store partition, so refer to the results obtained from "list disk" for exact disk number). 10. The message “Disk # is now the selected disk.” will appear. Figure 7 - 40 Diskpart - Select Disk #...
  • Page 198 Modules & Options 13. Type “detail disk”. Figure 7 - 42 Diskpart - Detail Disk 14. Type “select Volume #” (# is volume of your storage partition so refer to results obtained from "detail disk" for the exact volume number). 15.
  • Page 199 Modules & Options 16. Type the following, depending on the format of the SSD. • For MBR formatted SSDs: “set id=84 override” (the id must be set to 84). • For GPT formatted SSDs: “set id=D3BFE2DE-3DAF-11DF-BA40-E3A556D89593”. Figure 7 - 44 Diskpart - Set id= 17.

  • Page 200: Intel® Rapid Start Technology Driver Installation

    Modules & Options 19. Go the Windows control panel and double-click Administrative Tools (System and Security)> Computer Management > Storage > Disk Management. 20. The disk partition should read Healthy Hibernation Partition. Figure 7 - 45 Computer Management (Healthy Hibernation Healthy (Hibernation Partition) Partition) 21.

  • Page 201: Intel® Smart Connect Technology

    Modules & Options Intel® Smart Connect Technology  Intel® Smart Connect Technology periodically, and briefly, wakes the computer Intel® Smart Connect from Sleep mode in order to update information for certain applications (e.g. to get Technology System mail from Microsoft Outlook) as required. These updates can therefore be made Requirements without having to turn the computer on, and applications will be up to date when the Note that in order to sup-...

  • Page 202: Intel® Smart Connect Technology Configuration

    Modules & Options Intel® Smart Connect Technology Configuration  Access the Intel(R) Smart Connect Technology application from the Apps menu. Click the button to turn Keep Data Fresh ON. Wireless Device You can select to have the system update open application data every 15, 30 or Operation Aboard Aircraft 60 minutes.
  • Page 203 Modules & Options Click Customize Schedule to customize the update frequency, and the hours and  days when the updates will occur. Bear in mind that the more often you set the system to update, the more power is iSCT & System consumed, and this may be a consideration if the system is battery powered.
  • Page 204 Modules & Options Click the Help icon and select Help to access the menu.  Intel WLAN Modules If your purchase option includes an Intel WLAN module, (with Intel’s PROSet Wireless Con- nection Utility stalled), Intel® Smart Connect Technology will search for WiFi net- works around you that you have previously ac- cessed.
  • Page 205 Modules & Options Remote Wake Remote Wake allows you to wake the computer remotely from another device such as a phone, tablet or another PC. This will allow you to access files on the computer. A link to a list of applications and usage is supplied if you click Learn More and the link provided.

  • Page 206: Intel® Small Business Advantage

    Modules & Options Intel® Small Business Advantage  Intel® Small Business Advantage (Intel® SBA) is a hardware and software solu- Password Settings tion specifically designed for small businesses without a managed network or spe- cialist IT professionals. Intel® SBA includes six applications which help manage Make sure you input a security and productivity.

  • Page 207: Sba Application Modules

    Modules & Options SBA Application Modules PC Health Center This module allows you schedule automatic maintenance and hard disk defrag- mentation, and to delete Temporary internet files and cookies. You can Schedule these tasks to run at times most convenient for you e.g. in the middle of the night when the computer is off.
  • Page 208 Modules & Options Software Monitor The Software Monitor detects programs running on your system designed to protect your computer (e.g. Windows Defender, Microsoft Security Essentials etc.). Should any malicious software code try to attack any of this important soft- ware, the Software Monitor will pop up a warning. Figure 7 - 50 Software Monitor 7 - 62 Intel®...
  • Page 209 Modules & Options USB Blocker USB Blocker allows you to turn off types of mass storage (printers will still function) in order to prevent data theft. You can choose to allow specific devices (e,.g. your own flash drive) and prevent others from being used, or require a pass- word for use.
  • Page 210 Modules & Options Data Backup and Restore Data Backup and Restore will allow you to automatically backup your data at regular intervals without having to interrupt your work to do so. The App will use the Windows Backup Utility for a complete backup, and will take you through the process to do so.
  • Page 211 Modules & Options Energy Saver Energy Saver will help to shut down the computer, and start it up, at scheduled intervals. This feature can be useful if you are in the habit of leaving the comput- er on while away from work/home and letting it enter a power-saving state on its own.
  • Page 212 Modules & Options Help  For Help on Intel® SBA click the Help menu at the top right of the screen, and click on any topic heading to get more information . Intel® Smart Connect Technology You can also launch In- tel®...

  • Page 213: 3G/4G Module

    Modules & Options 3G/4G Module  If you have included an optional UMTS/HSPA+ based 3G Module (Universal Mo- Wireless Device bile Telecommunications System or High Speed Packet Access) module or LTE Operation Aboard (Long Term Evolution) 4G module (see “Communication (All Models)” on page D Aircraft for specification details) in your purchase option, you do not require a driver/ The use of any portable...
  • Page 214 Modules & Options 3G/4G Module USIM Card Installation  Follow the instructions below to install the USIM card (which will be provided by Power Safety your service provider). Warning Turn the computer off, and turn it over. Before you undertake any Slide the latch in the direction of the arrow.

