1 Product Overview
The Voice-over-IP (VoIP) Ceiling Speaker uses a single cable to connect to existing LANs to
broadcast digital audio over your public address system. The small footprint and low height makes
this an ideal speaker to discreetly mount almost anywhere. Prior to installation, do the following:
●
●

1.1 Typical System Installation

Figure 1
system.
PoE VoIP Speakers
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Create a plan for the locations of your loudspeaker amplifiers.
Consult local building and electrical code requirements.
illustrates how the VoIP Ceiling Speakers are normally installed as part of a public address
Figure 1. Public Address System
802.3af PoE compliant Hub
VoIP Phone
930095K
SIP Server
CyberData Corporation
1
