Advanced Information
Di470
www.minoltaeurope.com
The essentials of imaging

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Di470 and is the answer not in the manual?

Questions and answers

Related Manuals for Minolta Di470

Summary of Contents for Minolta Di470

  • Page 1 Advanced Information Di470 www.minoltaeurope.com The essentials of imaging...

  • Page 3: Table Of Contents

    A Brief Explanation of the Conventions used in this Manual ..1-5 A Brief Explanation of Important Concepts and Symbols ....1-7 Getting to Know Your Copier System Overview ................. 2-1 Copier Di470 (External) ..............2-1 Copier Di470 (Internal) ..............2-3 Optional Equipment ..............2-4 Original Cover .................2-4 Electronic Document Handler EDH-3 ..........2-5...
  • Page 4 Proper Use of Your Copier ............2-58 Initial Steps . . . Step-by-Step Instructions on Copying Your Documents ..3-1 Entering the Administrator Number..........3-4 Checking Copier Settings............3-5 Entering the Number of Copies........... 3-5 Starting the Copy Cycle ............... 3-6 Di470...
  • Page 5 Selecting a Fixed Zoom Factor............4-9 Selecting a Zoom Factor using the Arrow Keys ......4-10 Specifying a Zoom Factor using the Numeric Keypad ....4-11 Saving Zoom Factors..............4-13 Loading Saved Zoom Factors ............4-15 Specifying an Unproportional Zoom Factor .........4-17 Saving Unproportional Zoom Factors...........4-19 Di470...
  • Page 6 Original: 1-sided, Copy: 2-sided..........5-6 Original: 2-sided (File Margin left), Copy: 1-sided ..... 5-9 Original: 2-sided (File Margin left), Copy: 2-sided ....5-12 Original: 2-sided (File Margin above), Copy: 1-sided ....5-15 Original: 2-sided (File Margin above), Copy: 2-sided ....5-18 Di470...
  • Page 7 If a Message Appears on the Touch Screen......7-3 If Your Copier Is Not Working Correctly ......... 7-4 If a Malfunction Code Appears ..........7-5 Message Indicating a Fault .............7-5 Message Indicating a Malfunction ..........7-5 Di470...
  • Page 8 Cleaning the Automatic Document Feeder ........8-3 Cleaning the Corona Units ............. 8-4 Copier Maintenance ..............8-4 Specifications ................8-5 Copier Di470................... 8-5 Paper Feed Unit PF-208..............8-6 Paper Feed Unit PF-115..............8-7 Duplex Unit PF-7D ................. 8-7 Electronic Document Handler EDH-3..........8-8 Finisher FN-5 ..................
  • Page 9 Paper Feed Unit C-306L ...............8-13 Paper Size Tables ..............8-14 Metric ....................8-14 Inch ....................8-14 Zoom Factor Tables..............8-15 Metric ....................8-15 Inch ....................8-15 CE Marking (Declaration of Conformity)........8-17 Certifications on the Manufacturer's Name Plate ....8-18 Directory of Abbreviations ............8-19 Index.................... 8-20 Di470...
  • Page 10 Di470...

  • Page 11: Introduction

    Introduction Introduction We Want You to Be a Satisfied Customer Thank you for choosing a Minolta Copier System. To ensure the best performance and effective use of your copier, this manual will provide information on the following topics: Getting to Know Your Copier Initial Steps .

  • Page 12: Preserving The Environment

    ISO14001 (environment management). Takeback and Reutilisation Used devices, empty toner and drum units and used toner and drum units are taken back by a local MINOLTA partner and processed for recycling and reutilisation of materials. What is Energy Star®? ®...

  • Page 13: Guide To This Manual

    This chapter shows you how to configure the copier to meet your requirements. It provides information on: • Using the copy job program memory • Checking the meter count • Changing the User's Choice settings • Using administrator mode Di470...
  • Page 14 • How to clear a paper misfeed • How to clear a staple jam Appendix The appendix contains a collection of useful supplementary information such as: • Care of the unit • Specifications • Paper size tables • Zoom factor tables • Index Di470...

  • Page 15: A Brief Explanation Of The Conventions Used In This Manual

    The arrow marks the precautionary measure required to avoid the danger. CAUTION This is a caution! The caution points out a potential and dangerous situation. Neglecting the caution can lead to personal injury and/or machine damage. § The arrow marks the precautionary measure required to avoid the danger. Di470...
  • Page 16 Step 3 of a sequence of actions This bullet indicates a list within a sequence of actions. This is a helpful hint Texts highlighted in this manner contain useful little tips and tricks for improving and simplifying the copy process. Di470...

  • Page 17: A Brief Explanation Of Important Concepts And Symbols

    (copy of the original document) (document to be copied) Copy cycle enlarge, shrink Sort Feeding direction The feeding direction is the path the paper takes through the copier. The feeding direction is shown by the arrows in the following illustration. Di470...
  • Page 18 If side A of the paper format is longer than side B, this is referred to as crosswise. 21 x 29.7 cm 29.7 x 21 cm Lengthwise Crosswise Abbreviations are frequently placed after the paper sizes to indicate lengthwise or crosswise more accurately: Lengthwise: such as A4 L Crosswise: such as A4 C Di470...

  • Page 19: Getting To Know Your Copier

    Getting to Know Your Copier Getting to Know Your Copier System Overview Copier Di470 (External) Item Name Description Copy Tray Receives the created copies (maximum of 100 sheets of plain paper). Copy Tray Extender Pull out the extender when making copies on large-size paper.
  • Page 20 Getting to Know Your Copier Copier Di470 (external) Item Name Description Power Switch Switch the copier on and off with the power switch. Single Feed Tray The single feed tray holds up to 50 sheets of (also referred to as the...

  • Page 21: Copier Di470 (Internal)

    Getting to Know Your Copier Copier Di470 (Internal) Item Name Description Original Glass Place the original face down on the original glass. Original Width Scale Align the originals to the original width and original length scales. Original Length Scale Corona Cleaning Unit When necessary, clean the corona using the corona cleaning unit.

  • Page 22: Optional Equipment

    Getting to Know Your Copier Optional Equipment Original Cover The original cover holds an original placed on the original glass. Item Name Description Original Cover The original cover holds an original placed on the original glass. Original Pad Di470...

  • Page 23: Electronic Document Handler Edh-3

    Document Guide Plate Set the document guides to the original size. Single Feed Tray The single feed tray allows you to process thinner or thicker originals than with the document feeder. However, the originals must be fed one by one. Di470...

  • Page 24: Finisher Fn-105 And Finisher Fn-106

    Damage to the device by improperly estimating the space required The bottom offset tray of a finisher moves downward during copying. Objects below the offset tray may seriously damage it. § Do not place any objects below the offset tray of a finisher. Di470...

  • Page 25: Finisher Fn-503

    Open this cover to clear a paper misfeed. Top Offset Tray Cover for the Stapler Open this panel to clear a staple jam or Unit replenish staples. Recessed Grip Use the recessed grip to pull the finisher away from the copier. Di470...
  • Page 26 Damage to the device by improperly estimating the space required The bottom offset tray of a finisher moves downward during copying. Objects below the tray may seriously damage it. § Do not place any objects below the exit tray of a finisher. Di470...

  • Page 27: Large Desk-Type Cabinet Pf-115

    • The release button indicator flashes: The paper drawer is empty. Copying is stopped because the copy paper was being drawn from this paper drawer. 3rd Drawer This paper drawer holds up to 2.500 sheets of copy paper (80 g/m Di470...

  • Page 28: Duplex Cabinet Pf-7D

    Item Name Description Duplex Unit The duplex unit automatically turns copy paper over to enable double-sided copying. Storage Space Use the storage space for items such as copy paper and other accessories. 2-10 Di470...

  • Page 29: Desk-Type Cabinet Pf-208

    The duplex unit automatically turns copy paper over to enable double-sided copying. 3rd Drawer This paper drawer holds up to 500 sheets of copy paper (80 g/m 4th Drawer This paper drawer holds up to 500 sheets of copy paper (80 g/m Di470 2-11...

  • Page 30: Large Capacity Cassette C-306

    Key for lowering the Press the key to lower the paper plate. Paper Plate Cassette Door Open the cassette door: • to add paper or • to clear a paper misfeed. 2-12 Di470...

  • Page 31: Large Capacity Cassette C-306L

    If you copy material that requires a large amount of system memory, you may want to increase the system memory of the copier, which allows the system to process more data continuously. Printer Controller Pi5500/Pi4700e The printer controller allows the copier to be used as a computer printer. Di470 2-13...

  • Page 32: The Safe Use Of Your Copier

    Never insert paper clips, staples or other small pieces of metal into the openings of the copier. If metal objects are accidentally introduced into the copier in spite of all precautions, switch the copier off immediately. Unplug the power cord. Consult your technical representative. 2-14 Di470...
  • Page 33 Be sure that the power outlet is visible and accessible at all times. § If an extension cable is needed, use one with a capacity that corresponds to or exceeds the power consumption of the copier. § Never connect the copier to a multiple-socket extension cord. Di470 2-15...
  • Page 34 § Never place objects of more than 3 kg on the copier. § Never open any doors while the copier is making copies. § Never turn the copier off while it is making copies. 2-16 Di470...

  • Page 35: Laser Safety

    The laser radiation is completely confined within the machine housing. The laser beam cannot escape the housing at any time of operation. This machine is certified as a Class 1 laser product. This means that the unit does not generate any hazardous laser radiation. Di470 2-17...

  • Page 36: Internal Laser Radiation

    § Operate the copier only in accordance with the instructions provided in this manual. This is a semiconductor laser copier. The maximum radiation capacity of the laser diode is 0.68 mW. The wavelength is 785 nm. 2-18 Di470...

  • Page 37: Noise Emission

    The safety label is located inside the unit at the position marked below. WARNING Danger of burning from the heating unit! The heating unit may reach temperatures of up to 120°C. § Never touch the heating unit. Do not touch areas designated with this symbol : . § Di470 2-19...
  • Page 38 The safety label is located inside the unit at the positions marked below. DANGER Danger! High Voltage! Improper operation of the copier can result in personal injury caused by electric shock. § Operate the copier only in accordance with the instructions provided in this manual. 2-20 Di470...
  • Page 39 CLASS 1 LASER PRODUCT LASER KLASSE 1 PRODUCT DANGER Hazardous laser radiation! Improper operation of the copier can result in release of dangerous radiation. § Operate the copier only in accordance with the instructions provided in this manual. Di470 2-21...

  • Page 40: Data On The Manufacturer's Name Plate

    Getting to Know Your Copier Data on the Manufacturer's Name Plate The manufacturer's name plate for the copier is located on the rear-right side of the unit at the position marked below. Di470 Di470 220-240 50-60 1560-1700 N87/Z132 MINOLTA CO.,LTD...

  • Page 41: Transporting The Copier

    Away from personnel so that no one is subjected to the direct exhaust air of the copier The unit must be protected from the following influences: Splashing liquids Direct sunlight Strong temperature fluctuations Direct airflow from heating or air conditioning units Di470 2-23...

  • Page 42: Space Requirements For The Copier

    In a cool, dry, dust-free location Out of the reach of children WARNING Toner can be hazardous to your health! Toner is harmful if swallowed. § If you get any toner on your hands, immediately wash them thoroughly with soap and cold water. 2-24 Di470...

  • Page 43: Connecting The Copier

    Auto Paper Mode Zoom Factor: × 1.000 Exposure: Auto Exposure Finishing: Non-sort Copy mode: From 1-sided original to 1-sided copy You can change the default settings in the User's Choice. For more information, see page 6-20 and the following pages. Di470 2-25...