  • Page 215: 3G/4G Configuration In Windows

    Modules & Options 3G/4G Configuration in Windows You can configure a 3G/4G connection as below, however make sure the system is not in Airplane Mode before configuration begins. Charms Bar Go to the Charms Bar. Select Settings and then click the WiFi icon (it should read Available under the icon and Airplane mode should be Off).
  • Page 216 Modules & Options Any 3G/4G service provider (connection information is usually stored on the USIM card) will appear under Mobile Broadband. Double-click any connection icon under Mobile Broadband (or click and then click Connect). Figure 7 - 57 Mobile Broadband (Connect) The system will connect to your network.
  • Page 217 Modules & Options You can then access the internet, download e-mail etc. as per any internet  connection. To disconnect you can select the connection and click Disconnect Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited.

  • Page 218: Em820W 3G Module Pin Code & Power-Saving

    Modules & Options EM820W 3G Module PIN Code & Power-Saving Note that there may be some issues when a PIN Code is set for the EM820W 3G module (if you are unsure of your module version contact your distributor/supplier) in Windows, if Mobile Broadband has been turned off, and the system has resumed from a power-saving state.
  • Page 219 Modules & Options Click Network. Click the broadband connection under Mobile Broadband. Scroll down to Security and click Remove PIN. Enter the current PIN number and click OK. It is recommended that you do not Enable a PIN for the EM820W 3G module. Figure 7 - 60 Disable PIN EM820W 3G Module PIN Code &...

  • Page 220: Wireless Display

    Modules & Options Wireless Display  Wireless Display uses your Wireless LAN module/WLAN Bluetooth Combo mod- Compatible (you need to make sure that your video adapter/display device is compatible with Adapters your particular WLAN/Combo module) in conjunction with a compatible video adapter/display device (purchased separately) to allow you to display the contents of For a list of compatible the notebook display on another display (e.g.

  • Page 221: Wireless Display Configuration

    Modules & Options Wireless Display Configuration Note that no driver or application is required for wireless display in Windows 8.1. Go the Charms Bar, select Devices. Click Project. Click Add a wireless display. Figure 7 - 61 Add a Wireless Display Wireless Display 7 - 75...
  • Page 222 Modules & Options The system will then search for compatible display devices (this may take up to 60 seconds so allow time for this to complete). Figure 7 - 62 Searching For Devices Double-click any detected display device in the list. You may then need to input a pin number for the device to which you are connecting.
  • Page 223 Modules & Options The display will then connect (for specific settings for your display see the documentation supplied with your compatible adapter/display for full details). 10. To disconnect from the display you can select it in PC and Devices > Devices and click Remove Device >...
  • Page 224 Modules & Options 7 - 78...

  • Page 225: Troubleshooting Overview

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 226: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, “LED Indicators”...

  • Page 227: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 228: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 229: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 230 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 231: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
  • Page 232 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 233 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 234 Troubleshooting Problem Possible Cause - Solution The system freezes or the screen goes The system’s power saving features have timed-out. Use the AC/DC adapter, dark. press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
  • Page 235 Troubleshooting Problem Possible Cause - Solution The Bluetooth module is off after The Bluetooth module’s default state will be off after resuming from the Sleep resuming from Sleep. power-saving state. Use the key combination (Fn + F12) to power on the Bluetooth module after the computer resumes from Sleep.
  • Page 236 Troubleshooting Problem Possible Cause - Solution I have used Update Driver in Device It is very important that the drivers are installed in the order indicated in Chapter Manager (Unknown device > Other 4 (which is the numbered installation order on the Device Drivers & Utilities + Devices) to try and install the Airplane User’s Manual disc).
  • Page 237 Troubleshooting Problem Possible Cause - Solution I have connected a Bluetooth mouse but This is an issue with this mouse type and the Intel Wireless 7260 WLAN and it loses the Bluetooth connection and Bluetooth combo module series. To resolve this issue do the following: no longer responds after a short period of Go to the Device Manager control panel in Windows.
  • Page 238 Troubleshooting Problem Possible Cause - Solution When using a Bluetooth headset the This is a common issue with Bluetooth headsets. To resolve this issue do the audio appears to be mono and not following (you will need to repeat this procedure after every boot up, restart, stereo.

  • Page 239: Em820W 3G Module Pin Code & Power-Saving

    Troubleshooting EM820W 3G Module PIN Code & Power-Saving Note that there may be some issues when a PIN Code is set for the EM820W 3G module (if you are unsure of your module version contact your distributor/supplier) in Windows, if Mobile Broadband has been turned off, and the system has resumed from a power-saving state.
  • Page 240 Troubleshooting Click Network. Click the broadband connection under Mobile Broadband. Scroll down to Security and click Remove PIN. Enter the current PIN number and click OK. It is recommended that you do not Enable a PIN for the EM820W 3G module. Figure 8 - 3 - Disable PIN 8 - 16 EM820W 3G Module PIN Code &...

