User's Manual
You are reading the User's Manual provides information
regarding the various componets in the notebook PC
and how to use them. After you read through this
manual, please keep it well for you can refer it anytime in
the future.
Please read the safety precautions mentioned
on Page 3 before you operate the notebook.
How to Use This Manual................................................ 1
Safety Precautions......................................................... 3
■How To Use Your Notebook
Where to Place Your Notebook......................................7
Power System................................................................9
■Before Operating Your Notebook
Introducing Your Notebook...........................................10
Using Touchpad...........................................................17
Using Keyboard............................................................18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-Book 4000 U G1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAXDATA M-Book 4000 U G1

  • Page 1: Table Of Contents

    How to Use This Manual..........1 User’s Manual Safety Precautions............3 ■How To Use Your Notebook Where to Place Your Notebook........7 Power System..............9 You are reading the User’s Manual provides information regarding the various componets in the notebook PC and how to use them. After you read through this manual, please keep it well for you can refer it anytime in ■Before Operating Your Notebook the future.
  • Page 2: How To Use This Manual

    How to Use This Manual About the Symbols You will come across the following symbols in this manual. Warning Points out possible damage to property, personal injury or death To help you note and avoid possible damage to your notebook’s hardware or software, Attention or loss of your work Helpful points and tricks for operating your notebook...
  • Page 3 How To Use This Manual Rule of Presenting Operation Behavior in This Manual Corresponding Chart of Key Inscription and Keyboard The descriptions of each key on the keyboard are showed as follows. The Operation of Pushing the Plural Keys Simultaneously Actual key Actual ke in this Manual...
  • Page 4: Safety Precautions

    Safety Precautions The following safety precautions will increase the life of the notebook. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners, benzene, or other chemicals on or near the surface of your notebook.
  • Page 5 Safety Precautions Attention (The device and AC adapter) Please be sure not to pull out the Unplug this notebook from the wall ● ● power plug from the cord only. You outlet when you stop using this have to pull out the power plug from notebook.
  • Page 6 Warning (Battery Pack) Danger of explosion may occur if battery DO NOT dispose batteries in a fire. ● ● is incorrectly replaced. Replace only with They may explode. Check with local the same or equivalent type battery authorities for disposal instructions. recommended by the manufacturer.
  • Page 7 Safety Precautions Attention (Battery Pack) If liquid solution from the battery comes Do not connect the positive (+) and ● ● out and contacts with skin or clothes, negative (-) terminals with a metal object flush out with clean water. such as wire.
  • Page 8: Where To Place Your Notebook

    Set Up Your Notebook Where to Place Your Notebook Make sure that your notebook is placed in a well-ventilated area. Please reserve at least 15cm distance around the notebook. Please reserve suitable space in front of keyboard and touchpad for operating the notebook comfortably. Avoid placing the notebook on a bed, sofa, rug, or similar surface to prevent from blocking ventilations.
  • Page 9 Where to Place Your Notebook Adjusting the Angle of The Display Panel Correct Posture for Operating Your Notebook You can adjust the display to a easy to see angle. Please sit down before the notebook with correct posture. Sit up straight in front of the notebook Adjust the display to a easy to see angle...
  • Page 10: Power System

    Set Up Your Notebook Power System Connect the DC plug to DC-IN Jack DC-IN Jack Connect the AC power cord to the AC adapter Connect the AC power cord to an AC outlet...
  • Page 11: Introducing Your Notebook

    Before Operating Your Nptebook Introducing Your Notebook Open/Close the Notebook Open the panel cover and adjust it to a easy to Close the panel cover and make sure the notebook is see angle. closed well. Front Side 1 Web Camera 2 Display Panel Power Button Keyboard...
  • Page 12 Reset Stereo Speaker Stereo Speaker 1 Web Camera Internal Microphone The built-in camera allows picture taking or video It can be used for video conferencing, voice narration recording , audio recording, and multimedia applications. Page 21 ( ) Touchpad 2 Display Panel This is the pointing device of the notebook.
  • Page 13: Right Side

    Right Side 1 DC-IN Jack ( ) LAN Port HDMI Port USB Port ( ) Microphone Jack & Headphone Output Jack 1 DC-IN Jack ( HDMI Port ) To connect the AC adapter Page 16 ( ) To input Audio or A/V signal synchronously to TV set with HDMI interface.
  • Page 14: Left Side

    Introducing Your Notebook Left Side 1 Display Output Port ( ) Card reader USB Port ( 1 Display Output Port( Card reader ) To connect an external monitor The following cards listed belown can be used on this notebook. ・Memory Stick ・Memory Stick Pro ・SD USB Port (...
  • Page 15 Introducing Your Notebook About Status LEDs Power LED Battery LED Caps Lock LED Num LK LED HDD LED Wireless LAN LED Num LK LED Power LED This LED light when you press Num LK key on The LED lights when the notebook is turned ON and keyboard.
  • Page 16: Connecting Ac Adapter And Charging Battery

    Before Operating Your Notebook Connecting AC Adapter and Charging Battery For the First Time Using Connect the AC power cord to the AC adapter and connect the AC power cord to an AC outlet. The battery included in the package is not fully charged.
  • Page 17 Connecting AC Adapter and Charging Battery Power and Battery Status LEDs Battery LED (  ) Power LED (  ) (  ) Power LED Status Content Blue ON The notebook is powered on Blue Blinking The notebook is in suspend mode Orange Blinking Battery charge is between 15% ~ 3% Red Blinking Battery charge is less than 3%...
  • Page 18: Using Touchpad

    Using Touchpad Introducing the Touchpad Left Button The left button has the same function as mouse left button. Making selections, dragging objects, or double clicking. Touchpad Move the pointer over the icon you wish to execute, press the left button or tap the pad twice in rapid succession, and the system launches the corresponding program.
  • Page 19: Using Keyboard

    Before Operating Your Notebook Using Keyboard Function Keys Windows Logo Key Application Key Windows Logo Key Application Key The Application Key functions as same as Pressing the key in combination with other keys allows the right button on touchpad or mouse. invoking many common functions through the keyboard.
  • Page 20: Bluetooth Function

    Fn Key The following defines the hot keys on the keyboard. The commands can only be accessed by first pressing Web Camera Function and holding the Fn key while pressing a key with a icon. Toggles the Web Camera ON or OFF Power Saving Function Places the notebook in suspend mode (Save-to-RAM).
  • Page 21 Using Keyboard Function of Keys 15.1 15.2 Sending the Commnad to Discontinue or Compiling Text Interrupt the Operation 1 ESC (Escape) 5.2 Insert Equivalent to clicking the Cancel button. Allows text to be inserted. When insert is enabled, the text inserted in a document will not overwrite any other text.
  • Page 22 Combining the Other Key to Execute 10 Shift Function Giving the other keys an alternate meaning. When combined with alphabetic keys, the Shift key causes the system to output a capital letter. The Shift key 13 Ctrl (Control) can also be combined with other keys to produce program-dependent results.