  • Page 44: Switching The Copier Off

    The copier is automatically shut off approximately 90 minutes after the last copy activity. The idle time before energy save mode is automatically activated can be changed in the User's Choice settings. For more information, see page 6-30 and the following pages. 2-26 Di470...

  • Page 45: Control Panel Keys And Indicators

    Controls the Touch Screen contrast Only active if a printer controller (option) is installed: Ready Indicator • Indicator lights up: Ready for data transfer. • Indicator flashes: Print data being transferred..continued on next page Di470 2-27...
  • Page 46 On Line Key with Switch from on-line to off-line mode indicator • Indicator lights up: The copier is in on-line mode. Job List Key with Recall Job List indicator • Indicator lights up: Reserve copy job is pending. 2-28 Di470...

  • Page 47: Control Panel Right Side

    Access Confirm an input administration number Energy Saver Manual activation of energy save mode Interruption Key with Interruption of a copy cycle. indicator • Indicator lights up: Copy cycle is interrupted..continued on next page Di470 2-29...
  • Page 48 Stops a copy or scan cycle Start Key with Starts a copy or scan cycle indicator • Indicator lights up green: The copier is ready for operation. • Indicator lights up orange: The copier is not ready for operation. 2-30 Di470...

  • Page 49: Touch Screen

    Display panel Indicator Shows messages and the number of copies. Basics menu Keys Calls up the basic copier settings Current settings Indicator Indicates the current copier settings Supplementary Indicator Indicates the status of a reserve copy display Di470 2-31...

  • Page 50: The Touch Screen

    Touch screen displays may be different! The displays on the touch screen partly depend on the equipment of the copier. The displays shown in this user manual may be slightly different from the displays on your copier. 2-32 Di470...

  • Page 51: Structure Of Touch Screen Menus

    The “Basics” index card is devided into three sections: Paper, Zoom and Finishing. You can switch between the sections using the Basics menu keys. Sections Indicator on the Touch Screen Paper Zoom Finishing You can switch between the four settings screens using the index keys. Di470 2-33...
  • Page 52 Getting to Know Your Copier Settings Screens Indicator on the Touch Screen Basics For additional information, see page 2-33. Original > Copy Density Auxiliary 2-34 Di470...

  • Page 53: Adding Paper

    Press and hold the green keys on the paper size limiters. Set the paper size limiters to another paper size. Position the copy paper between the paper size limiters. The side that is to be printed must be down. Di470 2-35...
  • Page 54 Getting to Know Your Copier Ensure that the maximum paper filling height is not exceeded (see Max. mark on inside of the paper drawer). Close the paper drawer carefully. 2-36 Di470...

  • Page 55: 3Rd Paper Drawer - Pf-115 (Optional Equipment)

    Place another stack of paper into the left half of the paper drawer. The side that is to be printed must be down. Position the long side of the paper stack at the left-hand side of the paper drawer. Di470 2-37...
  • Page 56 The paper drawer is empty. The copy paper is drawn from another paper drawer. The release button indicator is blinking: The paper drawer is empty. Copying is stopped because the copy paper was being drawn from this paper drawer. 2-38 Di470...

  • Page 57: 3Rd And 4Th Paper Drawer - Pf-208 (Optional Equipment)

    The side that is to be printed must be down. Ensure that the maximum paper filling height is not exceeded (see Max. mark on inside of the paper drawer). Close the paper drawer carefully. Di470 2-39...

  • Page 58: Large Capacity Cassette - C-306 And C-306L (Optional Equipment)

    Open the front door of the large capacity cassette. Load the copy paper. The side that is to be printed must be up. Position the copy paper against the rear side of the paper drawer. 2-40 Di470...
  • Page 59 The paper plate of the drawer is raised. Always close the front door properly! If the front door is not properly closed, the paper plate will not be raised. Always make sure that the front door is properly closed. Di470 2-41...

  • Page 60: Single Feed Tray

    Only if you are using a custom paper size: Specify the paper types, the paper width and length. For more information, see page 4-4. Set the guide plates for the copy paper width. 2-42 Di470...
  • Page 61 Getting to Know Your Copier Ensure that the maximum paper filling height is not exceeded (see Max. mark on inside of the paper drawer). Di470 2-43...

  • Page 62: Replacing The Toner Bottle

    Use only the toner bottles suitable for this copier. Original accessories and materials guarantee the best output quality and minimum maintenance. For further information, consult your technical representative. Take hold of the recessed grips in the front door of the copier. Lower the front door outwards and down. 2-44 Di470...
  • Page 63 Be sure the side labelled "UP" on the toner bottle is pointed upwards when doing so. Make sure that the indent in the toner bottle points toward the mark on the toner bottle holder. The toner bottle is correctly installed. Di470 2-45...
  • Page 64 Dispose of the used toner bottle in an environmentally friendly manner. For more information, see page 1-2. Copies still too light? If copies are still too light immediately after replacing the toner bottle, you can activate the toner replenisher function. For more information, see page 6-19. 2-46 Di470...

  • Page 65: Replacing The Staple Cartridge

    The FN-5 finisher has one staple unit. Reach into the recessed grip at the top of the finisher. Pull the finisher carefully from the copier. Open the front door of the finisher. Carefully pull the stapler unit out. Di470 2-47...
  • Page 66 (see the figure on the right). Place the new staple cartridge into the holder. The staple cartridge locks into place with an audible click. Carefully push the stapler unit back in. Close the front door of the finisher. 2-48 Di470...
  • Page 67 Was the copy not stapled correctly? The staple unit is not correctly installed. § Ensure that the staple unit is correctly positioned. § If any staples are jammed, clear them. For more information, see page 7-51. Di470 2-49...

  • Page 68: Finisher Fn-105

    Open the cover at the right of the finisher (FN7). Rotate the green dial to the left to move the staple units to the centre position. Pull the empty staple unit carefully from the holder. Staple unit 2 Staple unit 1 2-50 Di470...
  • Page 69 The staple cartridge locks into place with an audible click. Close the right cover (FN7) of the finisher. Slide the finisher carefully back to the copier. The touch screen now displays a prompt to run a test staple cycle. Di470 2-51...
  • Page 70 Was the copy not stapled correctly? The staple unit is not correctly installed. § Ensure that the staple unit is correctly positioned. § If any staples are jammed, clear them. For more information, see page 7-53. 2-52 Di470...

  • Page 71: Finisher Fn-106

    Pull the staple unit carefully from the holder. Staple unit 1 Remove the empty staple cartridge from the staple unit. Position a new staple cartridge. Then carefully remove the seal on the staple cartridge. Di470 2-53...
  • Page 72 Was the copy not stapled correctly? The staple unit is not correctly installed. § Ensure that the staple unit is correctly positioned. § If any staples are jammed, clear them. For more information, see page 7-55. 2-54 Di470...

  • Page 73: Mailbin Finisher Fn-503

    Pull the stapler unit out of its bay. Press the green lever down. Pull the stapler unit out. Remove the empty staple cartridge from the staple unit. Di470 2-55...
  • Page 74 Push and hold the button. While holding it, turn it clockwise to close the cover of the stapler unit. The touch screen now displays a prompt to run a test staple cycle. 2-56 Di470...
  • Page 75 Was the copy not stapled correctly? The staple unit is not correctly installed. § Ensure that the staple unit is correctly positioned. § If any staples are jammed, clear them. For more information, see page 7-57. Di470 2-57...

  • Page 76: Shutting Down The Copier

    Money Stamps (cancelled or uncancelled) Personal identification cards Vehicle registration documents Copyrighted materials (without the permission of the copyright holder) If you are not sure whether a certain document may be copied, please consult the relevant public authorities. 2-58 Di470...

  • Page 77: Initial Steps

    Press [COPY MODE] on the control panel to activate copy mode. Load the originals: Load the originals face-up into the automatic document feeder. Lift the original cover. Place the original face down on the original glass. Di470...
  • Page 78 4-48. If necessary, change the Density settings, e.g.: Auto Exposure Manual Exposure Density Mode For more information, see page 4-60. If necessary, select an Auxiliary function, e.g.: Cover Number Stamping File Margin For more information, see page 4-64. Di470...
  • Page 79 Did you enter an incorrect number? § Press [C] on the control panel. Enter the number of copies again. Start the copy cycle by pushing [START]. Do you want to cancel the copy cycle? § Press [STOP] on the control panel. Di470...

  • Page 80: Entering The Administrator Number

    Press [KEY] on the control panel to confirm your input. The basic settings are displayed on the touch screen. The copier is enabled. You may now make copies. § Press [KEY] before leaving the copier. This secures the copier again. Di470...

  • Page 81: Checking Copier Settings

    Touch the corresponding keys on the numeric keypad. The number of copies is shown on the touch screen in the upper right- hand corner. Did you enter an incorrect number? § Press [C] on the control panel. Enter the number of copies again. Di470...

  • Page 82: Starting The Copy Cycle

    The copies are printed. Once the interim copy cycle has finished, touch [INTERRUPT]. The interrupted copy cycle is continued. Not all functions are available! When you are working in interrupt mode, not all functions are available. For more information, see page 7-60. Di470...

  • Page 83: Stopping The Copy Cycle

    Reset the copier to the default settings. § Press [RESET] on the control panel of the copier. The copier is reset to the default settings. Changing the default settings You can change the default settings of the copier. For more information, see page 6-20. Di470...

  • Page 84: Using The Automatic Document Feeder

    Translucent paper, OHP transparencies (overhead projector films) Folded, curled originals Punched, stapled originals Carbon-backed originals § Process unsuitable originals with the single feed tray. For more information, see page 3-12. Load unsuitable originals on the original glass. For more information, see page 3-13. Di470...

  • Page 85: Feeding Originals Of The Same Size

    (see Ä mark on the document feeder) Push the originals tight against the feed chamber of the automatic document feeder. Start the copy cycle. The originals are fed in automatically one after the other. Di470...

  • Page 86: Feeding Originals Of Different Sizes

    (see Ä mark on the document feeder). Push the originals tight against the feed chamber of the document feeder. Set the document guide to the largest original. Change any other necessary copier settings. Press the [ORIGINAL] button on the control panel. Original 3-10 Di470...
  • Page 87 Start the copy cycle. The originals are fed in automatically one after the other. The combination is the secret! Just combine mixed original detection with the “Auto Paper” “or Auto Size” functions. Originals Copies Automatic Paper Select Mode Automatic Size Mode Di470 3-11...

  • Page 88: Using The Single Feed Tray

    The side that is to be copied must be down. The original is automatically taken in and copied. Not all functions are available! When working with the single feed tray, not all functions are available. For more information, see page 7-60. 3-12 Di470...

  • Page 89: Placing Originals On The Glass

    Is the original transparent? § Place a sheet of white paper of the same size on top of the original. For transparent originals only Close the original cover. Change any other necessary copier settings. Start the copy cycle. Di470 3-13...

  • Page 90: Books And Bound Originals

    Close the original cover. Original Scale Is it impossible to close the original cover? § Leave the original cover open. § Do not look at the original glass during the copy process to avoid being dazzled by the extremely bright light. 3-14 Di470...

  • Page 91: Scanning Stacks Of Originals

    Load the originals. What should you consider when copying several, sequential originals using the original glass? § Scan the originals from front to back. Change any other necessary copier settings. Press the [ORIGINAL] button on the control panel. Original Di470 3-15...
  • Page 92 Place the next originals. Touch [START] to start the next scan cycle. The originals are scanned. Repeat step 6 until all originals have been scanned. Touch [FINISH] to stop the scan cycle. Start the copy cycle by touching [START]. 3-16 Di470...