  • Page 241: Resolving The "Insert A Sim" Issue With The 3G Module (Windows 8.1)

    Troubleshooting Resolving the “Insert a SIM” issue with the 3G Module (Windows 8.1) If a PIN was set for the EM820W 3G module, you have then switched Mobile broadband off (or put the system in Airplane Mode) in Networks, and the system has just resumed from a power-saving state the following error may occur.
  • Page 242 Troubleshooting 8 - 18...

  • Page 243: Interface (Ports & Jacks) Overview

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.  USB Port / Card Reader / ExpressCard Power Note that power to the USB ports, card reader and ExpressCard may be enabled/disabled in the BIOS (see page 10).

  • Page 244: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
  • Page 245 Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot.
  • Page 246 Interface (Ports & Jacks) A - 4...

  • Page 247: Control Center Overview

    Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
  • Page 248 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the Power Conservation Mode, Airplane Mode, Power Plan and PC camera power etc. You can click a Control Center icon to set an overall power mode and then click individual icons in the Control Center to power on/off the Touchpad and PC camera.
  • Page 249 Control Center Control Center Menus The Control Center contains 3 menu headings (System Program, Device and Gaming) under the Power Modes. Click the menu headings and then click any of the buttons outlined on the following pages. Figure B - 2 - Control Center Menus Control Center B - 3...
  • Page 250 Control Center Power Status (System Program) The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness (System Program) The Brightness icon will show the current screen brightness level.
  • Page 251 Control Center Sleep Button (System Program) Click either the Hibernate or Sleep buttons to have the computer enter the selected power-saving mode when the Fn + F4 key combination is pressed (see “Power-Saving States” on page 3 - Display Switch (System Program) Click the Display Switch button to access the menu (or use the + P key combination) and select the appro- priate attached display mode.
  • Page 252 Control Center Left Windows Key (Gaming) Click Disable to disable the Windows Key on the left side of the keyboard. This may be useful if you are using the keyboard for gaming and wish to avoid accidentally triggering menus with the Windows Key. Headphone (Gaming) The headphones may be set for different effects using this menu.

  • Page 253: Video Driver Controls

    Video Driver Controls Appendix C: Video Driver Controls  The basic settings for configuring the LCD are outlined in “Video Features” on Video Card Options page 1 - Note that card types, specifications and driv- Video Driver Installation ers are subject to contin- updates Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 -...

  • Page 254: Intel® Hd Graphics Control Panel

    Video Driver Controls Intel HD Graphics Control Panel ® Advanced video configuration options are provided by the Intel HD Control Pan- ® el. To access the control panel see below and overleaf: Click the Intel® HD Graphics Control Panel icon in the Apps screen. Figure C - 1 Apps Screen Intel ®...
  • Page 255 Video Driver Controls Right-click the Desktop and select Graphics Properties from the menu. Click Advanced settings in the Screen Resolution control panel in Windows. Click the Intel(R) HD Graphics Control Panel tab and click Graphics Properties (button). Double-click the Intel(R) HD Graphics control panel in the Windows Control Panel.
  • Page 256 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate menu panel and adjusting the settings from the menus. Figure C - 3 Intel ® HD Graphics Control Panel C - 4 Intel® HD Graphics Control Panel...
  • Page 257 Video Driver Controls Sub-Menus Some of the menu panels will also have sub-menus (in the top left corner of the menu alongside the icon ) to display further configuration options. Figure C - 4 Intel ® HD Graphics Control Panel Sub-Menus Intel®...
  • Page 258 Video Driver Controls Display  Click either Display Settings or Color to make display adjustments, including con- figuration for any attached external displays. Multiple Display At least one other dis- play must be attached in order to view multiple display selection tions.
  • Page 259 Video Driver Controls Click the Display menu at the top of the screen to display the sub-menus. The Mul-  tiple Displays menu allows you to configure the display mode of any attached dis- plays (see “Attaching Other Displays” on page C - 15).
  • Page 260 Video Driver Controls This menu allows you to choose how 3D images are displayed. Quality displays the most detail, Balanced provides better computer performance with good quality and Custom allows you to configure the Anisotropic Filtering and Vertical Sync fea- tures to your preferences.
  • Page 261 Video Driver Controls Options Options allows you to Customize Hot Keys (for opening the application, rotating the display, scaling etc.,) to your preferences. Click Apply to save changes. Figure C - 8 Intel ® HD Graphics Control Panel Options Intel® HD Graphics Control Panel C - 9...
  • Page 262 Video Driver Controls Click the Options menu at the top of the screen to display the sub-menus. The In-  formation Center provides details on System Information, the Built-In Display and any attached displays. Preferences Go to the Preferences sub-menu in Options to configure the preferenc- es for the Intel®...
  • Page 263 Video Driver Controls Video The Video Profiles menu allows you to brighten or darken movies, or to switch to vivid colors. The Preview image will display a sample image using the current set- tings. You can Save Profile and name the Profile to recall the settings at any time. Click Apply to save changes (select Color Enhancement, Image Enhancement, Image Scaling or Gamut Mapping from the menu).
  • Page 264 Video Driver Controls Click the Video menu at the top of the screen to display the sub-menus.The Image Enhancement menu allows you to adjust the Sharpness, Skin Tone Enhance- ment, Noise Reduction etc.Click Apply to save changes. Figure C - 11 Intel ®...
  • Page 265 Video Driver Controls The Image Scaling and Gamut Mapping menus allow you to adjust these items. Figure C - 12 Intel ® HD Graphics Control Panel Video Image Scaling & Gamut Mapping Intel® HD Graphics Control Panel C - 13...

