CyberData 10844 Operation Manual page 23

Web Page Item
SIP Server*
Outbound Proxy
Remote SIP Port*
Local SIP Port*
SIP User ID*
Authenticate ID*
Authenticate Password*
SIP Registration*
Unregister on Reboot*
Register Expiration*
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
2. On the SIP Setup page, enter values for the parameters indicated in
3. After changing the parameters, click Save Settings.
Table 2-7. SIP Setup Parameters
Description
Enter the SIP server represented as either a numeric IP
address in dotted decimal notation or the fully qualified
host name (FQHN) up to 64 characters.
Enter the Outbound Proxy as either a numeric IP address
in dotted decimal notation or the fully qualified host name
(FQHN) up to 64 characters.
Enter the Remote SIP Port number (default 5060).
Enter the Local SIP Port number (default 5060).
Enter the SIP User ID (up to 25 alphanumeric characters).
Enter the Authenticate ID (up to 25 alphanumeric
characters).
Enter the Authenticate Password (up to 25 alphanumeric
characters).
Enable/Disable SIP Registration.
• Select Yes to automatically unregister the speaker when
it is rebooted.
• Select No to keep the speaker registered when it is
rebooted.
Enter the SIP Registration lease time in minutes (default 60
minutes).
Click this button to save your configuration settings.
Changing a parameter that has an asterisk next to it will
cause a system reboot when saved.
Link to the Speaker Setup page.
Link to the MGROUPS Setup page.
Link to the Network Setup page.
Link to the Upgrade Firmware page.
Link to the Home page.
930095K
Installing the VoIP Ceiling Speaker
Configure the Speaker Parameters
Table 2-7.
CyberData Corporation
17