  • Page 93: Using Memory Recall

    Touch [MODE CHECK] to change copier settings. Press [START] to start printing. Delete the data before leaving the copier! Before leaving the copier, for security reasons you should touch [RESET] to delete the data in memory. Di470 3-17...

  • Page 94: Setting Up Reserve Copy Jobs

    Use the job list! The job list shows the pending reserve copy jobs. You can also delete reserve copy jobs in the job list. For more information, see page 3-19. 3-18 Di470...

  • Page 95: Using The Job List

    The job list can also be used for: Changing copy job settings. Deleting copy jobs Viewing the Job List § Touch [JOB LIST] on the control panel. The job list is shown. § To exit the Job List, touch [EXIT]. Di470 3-19...

  • Page 96: Viewing The Copier Settings For A Reserve Copy Job

    Select the reserve copy job whose copier settings you wish to view. The copier settings are shown. Check the copier settings. Touch [EXIT] to close the view. The job list is displayed again. Touch [JOB LIST] again to show the basic settings again. 3-20 Di470...

  • Page 97: Changing The Number Of Copies For A Reserve Copy Job

    Select the reserve copy job that you wish to change. From the numeric keypad, set the desired number of copies to be made. Confirm your changes with [ENTER]. The job list is displayed again. Touch [JOB LIST] again to show the basic settings again. Di470 3-21...

  • Page 98: Deleting A Reserve Copy Job From The Job List

    The job list is shown. Press [DELETE]. Select the reserve copy job that you wish to delete. A prompt window appears. <If the job is not locked> Touch [YES]. <If the job is locked> Enter a 4-digit password from the 10-Key Pad. 3-22 Di470...

  • Page 99: Deleting The Current Copy Job

    Delete a current job or scan cycle. Touch [STOP] while the job is being scanned or printed. A prompt window appears. Touch [DELETE PRINTING JOB]. The current printing job is deleted. Touch [DELETE SCANNING JOB]. The current scanning job is deleted. Press [START]. Di470 3-23...

  • Page 100: Submitting A Print Job

    Have you used the same password for more than one print job? § All print jobs assigned the same password are submitted for processing. § The status of the submitted print job is changed to “Wait”. 3-24 Di470...
  • Page 101 Initial Steps . . . Touch [EXIT] to close the job list. Touch [JOB LIST] again to show the basic settings again. Di470 3-25...

  • Page 102: Other Functions

    The time before sleep mode is activated can be changed. For more information, see page 6-30. Auto Copy Start A copy cycle can be started even during warm-up. The copies are printed automatically after warm-up is complete. 3-26 Di470...

  • Page 103: Customizing Your Copy

    Customizing Your Copy Customizing Your Copy Basic Settings You can make settings in the following areas in the basic settings: Paper For more information, see page 4-2. Zoom For more information, see page 4-8. Finishing For more information, see page 4-24 Di470...

  • Page 104: Enabling Auto Paper Select Mode

    To disable the “Auto Paper” mode again, select a paper drawer manually. For more information, see page 4-3. Wrinkled, curled and dog-eared? Wrinkled, curled or dog-eared originals are not always identified correctly in this mode. Use only smooth originals. Di470...

  • Page 105: Selecting The Paper Drawer Manually

    Touch the [BASICS] index key to show the Basics menu keys again. Not all drawers are always available! Which paper drawers are available depends on the equipment of your copier. The touch screen will only show the available drawers. Di470...

  • Page 106: Setting The Paper Type For The Single Feed Tray

    Touch the Basics menu key [Paper]. The paper settings are shown. Press the button for the single feed tray. The [SIZE INPUT] key is shown. Press [SIZE INPUT]. The display will change. Touch [PAPER TYPE]. The display will change. Di470...
  • Page 107 Touch the [BASICS] index key to show the Basics menu keys again. Not all modes are always available! If you have selected the [OHP] or [CARD VELLUM] paper types, not all copier functions will be available. For more information, see page 7-60. Di470...

  • Page 108: Setting The Paper Size For The Single Feed Tray

    Press the button for the single feed tray. The [SIZE INPUT] key is shown. Press [SIZE INPUT]. The display will change. Select a standard size. Press [INCH] to select an inch size. Press [CUSTOM SIZE] to set a custom paper size. The display will change. Di470...
  • Page 109 Confirm your entries by pressing [ENTER]. The display will change. Confirm your settings with [ENTER]. The paper settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. Di470...

  • Page 110: Enabling Auto Size

    Call up the paper settings. The paper settings are shown. Select the paper drawer that contains the copy paper. Touch the [BASICS] index key to show the Basics menu keys again. § To disable “Auto Size Mode”, specify a zoom factor manually. Di470...

  • Page 111: Selecting A Fixed Zoom Factor

    To reset all zoom settings and to make a copy of the same size as the original, touch [1:1]. To make sure nothing is lost! The zoom factor for [MINIMAL] is × 0.930. This allows you to copy A4-originals without losing any information. Di470...

  • Page 112: Selecting A Zoom Factor Using The Arrow Keys

    Touch the [BASICS] index key to show the Basics menu keys again. How to do it faster Select a fixed zoom factor key nearest to the desired value, e.g. [A4 > A3]. Then use the arrow key to set the exact zoom factor. 4-10 Di470...

  • Page 113: Specifying A Zoom Factor Using The Numeric Keypad

    Input a zoom factor with the numeric keypad. Example: Touch the numeric keypad keys 1, 3, 0, 0 in succession. The zoom factor is × 1.300. Did you enter an incorrect number? § Press [C] and enter the zoom factor again. Di470 4-11...
  • Page 114 Customizing Your Copy Confirm the zoom factor with [ENTER]. The zoom settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. 4-12 Di470...

  • Page 115: Saving Zoom Factors

    The zoom factor can be changed in 0.001 increments. Reduce to: × 0.250 Enlarge to: × 4.000 × 2.000 (with automatic document feeder) Touch the Basics menu key [Zoom]. The zoom settings are shown. Touch [CUSTOM ZOOM]. The display will change. Touch [INPUT]. Di470 4-13...
  • Page 116 Touch the [BASICS] index key to show the Basics menu keys again. Overwritten and deleted! If both memory locations are occupied, a new zoom factor can be stored only by overwriting a memory location. The overwritten zoom factor is then deleted. 4-14 Di470...

  • Page 117: Loading Saved Zoom Factors

    Loading Saved Zoom Factors Recall a stored zoom factor. Touch the Basics menu key [Zoom]. The zoom settings are shown. Touch [CUSTOM ZOOM]. The display will change. Touch [RECALL]. Select the memory key [1] or [2] with the desired zoom factor. Di470 4-15...
  • Page 118 Customizing Your Copy Confirm your selection with [ENTER]. The zoom settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. 4-16 Di470...

  • Page 119: Specifying An Unproportional Zoom Factor

    Reduce to: × 0.250 Enlarge to: × 4.000 × 2.000 (with automatic document feeder) Touch the Basics menu key [Zoom]. The zoom settings are shown. Touch [CUSTOM ZOOM]. The display will change. Touch [X/Y ZOOM]. The display will change. Di470 4-17...
  • Page 120 Y-side using the keypad. Confirm the zoom factors with [ENTER]. The display will change. Confirm the process with [ENTER]. The zoom settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. 4-18 Di470...

  • Page 121: Saving Unproportional Zoom Factors

    Reduce to: × 0.250 Enlarge to: × 4.000 × 2.000 (with automatic document feeder) Touch the Basics menu key [Zoom]. The zoom settings are shown. Touch [CUSTOM ZOOM]. The display will change. Touch [X/Y ZOOM]. The display will change. Di470 4-19...
  • Page 122 X-side using the keypad. Press [Y]. Enter the zoom factor for the Y-side using the keypad. Touch the key for the desired memory location [1], [2] or [3]. The input zoom factors are shown on the memory location key. 4-20 Di470...
  • Page 123 Touch the [BASICS] index key to show the Basics menu keys again. Overwritten and deleted! If all three memory locations are occupied, a new zoom factor can be stored only by overwriting a memory location. The overwritten zoom factor is then deleted. Di470 4-21...

  • Page 124: Loading Stored Unproportional Zoom Factors

    Loading Stored Unproportional Zoom Factors Load a stored, unproportional zoom factor. Touch the Basics menu key [Zoom]. The zoom settings are shown. Touch [CUSTOM ZOOM]. The display will change. Touch [X/Y ZOOM]. The display will change. Touch [RECALL]. 4-22 Di470...
  • Page 125 [1], [2] or [3] with the desired zoom factor. Confirm your selection with [ENTER]. The display will change. Confirm your settings with [ENTER]. The zoom settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. Di470 4-23...

  • Page 126: Non-Sorted Copies

    Customizing Your Copy Non-Sorted Copies Copies are fed out unsorted. In the Basics menu touch [FINISHING]. The display will change. Press the [NON-SORT] button. Touch the [BASICS] index key to show the Basics menu keys again. 4-24 Di470...

  • Page 127: Sort/Group Copies

    OHP or heavy/fine paper types are disabled when using the single feed tray Di470 4-25...
  • Page 128 Touch the [BASICS] index key to show the Basics menu keys again. Grouping copies Press [FINISHING] in the Basics menu. The Finishing settings are shown. Touch [GROUP]. Touch the [BASICS] index key to show the Basics menu keys again. 4-26 Di470...

  • Page 129: Stapling Copies - Overview

    Note the following important information! Staple type: Loading in the automatic Loading onto the original document feeder: glass: Corner staple 2-point staple 2-point staple If the staple capacity is exceeded, “Sort” or “Group” mode is automatically enabled. Staple mode is automatically disabled. Di470 4-27...
  • Page 130 The copies, however, are not stapled. Stapling can be carried out manually afterwards. For more information, see page 4-35. Output Distribution with the Auto Dual Function (only available if the FN-5 finisher is installed) 4-28 Di470...
  • Page 131 100 sets or 1000 sheets A3 L to B4 L 10 sheets 50 sheets (no stapling) A3 L to B4 L – – 100 sheets A3 L 10 sheets 50 sheets (no stapling) A3 L – 100 sheets 100 sheets Di470 4-29...
  • Page 132 (no stapling) (no stapling) * A Z-Fold can only be carried out on A3 L paper. If originals of differing sizes are loaded (A3 L with other sizes), output is mixed, consisting of Z-folded copies and unfolded copies. 4-30 Di470...
  • Page 133 Copy: A3 L, B4 L Original: A3 L, B4 L Copy: A3 L, B4 L Loading the originals differently? If you do not load the originals as illustrated, you have to adjust the original alignment. For more information, see page 4-51. Di470 4-31...

  • Page 134: Stapling Copies - Corner Staple

    2 to 30 sheets (80g/m FN-503 2 to 50 sheets (80g/m Press [FINISHING]in the Basics menu. The Finishing settings are shown. Press [CORNER STAPLE]. Touch the [BASICS] index key to show the Basics menu keys again. Corner staple 4-32 Di470...

  • Page 135: Stapling Copies - 2-Point Staple (Side)/Centre Staple

    2-Point Staple (Side) 2 to 50 sheets (80g/m Centre Staple 2 to 15 sheets (80g/m Press [FINISHING] in the Basics menu. The Finishing settings are shown. Press [2-POINT STAPLE]. 2-point staple (side) only available with the FN-5 finisher Centre Staple Di470 4-33...
  • Page 136 Customizing Your Copy Press [SELECT POSITION]. The display will change. Select the staple position. Confirm your selection with [ENTER]. The finishing settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. 4-34 Di470...