  • Page 266: Display Devices & Options

    Video Driver Controls Display Devices & Options Note that you can use external displays connected to the HDMI-Out port and/or ex- ternal monitor port. See your display device manual to see which formats are sup- ported.  Attaching Displays When you first attach an external display you may find that the desktop does not occupy the full screen area.

  • Page 267: Attaching Other Displays

    Video Driver Controls Attaching Other Displays  To Clone Displays: Multiple Display Attach your external display to the external monitor port/HDMI-Out port, and turn it on. Go to the Intel(R) HD Graphics Control Panel control panel and click Display > At least one other dis- Multiple Displays (sub-menu).
  • Page 268 Video Driver Controls To Enable Extended Mode:  Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Go to the Intel(R) HD Graphics Control Panel control panel and click Display > Display Settings Multiple Displays (sub-menu). Extended Desktop Click Extended from the Select Multiple Display Mode menu.
  • Page 269 Video Driver Controls To Enable Collage Mode:  Attach your external displays to the external monitor port and HDMI-Out port, and turn them on. Collage Mode Go to the Intel(R) HD Graphics Control Panel control panel and click Display > Multiple Displays (sub-menu).

  • Page 270: Attaching Other Displays - Devices (Charms Bar

    Video Driver Controls Attaching Other Displays - Devices (Charms Bar)  You can configure attached displays from Devices (in the Charms Bar) Windows Logo Key + P Key Attach your external display to the external monitor port/HDMI-Out port, and turn it on. Combination Go the Charms Bar, select Devices.

  • Page 271: Configuring An External Display In Windows

    Video Driver Controls Configuring an External Display In Windows Attach your external display to the external monitor port/HDMI-Out port, and turn it on. Go to the Screen resolution control panel (see page 35) in the Desktop app. Click the Detect button. The computer will then detect any attached displays.
  • Page 272 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 18 Screen Resolution Multiple Display Options • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...

  • Page 273: Hdmi Audio Configuration

    Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Adjustment In some cases it will be necessary to go to the Sound control panel and manually The sound volume level configure the HDMI audio output as per the instructions below. can be set using the vol- ume control in the Set- Go to the Control Panel.
  • Page 274 Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 20 HDMI Device Properties C - 22 HDMI Audio Configuration...
  • Page 275 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party application to play...
  • Page 276 Video Driver Controls C - 24...

  • Page 277: Specifications

    Specifications Appendix D: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your distributor/supplier for details.

  • Page 278: Processors

    Specifications Processors For Model B Only: Display Intel® Core i3-4100M (2.5GHz) For All Models: 15.6” / 39.62cm HD (1366 * 768) / HD+ Mobile Processor (1366 * 768) / FHD (1920 * 1080), 16:9 Intel® Core i7-4600M (2.9GHz) 3M L3 Cache, 22nm (22 Nanometer), Backlit Panel Mobile Processor DDR3L-1600MHz, TDP 37W...

  • Page 279: Storage

    Specifications Storage Card Reader Interface One Changeable 2.5" / 9.5 mm (h) / 7mm Embedded Multi-In-1 Push-Push Card One eSATA Port (h) HDD with SATA (Serial) Interface Reader One HDMI™ Out Port (with HDCP) One External Monitor Port One Changeable 12.7 mm(h) Super Multi - MMC/ RS MMC One Audio Combo Jack (Headphone Out Optical Device Drive with SATA Interface...

  • Page 280: Communication (Model A Only

    Specifications Built-In Intel® 10/100/1000Mb Base-TX 3rd Party WLAN 802.11b/g/n Half Mini- LED Indicators Ethernet LAN Card Module with PCIe Interface Power/Suspend, Battery, HDD/ODD, (Factory Option) 1.0M HD Video Camera Module (Factory Airplane Mode, Num Lock, Caps Lock, Option) Power Management Scroll Lock, Camera (on module) Communication (Model A Only) Operating System...

  • Page 281: Dimensions & Weight

    Specifications Dimensions & Weight 374 mm(w) * 250 mm(d) * 35.5 mm(h) 2.33kg with Battery Specifications D - 5...
  • Page 282 Specifications D - 6...

