Summary of Contents for Clarke WoodWorker CCS1
- Page 1 185MM CIRCULAR SAW 185MM CIRCULAR SAW MODEL No. CCS1 Part No. 6462015 Part No. 6460200 OPERATING & MAINTENANCE INSTRUCTIONS © 0606...
-
Page 2: Specifications
Thank you for purchasing this CLARKE Circular Saw, which is designed for DIY and light workshop use only. Before attempting to use the machine, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the saw giving you long and satisfactory service. -
Page 3: Safety Precautions
Safety Precautions WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. 1. - Page 4 14. When cutting e.g. doors etc ensure all nails have been removed beforehand. Nails will damage the saw blade. 14. Replacement blades are available from your CLARKE dealer. Note : The guard is operating correctly when it moves freely and readily returns to closed position...
-
Page 5: Electrical Connections
(as indicated by marking or colour code). 4. Replacement fuse covers can be obtained from your local Clarke dealer or most electrical stockists. FUSE RATING The fuse in the plug must be replaced with one of the same rating (13 amps) and this replacement must be ASTA approved to BS1362. -
Page 6: Changing Saw Blade
Changing Saw Blade Note : Item numbers refer to parts list. Ensure saw is switched off and isolated from the mains supply, by removing the plug from the socket. Loosen depth adjusting knob, (see Fig.1) and set to minimum cut depth. Fig. -
Page 7: Operation
Adjustments Ensure the machine is disconnected from the mains supply before attempting to make any adjustment. Depth Of Cut Always keep correct depth setting. The correct depth setting for all cuts should not exceed 6mm below the material being cut. More blade depth will increase the chances of kick- back and result in a rough cut. -
Page 8: Starting A Cut
8. Tool misuse or incorrect operating procedures. 9. Failure to adhere to the correct refitment of the saw blade. 10. Using the wrong saw blade. Starting A Cut The ON/OFF trigger/switch is located on the handle. To start the saw push IN and hold the trigger safety button on the side of handle, (see Fig 1) at the same time depress the trigger switch, and keep it depressed. -
Page 9: Maintenance
Check to ensure the fuse is sound and replace if necessary. If the fuse is sound or blows repeatedly, consult your CLARKE dealer. Accessories A wide range of accessories is available from your nearest CLARKE dealer, for further information, contact your nearest dealer, or telephone CLARKE International Sales department on 01992 565300. -
Page 10: Parts List
Parts List Part No Description Qty No. Part No Description GRCSS1001 Cable GRCSS1037 Spindle GRCSS1002 Cable Protector GRCSS1038 Screw GRCSS1003 Board GRCSS1039 Distance Collar GRCSS1004 Screw GRCSS1040 Screw GRCSS1005 Capacitor GRCSS1041 Rubber Stop GRCSS1006 Switch GRCSS1042 Screw GRCSS1007 Handle GRCSS1043 Spring GRCSS1008 Washer... -
Page 11: Parts Diagram
Parts Diagram...