  • Page 137: Stapling Copies - Manual Stapling

    50 sheets (80g/m ) at once. Place the stack of paper into the staple tray according the stapling position. The printed side must be face down. Align the stack of paper up to the rear edge of the finisher. Di470 4-35...
  • Page 138 Do not carry out step 6 until the finisher stops making noise, indicating that the preparation phase is complete. Select the staple position on the finisher's control panel. Start the staple cycle by pressing the staple button. 4-36 Di470...
  • Page 139 Customizing Your Copy Open the cover for the staple tray (FN10). Remove the stapled stack of paper. Close the cover of the staple tray (FN10). Di470 4-37...

  • Page 140: Punching Copies

    Have holes punched in your copies. Note the following important information! Paper sizes: A3L to A4 Hole type: Loading in the automatic Loading onto the original document feeder: glass: Press [FINISHING] in the Basics menu. The Finishing settings are shown. 4-38 Di470...
  • Page 141 Customizing Your Copy Press [HOLE PUNCH]. Press [SELECT POSITION]. The display will change. Select the hole position. Confirm your selection with [ENTER]. The finishing settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. Di470 4-39...

  • Page 142: Folding Copies - Overview

    Have your copies folded. There are three types of folding: Crease For more information, see page 4-40. Half-Fold For more information, see page 4-43. Z-Fold For more information, see page 4-45. Folding Copies – Crease (Only available if finisher FN-5 is installed.) 4-40 Di470...
  • Page 143 210 to 297 mm, length 279 to 432 mm, Fold capacity: 2 to 15 sheets (80g/m Press [FINISHING] in the Basics menu. The finishing settings are shown. Press the [FOLDING] button. Press the [CREASE] button. The display will change. Di470 4-41...
  • Page 144 Customizing Your Copy Press [2-POINT STAPLE]. Confirm your selection with [ENTER]. The display will change. Confirm your selection with [ENTER]. The finishing settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. 4-42 Di470...

  • Page 145: Folding Copies - Half-Fold

    Note the following important information! Paper sizes: A3 L, B4 L, width 257 to 297 mm, length 364 to 432 mm, Fold capacity: 2 to 10 sheets Press [FINISHING] in the Basics menu. The Finishing settings are shown. Di470 4-43...
  • Page 146 Select the desired finishing mode, such as [2-POINT STAPLE]. Confirm your selection with [ENTER]. The display will change. Confirm your selection with [ENTER]. The finishing settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. 4-44 Di470...

  • Page 147: Folding Copies - Z-Fold

    Note the following important information! Paper sizes: A3 L Fold capacity: Only Z-Fold: 2 to 10 sheets Z-Fold: 5 sheets + unfolded: 25 sheet Press [FINISHING] in the Basics menu. The Finishing settings are shown. Di470 4-45...
  • Page 148 Customizing Your Copy Press the [FOLDING] button. Press the [Z-FOLD] button. The display will change. Under “Output Size”, select the paper size onto which the unfolded copies are to be made. Select the desired finishing mode, such as [2-POINT STAPLE]. 4-46 Di470...
  • Page 149 Customizing Your Copy Confirm your selection with [ENTER]. The display will change. Confirm your selection with [ENTER]. The finishing settings are shown again. Touch the [BASICS] index key to show the Basics menu keys again. Di470 4-47...

  • Page 150: Original>Copy Functions

    Customizing Your Copy Original>Copy Functions You can select the copy mode in the Original>Copy settings. Original Copy Display 1-sided 1-sided 1-sided 2-sided 1-sided Single 2in1 1-sided Double 2in1 1-sided Single 4in1 4-48 Di470...
  • Page 151 Single 2in1 Only possible with automatic document feeder 2-sided Double 2in1 Only possible with automatic document feeder 2-sided Single 4in1 Only possible with automatic document feeder 2-sided Double 4in1 Only possible with automatic document feeder 2-sided Booklet Book 1-sided Di470 4-49...
  • Page 152 2-sided, 2in1, 4in1 or Booklet setting is selected under Copy. Exception: the “Separate Scan” function is not activated in the setting “Book - Separation - 2-sided Copy - Original Direction - Standard”. 4-50 Di470...

  • Page 153: Selecting A Copy Mode

    Touch the index key [Orig.>Copy]. The Original>Copy settings are shown. Select the type of original. e.g. 1-sided original Select the mode you wish to use for your copies. Touch the [4IN1/BOOKLET] key to select additional copy mode settings. Di470 4-51...
  • Page 154 The display will change. Press [ORIGINAL DIRECTION]. Set the text alignment of the original. Confirm your selection with [ENTER]. The Original>Copy settings are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. 4-52 Di470...

  • Page 155: Copying Originals With File Margins

    Touch the index key [Orig.>Copy]. The Original>Copy settings are shown. Select the settings for the originals and the copies. For more information, see page 4-51. Press [MARGIN]. The display will change. Set the position of the file margin on the originals. Di470 4-53...
  • Page 156 The 2nd original will be printed in the same direction as the 1st original. Settings: file margin above, file margin width 0 mm Result: The 2nd original will be printed in the opposite direction to the 1st original. 4-54 Di470...

  • Page 157: Copying Books

    Touch the index key [Orig.>Copy]. The Original>Copy settings are shown. Under “Original”, press [BOOK]. The display will change. Set the book type under “Original”. The display will change. Set the type of copy under “Copy”. The display will change. Di470 4-55...
  • Page 158 Customizing Your Copy Press [BOOK ERASE]. The display will change. Set the margin and frame erase for the book. Set the erase width of the margin or frame. Confirm your selection with [ENTER]. The display will change. 4-56 Di470...
  • Page 159 Customizing Your Copy Confirm your settings with [ENTER]. The Original>Copy settings are shown again. § The original settings are now set. Now make the copy settings. Di470 4-57...
  • Page 160 Select a copy mode. Which copy mode is available? § Only 1-sided or 2-sided copy mode is available. Press [PAGE ARRANGE.]. The display will change. Set the original direction of the book. The display will change. 4-58 Di470...
  • Page 161 Set the page arrangement of the book. The display will change. Book Order Standard Confirm your selection with [ENTER]. The Original>Copy settings are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470 4-59...

  • Page 162: Density Settings

    Customizing Your Copy Density Settings When setting the image density you can: enable or disable Auto Exposure make copies lighter or darker change the Exposure Mode 4-60 Di470...

  • Page 163: Toggling Auto Exposure

    To disable “Auto Exposure”, touch [LIGHTER] or [DARKER]. Control the copy density manually. Are your copies still too dark overall? You can change the default setting of the "Auto Exposure" mode in the User's Choice settings. For more information, see page 6-33. Di470 4-61...

  • Page 164: Making Copies Lighter Or Darker

    Set the exposure of the copies to a lighter or darker level to suit your requirements. Touch the index key [Density]. The display will change. Press [LIGHTER]to make a lighter copy. Touch [DARKER] to make a darker copy. 4-62 Di470...

  • Page 165: Changing The Density Mode

    The function is enabled. Control the image density manually. For more information, see page 4-62. Which setting for what? Text: if you copy primarily texts Text/Photo: if you copy texts and photos Photo: if you copy primarily photos Di470 4-63...

  • Page 166: Auxiliary Functions

    Customizing Your Copy Auxiliary Functions The auxiliary functions offer the following: Cover Page Insertion OHP Interleaving File Margin Edge/Frame Erase Image Repeat Number Stamping Image Stamping 4-64 Di470...

  • Page 167: Inserting A Cover Sheet

    When loading originals onto the original glass, the originals must first be scanned with the “Separate Scan” function. For more information, see page 3-15. Touch the index key [AUXILIARY]. The auxiliary functions are shown. Press [COVER]. The display will change. Di470 4-65...
  • Page 168 Blank A blank cover is inserted. Touch the key below “Cover Paper”. The display will change. Select the paper drawer from which the paper for the covers will be taken. The display will change. 4-66 Di470...
  • Page 169 You can also feed the cover paper with the single feed tray. Only the following paper sizes can be used in this mode: Paper width: min. 140 mm to max. 297 mm Paper length: min. 182 mm to max. 432 mm Di470 4-67...

  • Page 170: Inserting Separator Pages

    Load the originals containing the inserted separator pages into the document feeder. Align the originals in the right rear corner of the document feeder. Touch the index key [AUXILIARY]. The auxiliary functions are shown. 4-68 Di470...
  • Page 171 Select the settings for the insertion pages. With Image The original page after the insert marker will be printed on the inserted page. Blank A blank page is inserted. With Image Blank Touch the key below “Insert Paper”. The display will change. Di470 4-69...
  • Page 172 You can also feed the cover paper with the single feed tray. Only the following paper sizes can be used in this mode: Paper width: min. 140 mm to max. 297 mm Paper length: min. 182 mm to max. 432 mm 4-70 Di470...

  • Page 173: Ohp Interleaving

    Create an OHP transparency set. Insert OHP interleaves to complete the OHP transparency set. Load the originals. in the document feeder on the original glass Touch the index key [AUXILIARY]. The auxiliary functions are shown. Touch the index key [OHP INTERLEAVING]. The display will change. Di470 4-71...
  • Page 174 With Image Every original page will be printed on an OHP and on an insert marker. Blank A blank insert marker will be inserted after every OHP. Touch the key below “Insert Paper”. The display will change. 4-72 Di470...
  • Page 175 Confirm your settings with [ENTER]. The display will change. Confirm your settings with [ENTER]. The auxiliary functions are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470 4-73...

  • Page 176: Adding A Margin To Your Copy

    Add a file margin to your copies. Load the originals. in the document feeder on the original glass Touch the index key [AUXILIARY]. The auxiliary functions are shown. Press [FILE MARGIN]. The display will change. Select the position of the file margin. 4-74 Di470...
  • Page 177 The 2nd original will be printed in the same direction as the 1st original. Settings: file margin above, file margin width 0 mm Result: The 2nd original will be printed in the opposite direction to the 1st original. Di470 4-75...

  • Page 178: Erasing A Margin Or Frame Around Your Copy

    Touch the index key [AUXILIARY]. The auxiliary functions are shown. Press [EDGE/FRAME ERASE]. The display will change. Select the type of edge erase. Erase left edge Edge top edge Erase frame 4-76 Di470...
  • Page 179 If necessary, make additional copier settings. Start the copy cycle by touching [START]. The width of the edge is related to the original! The edge width for edge/frame erase is based on the originals, not on the copies. Di470 4-77...

  • Page 180: Duplicating Images Onto A Copy

    For more information, see page 4-11. Touch the index key [AUXILIARY]. The auxiliary functions are shown. Press [IMAGE REPEAT]. The display will change. Determine the size of the original image automatically. Set the original image size. For more information, see the following pages. 4-78 Di470...
  • Page 181 Determine the size of the original image automatically Press [AUTO DETECT]. The size of the original image is determined automatically. Confirm your input with [ENTER]. The auxiliary functions are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470 4-79...
  • Page 182 [Custom Size] is touched Press [X]. Input the length of the X-side with the numeric keypad. Press [Y]. Input the length of the Y-side with the numeric keypad. Confirm your inputs with [ENTER]. The display will change. 4-80 Di470...
  • Page 183 If necessary, make additional copier settings. Start the copy cycle by touching [START]. Number of image repeats The number of image repeats is automatically calculated based on the zoom factor, the size of the original image and the paper size. Di470 4-81...