  • Page 283: Docking Station Guide Overview

    Docking Station Guide Appendix E: Docking Station Guide Overview The docking station provides your computer with an easy connectable desktop environment when portability is not required. This allows for easy connections to external displays, USB devices (with a full range of extra USB ports), audio devices and provides a battery charging facility.

  • Page 284: Computer And Docking Station

    Docking Station Guide Computer and Docking Station The computer may hot or cold dock/undock with the docking station, i.e. the computer may be powered on (hot docking/undocking) or powered off (cold docking/undocking) when docking or undocking. However if you in- tend to hot dock/undock the system then make sure that the hot key driver, provided on the computer’s Device Drivers &...

  • Page 285: System Map: Front View

    Docking Station Guide System Map: Front View Figure E - 1 System Map Front Power Button LED Backup Button (if a Hard Disk is installed in the Device Bay) Lock Switch Notebook Eject Latch Notebook Placeholder Retaining Pins Docking Connector Eject Pins ...

  • Page 286: System Map: Rear View

    Docking Station Guide System Map: Rear View Figure E - 2 System Map Rear Security Lock Slot USB 3.0 Port DVI-D Out Port HDMI-Out Port External Monitor Port RS232 (Serial) COM Port RJ-45 LAN Jack DC-In Jack Headphone Jack 10. Microphone Jack 11.

  • Page 287: Power Button Led & Lock Switch Led Indicator

    Docking Station Guide Power Button LED & Lock Switch LED Indicator Icon Color Description Orange DC Power is Plugged In and the Computer is Off or in Hibernate Mode* Green The Docking Station is On or in Sleep Mode Table E - 1 - Power Button LED & Lock Switch LED Indicator *To confirm the computer’s power status check the LED Power Indicators on the computer itself.

  • Page 288: System Map: Left & Right Views

    Docking Station Guide System Map: Left & Right Views Figure E - 3 System Map Left & Right Views Bay with HDD or Dummy Caddy Bay with Optical Device Drive (DVD) Powered USB 3.0 Port USB 3.0 Ports  USB Port Power Note that power to the notebook computer and docking station’s USB ports may be enabled/ disabled in the notebook computer’s BIOS settings (see the BIOS guide in Chapter 5 of the notebook’s user manual).

  • Page 289: Cold Docking The Computer To The Docking Station

    Docking Station Guide Cold Docking the Computer to the Docking Station Remove all packing materials and place the docking station on a stable surface. Securely attach any peripherals you want to use with the docking station (e.g. keyboard and mouse) to their ports.
  • Page 290 Docking Station Guide Make sure the computer’s hot key driver is installed (especially if you intend to hot dock the system). Remove the AC/DC adapter from the notebook computer and then close the computer’s lid/LCD and turn it over. Slide the notebook computer’s docking port cover latch in the direction of the arrow at point to open the cover (failure to open the cover of the docking port before connecting the computer to the docking station may result in irreparable damage to the connector on the docking station).
  • Page 291 Docking Station Guide Make sure that the notebook computer’s AC/DC adapter is NOT ATTACHED to the computer’s DC-In jack and that the computer is OFF. Ensure that the lock switch on the docking station is in the unlock position. 10. Align the computer with the notebook placeholder and then press the computer down onto the docking station.

  • Page 292: Cold Undocking The Computer From The Docking Station

    Docking Station Guide Cold Undocking the Computer from the Docking Station Shut the computer down as per the normal Windows shutdown (select Shut Down from the Start menu in Windows 7) procedure (the Power LED on the docking station will be orange). Slide the lock switch on the docking station in to the unlock position.

  • Page 293: Hot Docking The Computer To The Docking Station

    Docking Station Guide Hot Docking the Computer to the Docking Station Remove all packing materials and place the docking station on a stable surface. Securely attach any peripherals you want to use with the docking station (e.g. keyboard and mouse) to their ports.
  • Page 294 Docking Station Guide Make sure the computer’s hot key driver is installed for hot docking/undocking the system. The computer should be on, however remove the AC/DC adapter from the notebook computer and then close the computer’s lid/LCD and turn it over (if you are using the optional 9 cell battery you cannot hot dock the computer with the docking station).
  • Page 295 Docking Station Guide Ensure that the lock switch on the docking station is in the unlock position. Press the computer down onto the docking station so that the docking connectors line up (the Power LED on the docking station will be orange). 10.

  • Page 296: Hot Undocking The Computer From The Docking Station

    Docking Station Guide Hot Undocking the Computer from the Docking Station Hot undocking using Windows: When the system is docked click the icon in the taskbar notification area and click Safely Remove Hard- ware and Eject Media (Figure E - 11) from the menu.
  • Page 297 Docking Station Guide Hot undocking using the Control Center: Make sure the computer’s hot key driver is installed for hot docking/undocking the system. Press the Fn + Esc key combination to run the Control Center. Click the Docking Enable button in the Control Center (the icon displays the current docking status).
  • Page 298 Docking Station Guide Press the Fn + Esc key combination to run the Control Center. The docking power LED will be Orange at this point and the ports, buttons and attached devices on the docking station will not work. If you do not wish to separate the notebook and docking station at this point you can click the docking icon in the Control Center to re-dock the system.

  • Page 299: Power Button Configuration

    Docking Station Guide Power Button Configuration To prevent your computer from entering a power-saving state if you choose to work with the lid/LCD closed, then it may be necessary to redefine what the computer is set to do if the lid/LCD is closed when plugged in. Go to the click Power Options (Hardware and Sound) control panel.

  • Page 300: Docking Station Ports & Jacks

    Docking Station Guide Docking Station Ports & Jacks The following will give a quick description of the interface (ports & jacks) which allow your docking station and computer to communicate with external devices, connect to the internet etc. When the notebook is docked to the docking station all the ports on the docking station will function, however only some of the ports on the notebook will function (see the note alongside each item for specific information.
  • Page 301 Docking Station Guide Item Description Note External Monitor (VGA) This port allows you to connect an external monitor, or Flat Panel Use only the external monitor Port Display, to get dual video or simultaneous display on the LCD port on the docking station and external monitor/FPD.
  • Page 302 Docking Station Guide Item Description Note Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD-capable PC to a Dolby AC-3 compatible receiver for “5.1”...

  • Page 303: Bios Controls - Usb Ports, Card Reader & Expresscard

    Docking Station Guide Multiple Displays Any two of the following displays may be enabled simultaneously when the system is docked. You can toggle through the display options by using the Fn + F7 key combination (make sure any attached displays are powered on).

  • Page 304: One Button Hard Disk Backup

    Docking Station Guide One Button Hard Disk Backup When the system is docked you can press the Hard Disk Backup Button ( Figure E - 14) to launch Win- dows 8’s Recovery application. If you do not have a hard disk installed in the docking station you can set the application to backup files or a system image to any attached hard disk, CD/DVD or non system partition of your computer.

  • Page 305: Backup Procedure

    Docking Station Guide Backup Procedure You can choose to backup individual files and folders or alternatively create a System Image Backup. Press the hard disk backup button. Windows Recovery application will be launched. Click File History. If you are on the first run of the program click Turn On. Figure E - 15 - Windows 8 File History (Turn On) Backup Procedure E - 23...
  • Page 306 Docking Station Guide You can click Select drive (see Figure E - 15 on page E - 23) and select the drive (e.g the drive installed on the docking station) to backup the system image, or libraries, desktop, contacts and favorites (see below) to (you can also choose to backup to a network location).

  • Page 307: System Image Backup

    Docking Station Guide System Image Backup Follow the instructions on these pages to perform a a full system image backup (if you want to backup individual files and folders see Figure on page E - Click System Image Backup from the File History control panel (see Figure E - 15 on page E - Select where you would like to save the backup (e.g the drive installed on the docking station) and click Next.
  • Page 308 Docking Station Guide Click Start backup to begin the backup procedure (for a large amount of data this could take some time). Windows will then begin the backup procedure. You system backup will now be stored on the selected location and you can use it as part of the recovery process if required.

  • Page 309: System Image Recovery

    Docking Station Guide System Image Recovery You can recover your backed up system image by using Update and recovery application in PC Settings. Go to the Charms Bar. Select Settings and then click Change PC Settings. Click Update and Recovery, and then click Recovery. Click Restart now under Advanced startup and the computer will restart to begin the recovery process.
  • Page 310 Docking Station Guide Click Troubleshoot.and then click Advanced Options. Click System Image Recovery. Figure E - 20 - Troubleshoot / advanced Options The system will the prepare to recover the system image. You will be asked to select your account by clicking on the account name. Input the system password when prompted and click Continue.

  • Page 311: File History Backup

    Docking Station Guide File History Backup You can click Select drive to select a drive to backup the libraries, desktop, contacts and favorites (see below) to by clicking select drive (you can also choose to backup to a network location). ...
  • Page 312 Docking Station Guide Click Exclude folders and then click Add to select any folders you do not want to back up as part of the process, then click Save changes to confirm. Figure E - 22 - Exclude Folders E - 30 Backup Procedure...
  • Page 313 Docking Station Guide Click Advanced settings: • Save copies of files: Set the interval of the backup (in Windows 8 the default is a continuous backup that takes a snapshot of the files every hour). • Size of offline cache: Set the amount of disk space to be reserved for the backup files. •...
  • Page 314 Docking Station Guide Click Run now to begin the backup process (you can click Stop at any time if you need to cancel the backup process). Figure E - 24 - Run Now E - 32 Backup Procedure...