  • Page 184: Creating Page Numbers

    Creating Page Numbers (Only possible if a hard disk is installed.) Add the following information to your copies: Date You can set the date format in the User's Choice settings. For more information, see page 6-28. Page Number Set Numbers 4-82 Di470...
  • Page 185 Touch the index key [AUXILIARY]. The auxiliary functions are shown. Touch [NUMBER STAMPING]. The display will change. Touch [DATE]. The display will change. Specify the position at which the date should be printed. Di470 4-83...
  • Page 186 Background erased Background not erased Confirm your inputs with [ENTER]. The display will change. Confirm your inputs with [ENTER]. The auxiliary functions are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. 4-84 Di470...
  • Page 187 The display will change. Touch [PAGE]. The display will change. Touch the arrow key below [STARTING NUMBER]. Use the keypad to set the starting number for the page numbers. The starting number can be a number between 1 and 999999999. Di470 4-85...
  • Page 188 The starting number can be between 1 and 99. Set whether the background at the page number position should be erased. Background erased Background not erased Confirm your inputs with [ENTER]. The display will change. 4-86 Di470...
  • Page 189 Customizing Your Copy Confirm your inputs with [ENTER]. The auxiliary functions are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470 4-87...
  • Page 190 The auxiliary functions are shown. Touch [NUMBER STAMPING]. The display will change. Touch [DISTRIBUTION]. The display will change. Use the keypad to set the starting number for the record numbers. The starting number can be a number between 1 and 999. 4-88 Di470...
  • Page 191 First page only All pages Confirm your inputs with [ENTER]. The display will change. Confirm your inputs with [ENTER]. The auxiliary functions are shown again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470 4-89...

  • Page 192: Creating Image Stamping

    For more information, see page 6-9. Load the originals. in the document feeder on the original glass Touch the index key [AUXILIARY]. The auxiliary functions are shown. Touch [IMAGE STAMPING]. The display will change. 4-90 Di470...
  • Page 193 Select the memory location in which the image that is to be inserted was saved. The display will change. Select the position to which the image should be inserted on the copy. Confirm your selection with [ENTER]. The display will change. Di470 4-91...
  • Page 194 Customizing Your Copy Confirm your selection with [ENTER]. The auxiliary functions are shown. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. 4-92 Di470...

  • Page 195: Combining Functions

    For more information, see page 4-74 7. Staple/Hole position in the Finishing settings For more information, see page 4-27 8. Loading originals in the automatic document feeder A horizontal line in a table field indicates that no setting is required there. Di470...
  • Page 196 For more information, see page 4-51. Original alignment If you use A3 L or B4 L copy paper, the “2-Point Staple” and “Hole Punch” functions are not available. Function combinations 9 10 11 12 Di470...

  • Page 197: Original: 1-Sided, Copy: 1-Sided

    Desired result Copy Finishing Margin Margin Pos. 1-sided Corner Staple 1-sided Corner Staple 1-sided Hole Punch, 2-point staple 1-sided Hole Punch, 2-point staple 1-sided Corner Staple 1-sided Corner Staple 1-sided Hole Punch, 2-point staple 1-sided Hole Punch, 2-point staple Di470...
  • Page 198 Corner 2in1 Staple Single Corner 2in1 Staple Single Hole Punch, 2in1 2-point staple Single Hole Punch, 2in1 2-point staple Single Corner 2in1 Staple Single Corner 2in1 Staple Single Hole Punch, 2in1 2-point staple Single Hole Punch, 2in1 2-point staple Di470...
  • Page 199 Corner 4in1 Staple Single Corner 4in1 Staple Single Hole Punch, 4in1 2-point staple Single Hole Punch, 4in1 2-point staple Single Corner 4in1 Staple Single Corner 4in1 Staple Single Hole Punch, 4in1 2-point staple Single Hole Punch, 4in1 2-point staple Di470...

  • Page 200: Original: 1-Sided, Copy: 2-Sided

    Desired result Copy Finishing Margin Margin Pos. Corner sided Staple Corner sided Staple Hole Punch, sided 2-point staple Hole Punch, sided 2-point staple Corner sided Staple Corner sided Staple Hole Punch, sided 2-point staple Hole Punch, sided 2-point staple Di470...
  • Page 201 Corner 2in1 Staple Double Hole Punch, 3 4 5 6 2in1 2-point staple Double Hole Punch, 2in1 2-point staple Double Corner 2in1 Staple Double Corner 2in1 Staple Double Hole Punch, 2in1 2-point staple Double Hole Punch, 2in1 2-point staple Di470...
  • Page 202 11 12 Double Corner 7 8 9 10 4in1 Staple 11 12 Double Corner 4in1 Staple 9 10 11 12 Double Hole Punch, 9 10 4in1 2-point 11 12 staple Double Hole Punch, 4in1 2-point 9 10 staple 11 12 Di470...

  • Page 203: Original: 2-Sided (File Margin Left), Copy: 1-Sided

    Desired result Copy Finishing Margin Margin Pos. 1-sided Corner Staple 1-sided Corner Staple 1-sided Hole Punch, 2-point staple 1-sided Hole Punch, 2-point staple 1-sided Corner Staple 1-sided Corner Staple 1-sided Hole Punch, 2-point staple 1-sided Hole Punch, 2-point staple Di470...
  • Page 204 2in1 Staple Single Corner 2in1 Staple Single Hole Punch, 2in1 2-point staple Single Hole Punch, 2in1 2-point staple Single Corner 2in1 Staple Single Corner 2in1 Staple Single Hole Punch, 2in1 2-point staple Single Hole Punch, 2in1 2-point staple 5-10 Di470...
  • Page 205 4in1 Staple Single Corner 4in1 Staple Single Hole Punch, 4in1 2-point staple Single Hole Punch, 4in1 2-point staple Single Corner 4in1 Staple Single Corner 4in1 Staple Single Hole Punch, 4in1 2-point staple Single Hole Punch, 4in1 2-point staple Di470 5-11...

  • Page 206: Original: 2-Sided (File Margin Left), Copy: 2-Sided

    Desired result Copy Finishing Margin Margin Pos. 2-sided Corner Staple 2-sided Corner Staple 2-sided Hole Punch, 2-point staple 2-sided Hole Punch, 2-point staple 2-sided Corner Staple 2-sided Corner Staple 2-sided Hole Punch, 2-point staple 2-sided Hole Punch, 2-point staple 5-12 Di470...
  • Page 207 2in1 Staple Double Hole Punch, 3 4 5 6 2in1 2-point staple Double Hole Punch, 2in1 2-point staple Double Corner 2in1 Staple Double Corner 2in1 Staple Double Hole Punch, 2in1 2-point staple Double Hole Punch, 2in1 2-point staple Di470 5-13...
  • Page 208 Double Corner 7 8 9 10 4in1 Staple 11 12 Double Corner 4in1 Staple 9 10 11 12 Double Hole Punch, 4in1 2-point 9 10 11 12 staple Double Hole Punch, 4in1 2-point 9 10 staple 11 12 5-14 Di470...

  • Page 209: Original: 2-Sided (File Margin Above), Copy: 1-Sided

    Desired result Copy Finishing Margin Margin Pos. 1-sided Corner Staple 1-sided Corner Staple 1-sided Hole Punch, 2-point staple 1-sided Hole Punch, 2-point staple 1-sided Corner Staple 1-sided Corner Staple 1-sided Hole Punch, 2-point staple 1-sided Hole Punch, 2-point staple Di470 5-15...
  • Page 210 2in1 Staple Single Corner 2in1 Staple Single Hole Punch, 2in1 2-point staple Single Hole Punch, 2in1 2-point staple Single Corner 2in1 Staple Single Corner 2in1 Staple Single Hole Punch, 2in1 2-point staple Single Hole Punch, 2in1 2-point staple 5-16 Di470...
  • Page 211 4in1 Staple Single Corner 4in1 Staple Single Hole Punch, 4in1 2-point staple Single Hole Punch, 4in1 2-point staple Single Corner 4in1 Staple Single Corner 4in1 Staple Single Hole Punch, 4in1 2-point staple Single Hole Punch, 4in1 2-point staple Di470 5-17...

  • Page 212: Original: 2-Sided (File Margin Above), Copy: 2-Sided

    Desired result Copy Finishing Margin Margin Pos. 2-sided Corner Staple 2-sided Corner Staple 2-sided Hole Punch, 2-point staple 2-sided Hole Punch, 2-point staple 2-sided Corner Staple 2-sided Corner Staple 2-sided Hole Punch, 2-point staple 2-sided Hole Punch, 2-point staple 5-18 Di470...
  • Page 213 2in1 Staple Double Hole Punch, 3 4 5 6 2in1 2-point staple Double Hole Punch, 2in1 2-point staple Double Corner 2in1 Staple Double Corner 2in1 Staple Double Hole Punch, 2in1 2-point staple Double Hole Punch, 2in1 2-point staple Di470 5-19...
  • Page 214 Double Corner 7 8 9 10 4in1 Staple 11 12 Double Corner 4in1 Staple 9 10 11 12 Double Hole Punch, 9 10 4in1 2-point 11 12 staple Double Hole Punch, 4in1 2-point 9 10 staple 11 12 5-20 Di470...

  • Page 215: Utilities

    (option) and the "100 Accounts" function is enabled Make copier settings as required. Touch [UTILITY]. The Utility screen appears. Touch [JOB/IMAGE MEM. INPUT]. The display will change. Touch [JOB MEMORY INPUT]. The display will change. Di470...
  • Page 216 Why is there a symbol at some memory locations? The free symbol indicates that the memory location is free. § Save a copy job program to a free memory location. occupied free Confirm your settings with [ENTER]. The display will change. Di470...
  • Page 217 [START]. Overwritten and deleted! If all three memory locations are occupied, a copy job program can be stored only by overwriting a memory location. The copy job program on the overwritten memory location is deleted by this action. Di470...

  • Page 218: Checking The Settings Of A Copy Job Program

    Checking the Settings of a Copy Job Program Check the settings of a stored copy job program. Touch [UTILITY]. The Utility screen appears. Touch [JOB/IMAGE MEM. INPUT]. The display will change. Touch [JOB MEMORY INPUT]. The display will change. Press [CHECK]. The display will change. Di470...
  • Page 219 Touch [EXIT] to finish checking. Touch [ENTER] to close the Job Memory Input screen. The display will change. Press [EXIT] to complete the procedure. The Utility screen appears again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470...

  • Page 220: Recalling A Stored Copy Job Program

    § Select the correct copy job program from the screen. Confirm your selection with [EXIT]. The settings of the copy job program are loaded into the copier. The copy cycle can be started. Di470...

  • Page 221: Deleting A Stored Copy Job Program

    Deleting a Stored Copy Job Program Delete a copy job program from job memory. Press the [UTILITY] button on the control panel. The Utility screen appears. Touch [JOB/IMAGE MEM. INPUT]. The display will change. Touch [JOB MEMORY INPUT]. The display will change. Press [DELETE]. Di470...
  • Page 222 The free symbol appears at the memory location again. Confirm the deletion with [ENTER]. Press [EXIT] to complete the procedure. The Utility screen appears again. § If necessary, make additional copier settings. Start the copy cycle by touching [START]. Di470...