  • Page 315: Restoring Files From File History Backup

    Docking Station Guide Restoring Files from File History Backup Press the hard disk backup button. Windows 8’s File History application will be launched. Click “Restore personal files”. Figure E - 25 - Restore Personal Files Backup Procedure E - 33...
  • Page 316 Docking Station Guide The most recent backup will appear in the Home - File History window (you can click the arrows to scroll through the different backup date files if they are retained). Click the button to restore the whole backup to the original location. Figure E - 26 - Home File History E - 34 Backup Procedure...
  • Page 317 Docking Station Guide If the files are being restored to their original location then you will be asked if you want to replace files, skip files or decide for each file. You can decide which file to keep, or select both to add a file with a number added as a suffix. Figure E - 27 - Replace or Skip Files/File Conflicts Backup Procedure E - 35...
  • Page 318 Docking Station Guide You can also browse the individual backed up folders to select files. Right-click an individual file and select Restore to, to select a location of your choice to restore the file. Figure E - 28 - Right-Click File Menu E - 36 Backup Procedure...

  • Page 319: Specifications

    Docking Station Guide Specifications Power Full Range AC/DC 90W Adapter Storage AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 4.74A One Changeable 12.7mm(H) Super Multi ODD / Blu-ray Combo Security ODD or 2.5" / 9.5 mm(H) HDD Caddy with SATA (Serial) Interface (Factory Option) Security (Kensington®...
  • Page 320 Docking Station Guide E - 38...

  • Page 321: Windows 10 Overview

    Windows 10 Appendix F: Windows 10 Overview This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows 10 OS. You can refer to the main manual for details of audio & video information, BIOS, modules etc. However drivers information specific to Windows 10 will be included in this Appendix, as well as details on how to navigate the Windows 10 user interface to access the applications, control panels, taskbar etc.

  • Page 322: Windows 10 Start Menu

    Windows 10 Windows 10 Start Menu Most of the apps, control panels, utilities and programs within Windows 10 can be accessed from the Start Menu by clicking the icon in the taskbar in the lower left corner of the screen (or by pressing the Windows Logo Key on the keyboard).

  • Page 323: Right-Clicking The Windows Logo In Start Menu

    Windows 10 Right-Clicking the Windows Logo In Start Menu Right-click the Start Menu icon (or use the Windows Logo Key + X key combination) to bring up an advanced Context Menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc.

  • Page 324: Start Menu Apps & Tiles

    Windows 10 Start Menu Apps & Tiles The Windows 10 Start Menu will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on the screen so may need click and drag the handles at the edge of the screen to expand the menu in order to view all the apps (you can use the scroll bar to move up and down the screen).

  • Page 325: Pining/Unpinning Apps & Programs To/From The Start Menu

    Windows 10 Pining/Unpinning Apps & Programs to/from the Start Menu To make things easy to find you can add and remove tiles for apps and programs to the Start Menu. Right-Click on a program’s icon and select Pin to Start from the drop-down menu. To remove an app or program from the Start Menu right-click the icon and select Unpin from Start.

  • Page 326: Windows 10 Control Panel

    Windows 10 Windows 10 Control Panel In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel can be accessed in a number of ways in Windows 10. • Right-click the Start Menu icon in the taskbar in the lower left corner of the screen and select Control Panel from the menu.

  • Page 327: Settings

    Windows 10 Settings The Settings item in the Start Menu (and also as an App) gives you quick access to a number of system settings control panels allowing you to adjust settings for System, Devices, Network & internet, Personalization, Ac- counts, Time &...

  • Page 328: Windows 10 Taskbar

    Windows 10 Windows 10 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar. The notification area of the taskbar in the bottom right of the screen. Some of the Control Panels and appli- cations referred to throughout the course of this manual can be accessed from here.

  • Page 329: Video Features

    Windows 10 Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearance and Personalization). Click Adjust resolution to make changes to the appearance of the display and to detect and configure any attached displays. In Windows 10 it is possible to quickly configure external displays from the Project menu ( press the Windows logo key on your keyboard and the P key).
  • Page 330 Windows 10 To access Display (Control Panel) and Screen Resolution in Windows: Go to the Control Panel. Click Display (icon) - In the Appearance and Personalization category. Make and changes required from the Display, Resolution, Orientation or Multiple display menus. Click Apply to save the settings.
  • Page 331 Windows 10 Display Settings: You can quickly adjust the display by right-clicking the desktop and selecting Display Settings Adjust the settings using the sliders in the menu or click Advanced display settings to change resolution. Click Apply to save any changes made to resolution. Figure F - 10 - Display Settings Video Features F - 11...

  • Page 332: Power Options

    Windows 10 Power Options Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power button item in Start Menu (or the context menu) may be used to Shut down or Restart (you can also add Hibernate/Sleep to the menu - see page 13).
  • Page 333 Windows 10 You can also use the context menu (right-click the Start Menu icon or press the Windows logo + X key combination) to Sign out, Sleep, Hibernate, Shut down, and Restart.  Adding Hibernate/Sleep to the Power Men Go to the Power Options (Hardware and Sound) control panel.

  • Page 334: Minimum Screen Resolution Settings

    Windows 10 Minimum Screen Resolution Settings Windows 10 has minimum screen resolution requirements. Right-click a blank area of the Desktop and select Screen Resolution (or go to the Display control panel). Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above. Figure F - 13 - Screen Resolution F - 14 Power Options...

  • Page 335: Windows 10 Drivers & Utilities

    Windows 10 Windows 10 Drivers & Utilities Make sure you install all the drivers and utilities for your Windows 10 system as outlined in the following pages. Driver Installation (Windows 10) Insert the Device Drivers & Utilities + User’s Manual disc into the computer’s DVD drive, or an attached DVD drive if applicable.
  • Page 336 Windows 10 Windows 10 (64-bit) Drivers Chipset Page F - 17 Wireless LAN Module Page F - 19 Video (VGA) Page F - 17 Fingerprint Reader Module Page F - 21 Page F - 17 Bluetooth & WLAN Combo Module Page F - 23 CardReader Page F - 17...

  • Page 337: Driver Installation Procedure

    Windows 10 Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual 1. Click 3.Install LAN Driver > Yes. disc and click Install Drivers (button). 2. Click Install Drivers and Software > Next. 3. Click the button to accept the license and click Chipset Next.

  • Page 338: Airplane

    Windows 10 Airplane Audio Note: Do not use Update Driver in Device Manager to 1. Click 9.Install Audio Driver > Yes. install the Airplane Mode driver. 2. Click Next. 3. Click Finish to restart the computer. 1. Click 6.Install Airplane Driver > Yes. 2.

  • Page 339: Wireless Lan Module

    Windows 10 Wireless LAN Module If you have included an Intel® or 3rd Party WLAN module in your purchase option make sure that the module is on (i.e. the system is not in Airplane Mode) before installing the driver. Make sure you install the drivers in the order indicated in Table F - 1, on page F - Note that you need to install both the WLAN &...

  • Page 340: 3Rd Party Wlan Driver Installation

    Windows 10 3rd Party WLAN Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install WLAN Driver > Yes. 4.

  • Page 341: Fingerprint Reader Module

    Windows 10 Fingerprint Reader Module The fingerprint reader module provides a high level of security for your computer. Make sure you have admin- istrator’s rights to your computer, and have a Windows password enabled for full security protection. The fingerprint reader module uses the Sign-in options configuration of the Windows Account. ...

  • Page 342: Fingerprint Module Configuration

    Windows 10 Fingerprint Module Configuration Click the Settings item in the Start Menu and then click Accounts and click Sign-in options. You will need to add a Windows password (click Add under Password). After you have added the password you will need to also add a PIN. Under Windows Hello click Set up under Fingerprint.

  • Page 343: Bluetooth & Wlan Combo Module

    Windows 10 Bluetooth & WLAN Combo Module If your purchase option includes the Combination Wireless LAN & Bluetooth module (either Intel® or 3rd Party) then install the driver as instructed overleaf (two drivers are provided for the 3rd party WLAN module and one for the Intel WLAN module).

  • Page 344: 3Rd Party Bluetooth Combo Driver Installation

    Windows 10 3rd Party Bluetooth Combo Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2. Click Option Drivers (button). 3. Click 3.Install Combo BT Driver > Yes. 4.
  • Page 345 Windows 10 Bluetooth Configuration Click the Settings item in the Start Menu and then click Devices. Click Bluetooth and make sure Bluetooth is On and a list of discovered devices will appear. Double-click the device you want to pair with the computer and click Pair. On first connection the computer will provide you with a pairing code to be entered onto the device.

  • Page 346: F - 26 Intel® Rapid Storage Technology

    Windows 10 Intel Rapid Storage Technology ® Install the Intel® Rapid Storage Technology to support your AHCI mode SATA drive. IRST Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2. Click Option Drivers (button). 3.

  • Page 347: Pc Camera

    Windows 10 PC Camera Use the Fn + F10 key combination or Control Center button to toggle power to the PC Camera module. When the PC Camera is in use the LED indicator to the left of the camera will be illuminated in red. Note that you need to use the Camera app in Windows to take pictures and capture video.

  • Page 348: F - 28 Trusted Platform Module

    Windows 10 Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentica- tion. This type of security is usually administered within large enterprises and organizations, and therefore re- quires implementation by a system administrator before users can access security features. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full se- curity protection.

  • Page 349: 4G Module

    Windows 10 3G/4G Module If you have included an optional UMTS/HSPA+ based 3G Module (Universal Mobile Telecommunications System or High Speed Packet Access) module or LTE (Long Term Evolution) 4G module (see “Communica- tion (All Models)” on page D - 3 for specification details) in your purchase option, you do not require a driver/ application installation for Windows 10.

  • Page 350: 3G/4G Configuration In Windows 10

    Windows 10 3G/4G Configuration in Windows 10 You can configure a 3G/4G connection as below, however make sure the system is not in Airplane Mode before configuration begins. Click the Settings item in the Start Menu and then click Network and Internet. Click Cellular a list of available access points will appear.

Table of Contents