  • Page 223: Using The Image Memory

    Stamping” function. For more information, see page 4-90. Storing an Image Place the original lengthwise on the original glass. Touch [UTILITY]. The display will change. Touch [JOB/IMAGE MEM. INPUT]. The display will change. Touch [IMAGE MEMORY INPUT]. The display will change. Di470...
  • Page 224 Activate an edge/frame erase. For more information, see the following pages. Set the image direction of the original on the original glass. Start the scan cycle by touching [START]. 6-10 Di470...
  • Page 225 Press [CUSTOM SIZE]. The display will change. Press [X] or [Y]. Input an image size with the numeric keypad. Confirm your setting with [ENTER]. The display will change. Setting the Edge/Frame Erase Touch [ERASE]. The display will change. Di470 6-11...
  • Page 226 Utilities Select the erase position for the edge or frame. Set the erase width of the edge or frame with the arrow keys. Confirm your setting with [ENTER]. The display will change. 6-12 Di470...

  • Page 227: Checking A Stored Image

    Utilities Checking a Stored Image Check a stored image. Touch [UTILITY]. The Utility screen appears. Touch [JOB/IMAGE MEM. INPUT]. The display will change. Touch [IMAGE MEMORY INPUT]. The display will change. Press [CHECK]. Di470 6-13...
  • Page 228 Touch the memory location key where the desired image was stored. The display will change. Select the drawer from which the copy paper is to be fed. The display will change. Touch [START] to start printing. The stored image is printed. 6-14 Di470...

  • Page 229: Deleting A Stored Image

    Utilities Deleting a Stored Image Delete an image from memory. Touch [UTILITY]. The Utility screen appears. Touch [JOB/IMAGE MEM. INPUT]. The display will change. Touch [IMAGE MEMORY INPUT]. The display will change. Press [DELETE]. Di470 6-15...
  • Page 230 The free symbol appears at the image memory location again. Confirm the deletion with [ENTER]. The Utility screen appears again. Press [EXIT] to complete the procedure. The Utility screen appears again 6-16 Di470...

  • Page 231: Checking Copier Meter Counts

    The size is the same as that of the paper size counter. Account Total (Only for access with an administrator number.) The Account Total Indicator shows the number of copies made for the current administrator number. Di470 6-17...
  • Page 232 Size (Only if a printer controller is installed.) The Paper Size Counter shows the number of printouts made on copy paper of a preset size. The size will be set by your technical representative. 6-18 Di470...

  • Page 233: Starting The Toner Replenisher Function

    This will ensure even copy quality. Touch [UTILITY]. The display will change. Touch [TONER REPLENISHER]. During the toner replenisher cycle: Do not turn the copier off. Do not open the front door of the copier. The process will end automatically. Di470 6-19...

  • Page 234: Configuring The User's Choice Settings

    User's Choice [1/6] see page 6-24 User's Choice [2/6] see page 6-26 User's Choice [3/6] see page 6-28 User's Choice [4/6] see page 6-29 User's Choice [5/6] see page 6-30 User's Choice [6/6] see page 6-33 6-20 Di470...
  • Page 235 The prompt for entering the administrator number appears. Touch [UTILITY]. The Utility screen appears. Touch [ADMINISTRATOR MODE]. The prompt for entering the administrator code appears. Enter the 4-digit administrator code. All six index cards can now be selected. Di470 6-21...

  • Page 236: Configuring User's Choice Settings

    Utilities Configuring User's Choice Settings Touch [UTILITY]. The Utility screen appears. Touch [USER'S CHOICE]. The display will change. Select the index card for the setting that you wish to change. Select the setting that you wish to change. 6-22 Di470...
  • Page 237 The Utility screen appears again. First clear old values! Some User Settings require values to be input with the numeric keypad. Before you can input a new value, you must first delete the old value. Press [C] to delete the old value. Di470 6-23...

  • Page 238: User's Choice [1/6]

    This key allows you to switch quickly to 1>1 mode. Selecting a Language Specify the language that will be activated on the touch screen when the copier is switched on or reset. § Select the desired language. The default setting is “English”. 6-24 Di470...
  • Page 239 Select [AUTO PAPER], [AUTO SIZE] or [MANUAL]. The default setting is [AUTO SIZE]. Tray Priority Specify the paper drawer to be enabled by default when the copier is switched on or reset. § Select the desired paper drawer. The default setting is “1st Drawer”. Di470 6-25...

  • Page 240: User's Choice [2/6]

    Select [AUTO] for Auto Exposure or [MANUAL] for Manual Exposure. The default setting is [AUTO]. § If you have selected the [MANUAL] image density setting, select image density optimisation for [TEXT], [TEXT/PHOTO] or [PHOTO]. The default setting is [TEXT]. 6-26 Di470...
  • Page 241 § Select the desired setting. The default setting is [ON]. Criss-Cross Mode Specify whether Criss-Cross mode is activated when the finishing functions “Sorting” or “Group” are activated. § Select the desired setting. The default setting is [ON]. Di470 6-27...

  • Page 242: User's Choice [3/6]

    § Select the punctuation. The default setting is [XX/XX/XX]. § Select the format for the year. The default setting is [YY]. § Select the format for the date. The default setting is [00/12/27] (Year/Month/Day). 6-28 Di470...

  • Page 243: User's Choice [4/6]

    Touch [USER'S CHOICE] on the Touch Screen. The display will change. Press [4/6]. Confirmation Beep Specify whether an audible signal tone should sound when a key is pressed on the Touch Screen. § Select the desired setting. The default setting is [ON]. Di470 6-29...

  • Page 244: User's Choice [5/6]

    • 2-sided Copying Insert This paper drawer will not be used in: cover/page • Auto Paper Mode • Automatic Paper Drawer Change Cover This paper drawer will not be used in: • Auto Paper Mode • Automatic Paper Drawer Change 6-30 Di470...
  • Page 245 The default setting is [90 MINUTES]. § (With printer controller – Sleep Mode) Input a value between 15 and 90 minutes with the numeric keypad. Press [NO RESET] if the copier should not be automatically shut off. The default setting is [90 MINUTES]. Di470 6-31...
  • Page 246 6-49. Applicable for Switzerland only! To meet the E2000 regulations in Switzerland, when the device is installed the default setting for activating Energy Save Mode (Auto Shut Off) is to be changed from 90 minutes to 40 minutes. 6-32 Di470...

  • Page 247: User's Choice [6/6]

    Select [MODE 1] for originals with normal coverage such as text printed with a laser printer. The default setting is “On”. § Select [MODE 2] for very light originals such as text written with a pencil. The default setting is [MODE 1]. Di470 6-33...
  • Page 248 Priority Offset Tray (Only available if an FN-5, FN-105 or FN-106 finisher is installed.) Specify the offset tray to which the copies should preferably be fed out. § Select the desired setting. The default setting is [TOP TRAY]. 6-34 Di470...

  • Page 249: Using The Administrator Mode

    Making Settings in Administrator Mode Open administrator mode to make administrator settings. Touch [UTILITY]. The Utility screen appears. Touch [ADMINISTRATOR MODE]. The display will change. Input a 4-digit administrator code using the keypad. Administrator mode is displayed. Di470 6-35...
  • Page 250 Utilities <When jobs are queued> The Touch Panel now shows the detailed functions that can be set under Administrator Mode. <When jobs are not queued> Confirm your settings with [EXIT]. The basic settings are shown again. 6-36 Di470...

  • Page 251: Turning On The Copy Counter

    Open the administrator menu. For more information, see page 6-35. Touch [COPY TRACK]. The display will change. Specify the copy mode (copier or printer) for which the copy track should be activated. Di470 6-37...
  • Page 252 1000 Copy Tracks. Confirm your selection with [ENTER]. Confirm your selection with [ENTER]. The administrator menu is shown again. NOTE If Copy Track is turned on for the printer, account No.0001 cannot be used. (Specify accounts starting from No.0002.) 6-38 Di470...

  • Page 253: Setting Access Numbers

    Touch a key under “Access Code”. Enter a 4-digit administrator code on the keypad. Did you enter an incorrect number? § Press [C] on the control panel. Input the Access number again. If necessary, make additional settings for other counters. Di470 6-39...
  • Page 254 Utilities Confirm your inputs with [ENTER]. The display will change. Touch [ENTER] to complete the procedure. The administrator menu is shown again. 6-40 Di470...

  • Page 255: Setting Copy Limits For Access Numbers

    Touch a key under “Copy Limit”. Set the Copy Limit with the numeric keypad. Did you enter an incorrect number? § Press [C]on the control panel. Input the Access number again. If necessary, make additional settings for other counters. Di470 6-41...
  • Page 256 Utilities Confirm your inputs with [ENTER]. The display will change. Touch [ENTER] to complete the procedure. The administrator menu is shown again. 6-42 Di470...

  • Page 257: Printing Copy Track Data

    Press [COPY TRACK DATA]. The display will change. Place A4 L copy paper in the single feed tray. Press [START]. The Copy Track Data will be printed. Touch [ENTER] to complete the procedure. The administrator menu is shown again. Di470 6-43...

  • Page 258: Resetting Individual Access Numbers

    Touch the key of a count group. The display will change. Press the key for the value that you wish to reset. Press [C] to reset the value. If necessary, reset other counters. Confirm your inputs with [ENTER]. The display will change. 6-44 Di470...
  • Page 259 Utilities Touch [ENTER] to complete the procedure. The administrator menu is shown again. Di470 6-45...

  • Page 260: Resetting All Counters

    For more information, see page 6-35. Press [COPY TRACK DATA]. The display will change. Press [ALL COUNTER RESET]. The display will change. Touch [YES] to reset all Copy Track counters. The display will change. Confirm your selection with [ENTER]. The display will change. 6-46 Di470...
  • Page 261 Utilities Touch [ENTER] to complete the procedure. The administrator menu is shown again. Di470 6-47...

  • Page 262: Limiting The Number Of Copies Per Copy Cycle

    Did you enter an incorrect number? § Press [C] on the control panel. Input the Access number again. Touch [ENTER] to confirm your inputs. The administrator menu is shown again. 6-48 Di470...

  • Page 263: Locking The Auto Shut Off Mode

    The display will change. Touch [YES] to enable the function for the user. Touch [NO] to ensure that this function cannot be disabled by the user. Touch [ENTER] to confirm your inputs. The administrator menu is shown again. Di470 6-49...

  • Page 264: Job Delete

    Deletes documents stored in the machine. To show [COPY TRACK] on the Touch Panel, follow the steps given in “Selecting the Administrator Mode.” Touch [JOB DETETE]. Touch the job no. key to be deleted. Touch [YES]. Touch [EXIT]. 6-50 Di470...

  • Page 265: Troubleshooting

    4-62. The entire surface of the Clean the original glass, original glass is dirty. see page 8-1. The original is not flat Place the original on the against the original glass. original glass correctly, see page 3-13. Di470...
  • Page 266 The original is not suitable Place the original on the for the document feeder. original glass, see page 3-13. The entire surface of the Clean the original glass, see original glass is dirty. page 8-1. (When using the automatic document feeder) Di470...

  • Page 267: If A Message Appears On The Touch Screen

    Original left on the Glass. There is still an original Remove the original from on the original glass. the glass. This mode cannot be Certain modes cannot Cancel one of the two selected with the OOO be combined, see functions. mode. page 7-60. Di470...

  • Page 268: If Your Copier Is Not Working Correctly

    The room circuit breaker Close the room circuit is open. breaker. If any other technical problems should occur: Turn the copier off, Remove the power plug from the outlet, and Call your technical representative Di470...

  • Page 269: If A Malfunction Code Appears

    Report the code shown on the display to your technical representative. Message Indicating a Malfunction Use the power switch to turn the copier off. Report the code shown on the display to your technical representative. Di470...

  • Page 270: How To Clear A Paper Misfeed

    7-17 Finisher FN-105 see page 7-35 Finisher FN-106 see page 7-38 Finisher FN-503 see page 7-41 Desk Type Cabinet PF-208 see page 7-44 Large Desk Type Cabinet PF-115 see page 7-46 Large Capacity Cassette C-306/C-306L see page 7-48 Di470...

  • Page 271: Main Unit

    First, remove misfed paper from the fusing section and then from the paper feed section. Fusing section Remove the paper from the copy tray. Remove the copy tray. Open the front door. Open the upper cover (L1) on the left side of the unit. Di470...
  • Page 272 Open the middle cover (L2) on the left side of the unit. Carefully pull out any paper jammed there. Close the cover (L2) again. Release the transport unit with the lock release lever (M3). Carefully pull out any paper jammed there to the front. Di470...
  • Page 273 Open the cover (R1) on the right side of the unit. Pull out the jammed paper found there. Close the cover (R1) again. Carefully pull the paper drawer currently in use out to the stop. Remove the copy paper from the paper drawer. Di470...
  • Page 274 Troubleshooting Fan the copy paper. Place the copy paper back in the paper drawer. Close the paper drawer. Open and close the front door to clear the paper misfeed message. 7-10 Di470...

  • Page 275: Single Feed Tray

    Open the upper cover (R1) on the right side of the unit. Carefully pull out any paper jammed there. Close the cover (R1) again. Fan the paper from the single feed tray thoroughly. Replace it in the single feed tray. Di470 7-11...

  • Page 276: Electronic Document Handler Edh-3

    Open the document guide (F2). Carefully pull out any paper jammed there. Lift the document tray (F3) up until you hear an audible click. Carefully pull out any originals jammed there. 7-12 Di470...
  • Page 277 Unlock the document tray (F3). Lower the document tray (F3) again Scanner section Open the Electronic Document Handler. Open the document guide (F5) on the lower right side of the document feeder. Carefully pull out any originals jammed there. Di470 7-13...
  • Page 278 Count the number of originals last fed as shown on the Touch Screen. Place the counted originals back in the document feeder. Take the originals that have not yet been scanned. Place these originals under the previous originals. 7-14 Di470...

  • Page 279: Duplex Unit Pf-7D/Pf-208

    Open the middle cover (L2) and the lower cover (L1) on the left side of the unit. Carefully pull out any paper jammed there. Close covers (L2) and (L1) again. Open the lower cover (R2) on the right side of the unit. Di470 7-15...
  • Page 280 Open the guide plate (D). Pull out the jammed paper found there. Close the guide plate (D). Slide the duplex unit back into position. Open and close the front door to clear the paper misfeed message. 7-16 Di470...

  • Page 281: Finisher Fn-5 - Overview

    7-18. Finisher FN-5 – Paper Misfeed 2 For additional information, see page 7-23. Finisher FN-5 – Paper Misfeed 3 For additional information, see page 7-26. Finisher FN-5 – Paper Misfeed 4 For additional information, see page 7-27. Di470 7-17...

  • Page 282: Finisher Fn-5 - Paper Misfeed 1

    The first 8 steps . . . Reach into the recessed grip at the top of the finisher. Pull the finisher carefully from the copier. Open the paper misfeed door (H1). Carefully pull out any paper jammed there. 7-18 Di470...
  • Page 283 Open the front door on the front of the finisher. Open the transport unit while pulling its release lever. Carefully pull out any paper jammed there. Lift the paper misfeed door (FN3). Carefully pull out any paper jammed there. Di470 7-19...
  • Page 284 Carefully pull out any paper jammed there. Close the paper misfeed door (FN4). Close the transport unit. Rotate the two paper transport knobs (FN6) and (FN7) to the left. This will transport jammed paper out of the unit. 7-20 Di470...
  • Page 285 . . . and just a few more steps to go Loosen both screws and open the paper misfeed door. Carefully pull out any paper jammed there. Close the paper misfeed door. Tighten both screws again. Close the paper misfeed door (FN1). Di470 7-21...
  • Page 286 Troubleshooting Close the front door. Slide the finisher carefully back to the copier. 7-22 Di470...

  • Page 287: Finisher Fn-5 - Paper Misfeed 2

    Metal parts in the finisher can be hot. § Do not touch metal parts in the finisher. Reach into the recessed grip at the top of the finisher. Pull the finisher carefully from the copier. Open the front door on the front of the finisher. Di470 7-23...
  • Page 288 Rotate the two paper transport knobs (FN6) and (FN7) to the left. This will transport jammed paper out of the unit. Push the release levers of the paper misfeed door (FN5) together. Open the paper misfeed door (FN5). 7-24 Di470...
  • Page 289 Troubleshooting Carefully pull out any paper jammed there. Close the paper misfeed door (FN5). Close the front door. Slide the finisher carefully back to the copier. Di470 7-25...

  • Page 290: Finisher Fn-5 - Paper Misfeed 3

    Do not touch metal parts in the finisher. Open the top offset tray (FN9). Carefully pull out any paper jammed there. Close the top offset tray (FN9). Open the staple tray (FN10). Carefully pull out any paper FN10 jammed there. Close the staple tray (FN10). 7-26 Di470...

  • Page 291: Finisher Fn-5 - Paper Misfeed 4

    The first 8 steps . . . Reach into the recessed grip at the top of the finisher. Pull the finisher carefully from the copier. Open the paper misfeed door (H1). Carefully pull out any paper jammed there. Di470 7-27...
  • Page 292 Open the front door on the front of the finisher. Open the transport unit while pulling its release lever. Carefully pull out any paper jammed there. Lift the paper misfeed door (FN3). Carefully pull out any paper jammed there. 7-28 Di470...
  • Page 293 Carefully pull out any paper jammed there. Close the paper misfeed door (FN4). Close the transport unit. Rotate the two paper transport knobs (FN6) and (FN7) to the left. This will transport jammed paper out of the unit. Di470 7-29...
  • Page 294 Check whether there is any visible jammed paper left in the finisher. Is any jammed paper left? Jammed paper can prevent the paper folding unit (PF2) from being pulled out. § Repeat step 7 once again. 7-30 Di470...
  • Page 295 Carefully pull out any paper jammed there. Close the paper misfeed door (FN4). Close the transport unit. Rotate the two paper transport knobs (FN6) and (FN7) to the left. This will transport jammed paper out of the unit. Di470 7-31...
  • Page 296 (FN5). Carefully pull out any paper jammed there. Close the paper misfeed door (FN5). Carefully pull out the paper folding unit (PF2). Open the paper misfeed door (PF3). Carefully pull out any paper jammed there. 7-32 Di470...
  • Page 297 Carefully pull out any paper jammed there. Lower the paper misfeed door (PF4). Open the paper misfeed door (PF5). Carefully pull out any paper jammed there. Open the paper misfeed door (PF6). Carefully pull out any paper jammed there. Di470 7-33...
  • Page 298 Troubleshooting Carefully push the paper folding unit (PF2) back in. Close the front door. Slide the finisher carefully back to the copier. 7-34 Di470...

  • Page 299: Finisher

    Stapler section Reach into the recessed grip at the top of the finisher. Pull the finisher carefully from the copier. Pull the jammed paper carefully from the right side of the finisher. Di470 7-35...
  • Page 300 Open the front door (FN4) on the front of the finisher. Rotate the two paper transport knobs (FN5) to the right simultaneously. This will transport jammed paper out of the staple unit. Close the front door of the finisher (FN4). 7-36 Di470...
  • Page 301 Close the guide plate (FN3). Close the paper release cover (FN1). Open the paper release cover (FN6) on the left side of the unit. Carefully pull out any paper jammed there. Slide the finisher carefully back to the copier. Di470 7-37...

  • Page 302: Finisher

    Stapler section Reach into the recessed grip at the top of the finisher. Pull the finisher carefully from the copier. Pull the jammed paper carefully from the right side of the finisher. 7-38 Di470...
  • Page 303 Rotate the two paper transport knobs (FN5) to the right simultaneously. This will transport jammed paper out of the staple unit. Close the front door of the finisher (FN4). Open the paper release cover (FN1) at the upper right of the finisher. Di470 7-39...
  • Page 304 Close the guide plate (FN3). Close the paper release cover (FN1). Open the paper release cover (FN6) on the left side of the unit. Carefully pull out any paper jammed there. Slide the finisher carefully back to the copier. 7-40 Di470...

  • Page 305: Finisher

    Pull the finisher carefully from the copier. Open the paper misfeed door (FN2). Only if the hole punch feature has been used: Turn the hole adjustment wheel about 4 times downward. Pull out any paper jammed there. Di470 7-41...
  • Page 306 (FN3) and (FN2) Lift the cover for the top offset tray (FN1). Carefully pull out any paper jammed there. Close the cover (FN1). Open the paper misfeed cover (FN4) on the right side of the unit. 7-42 Di470...
  • Page 307 Troubleshooting Carefully pull out any paper jammed there. Open the paper misfeed door (FN5). Carefully pull out any paper jammed there. Close the paper misfeed door (FN4). Slide the finisher carefully back to the copier. Di470 7-43...

  • Page 308: Desk Type Cabinet Pf-208

    Desk Type Cabinet PF-208 Open the lower cover (R2) on the right side of the unit. Carefully pull out any paper jammed there. Close the cover (R2) again. Carefully pull the paper drawer out as far as it will go. 7-44 Di470...
  • Page 309 Troubleshooting Fan the copy paper. Replace the copy paper. Close the paper drawer carefully. Open and close the front door to clear the paper misfeed message. Di470 7-45...

  • Page 310: Desk Type Cabinet Pf-115

    Carefully pull out any paper jammed there. Close the cover (R2) again. Press the release button on the paper drawer. The paper plate is lowered. Carefully pull the paper drawer out as far as it will go. 7-46 Di470...
  • Page 311 Remove the copy paper from the paper drawer. Fan the copy paper. Replace the copy paper. Close the paper drawer carefully. The paper plate of the drawer is automatically raised. Open and close the front door to clear the paper misfeed message. Di470 7-47...

  • Page 312: Large Capacity Cassette C-306/C-306L

    Carefully pull out any paper jammed in the paper take-up area. Close the front door. Pull and hold the release buttons on top of the large capacity cassette. Pull the large capacity cassette carefully away from the copier. 7-48 Di470...
  • Page 313 Troubleshooting Pull the jammed paper carefully from the back of the large capacity cassette. Slide the large capacity cassette back to the copier. Di470 7-49...

  • Page 314: How To Release A Staple Jam

    7-51 Finisher FN-105 see page 7-53 Finisher FN-106 see page 7-55 Finisher FN-503 see page 7-57 Staple jam corrected and stapling not possible! Contact your technical representative if stapling does not function after correcting a staple jam. 7-50 Di470...

  • Page 315: Finisher Fn-5

    Pull the finisher carefully from the copier. Open the front door of the finisher. Carefully pull the stapler unit out. Press the release button for the staple cartridge. Remove the staple cartridge from its holder. Di470 7-51...
  • Page 316 Place the staple cartridge back into the holder. The staple cartridge locks into place with an audible click. Carefully push the stapler unit back in. Close the front door of the finisher. Slide the finisher carefully back to the copier. 7-52 Di470...

  • Page 317: Finisher Fn-105

    Open the cover (FN7) on the right side of the finisher. Rotate the green dial to the left. This moves the staple units to the middle. Pull the two staple units carefully from the holders. Di470 7-53...
  • Page 318 Replace the staple units in the holders. The staple units click into the holders with an audible click. Close the cover (FN7) on the right side of the unit. Slide the finisher carefully back to the copier. 7-54 Di470...

  • Page 319: Finisher Fn-106

    Rotate the green dial on the right side of the finisher to the left. This moves the staple unit to the middle. Pull the staple unit carefully from the holder. Lift the staple guide. Pull a set of staples out. Di470 7-55...
  • Page 320 Troubleshooting Lower the staple guide of the staple unit. Position the staple unit back in the holder. The staple unit clicks into the holder with an audible click. Slide the finisher carefully back to the copier. 7-56 Di470...

  • Page 321: Mailbin Finisher Fn-503

    (FN1). Pull out any remaining copy paper. Close the cover (FN1). Push and hold the button. While holding it, turn it counterclockwise to open the cover of the stapler unit. Lift the stapler unit out of its bay. Di470 7-57...
  • Page 322 Position the staple cartridge into the staple unit. The staple unit clicks into the holder with an audible click. Align the arrows on the stapler unit to those on the finisher. Position the staple unit back in the holder bay. 7-58 Di470...
  • Page 323 The copier runs about 10 test staple cycles without setting ay staples. During this, the stack of paper is aligned based on the required stapling position. Di470 7-59...

  • Page 324: These Functions Cannot Be Combined

    “Z-Fold”.) If an FN-105, FN-106 or FN-503 finisher is installed, this combination is only possible if the original pages have varying widths and “Auto Paper Mode” is enabled. (“Staple” is automatically disabled.) 7-60 Di470...
  • Page 325 The combination is only possible if the Finisher FN-5 is installed. If an FN-105, FN-106 or FN-503 finisher is installed, the function enabled last is given priority. The function that was activated last has priority. (“Centre Staple” is enabled automatically.) The “2-Point Staple” function is enabled automatically. – No effect. Di470 7-61...

  • Page 326: Basic Settings

    • Page Arrangement – • Corner Staple • Cover • 2-point staple • Page Insertion • Centre Staple • OHP Interleaving × • Punching • Image Stamping × • Crease • Reserve Copy Job – • Image Memory Input × 7-62 Di470...
  • Page 327 × • 1:1 × • Single 2in1/4in1 • Modified Zoom Factor × • Double 2in1/4in1 • Zoom Memory Input × • Booklet • Zoom Factor from × • Reserve Copy Job – Numeric Keypad • Image Memory Input Di470 7-63...
  • Page 328 • Crease × • Single Feed Tray - Card/ • Booklet Vellum • OHP Interleaving • Single Feed Tray - Small • Image Repeat × Sizes • Document Handler × • Centre Staple • Reserve Copy Job – 7-64 Di470...
  • Page 329 • Image Repeat × • Auto Size Mode • Mixed Original • X/Y Zoom Detection × • Centre Staple • Document Handler – • Crease × • Reserve Copy Job • Half Fold × • Loading onto the Original Glass Di470 7-65...

  • Page 330: Orig.>Copy Settings

    • Page Arrangement – • Original: Book × • Image Repeat × • Copy: 1-sided × • Mixed Original • Copy: 2-sided × Detection × • Double 2in1/4in1 × • Document Handler – • Booklet × • Reserve Copy Job 7-66 Di470...
  • Page 331 • Page Insertion • Original: 1-sided × • Edge/Frame Erase • Original: 2-sided × • Image Repeat × • Single 2in1/4in1 × • Document Handler × • Double 2in1/4in1 × • Reserve Copy Job – • Image Memory Input × Di470 7-67...
  • Page 332 • Half Fold • Edge/Frame Erase • Z-Fold • Image Repeat × • Original: 1-sided × • Document Handler × • Original: 2-sided × • Reserve Copy Job – • Copy: 1-sided × • Image Memory Input × 7-68 Di470...

  • Page 333: Auxiliary Functions

    • Crease File Margin • Half Fold • Document Handler × • Image Repeat × • Reserve Copy Job – Edge/Frame • Original: Book × • Page Arrangement – Erase • Book Erase – • Reserve Copy Job – Di470 7-69...
  • Page 334 • Reserve Copy Job – • Image Repeat × • Reserve Copy Job – • Non-sort • Image Repeat × • Group • Reserve Copy Job – • OHP Interleaving Image • Image Repeat × Stamping • Reserve Copy Job – 7-70 Di470...

  • Page 335: Other

    • Reserve Copy Job • Punching • Image Memory Input Reserve • Single Feed Tray • Image Memory Input Copy Job • OHP Interleaving Loading • Page Insertion • Reserve Copy Job – onto the • Document Handler × Original Glass Di470 7-71...
  • Page 336 • File Margin – • Punching – • Edge/Frame Erase – • Crease – • Image Repeat – • Half Fold – • Number Stamping – • Z-Fold – • Document Handler – • Reserve Copy Job – 7-72 Di470...

  • Page 337: Appendix

    Shut off the copier with the power switch before cleaning the unit. Cleaning Clean the copier as described below. Housing clean with a soft cloth dampened with mild detergent. Original Cover clean with a soft cloth dampened with mild detergent. Di470...
  • Page 338 Appendix Control Panel and Touch Screen clean with a soft dry cloth. Original Glass Original Glass clean with a soft dry cloth. Front Door clean with a soft dry cloth. Di470...

  • Page 339: Cleaning The Automatic Document Feeder

    Cleaning the Automatic Document Feeder Open the automatic document feeder. Clean the original pad with a soft cloth dampened with mild detergent. Clean the surface of the guide plate and polyester film with a soft dry Document cloth. Guide Plate Polyester Film Di470...

  • Page 340: Cleaning The Corona Units

    Carefully pull the lower corona unit cleaner out as far as it will go. Push the corona unit cleaner back fully. Repeat the complete cleaning process two or three times. Copier Maintenance For further information, consult your technical representative. Di470...

  • Page 341: Specifications

    Appendix Specifications Copier Di470 Specifications Type Copier/Printer Original Glass Stationary Photoconductor Copying System Electrostatic Dry Powdered Image Transfer to Plain Paper Developing System Micro-Toning System Fusing System Lamp-Heated Roller Resolution 600 dpi Types of Original Single sheets, books and other three-dimensional...

  • Page 342: Paper Feed Unit Pf-208

    A3 L to A4 L Capacity • 3rd Paper Drawer 500 sheets (80 g/m • 4th Paper Drawer 500 sheet (80 g/m Power Requirements supplied from copier Dimensions • Width: 664 mm • Depth: 730 mm • Height: 388 mm Weight 45.5 kg Di470...

  • Page 343: Duplex Unit Pf-7D

    Specifications Paper Types Plain Paper (60 g/m˛ to 90 g/m˛), Recycled Paper Paper Size Duplex Unit:A3L to A5L Power Requirements supplied from copier Dimensions • Width: 664 mm • Depth: 730 mm • Height: 388 mm Weight 37.5 kg Di470...

  • Page 344: Electronic Document Handler Edh-3

    A3 L to A5 L Capacity up to 100 sheets (80 g/m Power Requirements supplied from copier Current Consumption 72 W or less Dimensions • Width: 662 mm • Depth: 579 mm • Height: 139 mm Weight 13 kg Di470...
  • Page 345 1,111 mm Weight 94.2 kg Options 1 staple holder with 5,000 staples/holder Finisher FN-5 and the auto dual function! If the auto dual function is enabled, output is automatically distributed to the trays. For more information, see page 4-27. Di470...
  • Page 346 • Punching 4-point punching Power Requirements supplied from copier Current Consumption 63 W or less Dimensions • Width: 538 mm • Depth: 629 mm • Height: 978 mm Weight 39.2 kg Options 2 staple holders with 5,000 staples/holder 8-10 Di470...
  • Page 347 • Number of copies 2 to 30 sheets (80 g/m Power Requirements supplied from copier Current Consumption 63 W or less Dimensions • Width: 538 mm • Depth: 629 mm • Height: 978 mm Weight 35.5 kg Options 1 staple holder with 3,000 staples/holder Di470 8-11...

  • Page 348: Mailbin Finisher Fn-503

    • plain paper (80 g/m 200 sheets/tray recycled paper Stapling • Paper size A3 L to A4 • Number of copies 2 to 50 sheets (80 g/m Punching • Paper size A3 L to A4 • Punching 4-point punching 8-12 Di470...

  • Page 349: Paper Feed Unit C-306L

    A4 L, A4 C, Legal L, Letter L, Letter C Capacity 3,000 sheets (80 g/m Power Requirements supplied from copier Current Consumption 40 W or less Dimensions • Width: 440 mm • Depth: 446 mm • Height: 491 mm Weight 16.4 kg Di470 8-13...

  • Page 350: Paper Size Tables

    210 x 301 mm Letter 8-1/2" x 11" 216 x 279 mm Government 8" x 10-1/2" 203 x 267 mm Letter Quarto 8" x 10" 203 x 254 mm Statement Invoice 5-1/2" x 8-1/2" 140 x 216 mm 8-14 Di470...

  • Page 351: Zoom Factor Tables

    1.640 x 1.224 x 1.154 x 0.707 x 1.414 x 0.866 x 0.816 x 1.414 x 1.640 x 2.000 x 1.154 x 1.733 x 2.000 x 1.224 x 1.414 x 2.000 x 1.414 x 1.733 x 1.224 Inch Di470 8-15...
  • Page 352 0.500 Legal x 1.545 11" x 14" Legal x 0.772 Foolscap x 1.529 Foolscap x 0.772 Letter x 1.294 Letter x 0.772 Invoice x 0.500 Legal Legal x 0.928 Foolscap x 0.785 Letter x 0.607 Invoice x 1.214 8-16 Di470...

  • Page 353: Ce Marking (Declaration Of Conformity)

    Incorrect cable types can cause interference to radio communications! This device may only be operated when equipped with shielded interface cables. The use of other cable types can impair radio communications. According to EC guidelines, this is not permitted. § Use only shielded interface cables. Di470 8-17...

  • Page 354: Certifications On The Manufacturer's Name Plate

    Appendix Certifications on the Manufacturer's Name Plate Certifications are printed on the Manufacturer's Name Plate for the copier. The certifications are defined as follows: Di470 220-240 50-60 1560-1700 N87/Z132 MINOLTA CO.,LTD MADE IN CHINA Item Name Meaning The certification office confirms the observance of all legally mandatory European EMC standards that apply to this device.

  • Page 355: Directory Of Abbreviations

    For example Electronic Document Hander – Automatic Document Feeder (see ADF) Electromagnetic compatibility Foolscap Tested safety Lengthwise, e.g. A4 L Man. Manual Overhead projector Single Document Feeder – Single Automatic Document Feeder TÜV German technical control board Di470 8-19...

  • Page 356: Index

    Auto Shut Off ..............3-26 6-30 6-49 Auto Size ................... 4-8 6-24 Automatic Document Feeder ............3-8 Automatic reset ................. 3-26 Auxiliary functions ..............4-64 7-69 Back cover ..................4-65 Basic drawers ................... 2-35 Basic settings ................... 7-62 Basics ....................4-1 8-20 Di470...
  • Page 357 ..................2-23 Copier maintenance ................8-4 Copy cycle interrupt ..................3-6 start ....................3-6 stop ....................3-7 Copy density ..................4-60 Copy job program check .....................6-4 delete .....................6-7 recall ....................6-6 store ....................6-1 Copy limits ..................6-41 Copy Mode ................4-48 4-51 Copy start, automatic ................3-26 Di470 8-21...
  • Page 358 Duplex Cabinet ................. 2-10 Edge/frame erase ................4-76 Electronic Document Handler ............. 2-5 Energy Save Mode ..............3-26 6-30 Environmental protection ..............1-2 Environmental requirements ............. 2-23 Errors ..................7-1 Exposure ................... 6-33 Exposure fine adjustment ..............6-26 8-22 Di470...
