SETUP INSTRUCTIONS

Di200f/Di251f/Di351f

NOTE

• Keep all packing materials out of the reach of children.

• Before setting up, be sure to unplug the power cord of the copier.

4011-7747-02

Printed in China

Need help?

Do you have a question about the Di200f and is the answer not in the manual?

Questions and answers

Summary of Contents for Minolta Di200f

Page 1 Return to SubMenu SETUP INSTRUCTIONS Di200f/Di251f/Di351f NOTE • Keep all packing materials out of the reach of children. • Before setting up, be sure to unplug the power cord of the copier. 4011-7747-02 © MINOLTA CO., LTD. Printed in China...
Page 2 Di200f/Di251f standard equipment. • The Di251f/Di351f copier is provided with two drawers. • The Di200f copier is provided with a single drawer. 4011U017AC I Removing the Tapes and Cushions from the Copier 1. Peel off all the tapes and cushions from the copier.
Page 3 Di200f/Di251f/Di351f 2. Remove the cap and the Rear Upper Cover <For Di251f, Europe areas only> (two screws). NOTE DO NOT remove the cushion (shaded part in the illustration). Cushion 4011U038CA 4011U001AA 3. Remove the fixing bracket shown. 4011U002AA 4. Turn the fixing bracket which has been removed and reinstall it.
Page 4 Di200f/Di251f/Di351f I Installing the Imaging Unit 2. Remove two pieces of tape and sponge Tape NOTE (rear) as shown in the figures. Always keep the imaging unit in horizontal position when handing it. 1. Remove the imaging unit from the box and check that it contains the following items.
Page 5 Di200f/Di251f/Di351f I Installing the Toner Bottle 5. Align, the green labels on both ends of the 1. Open the Toner Bottle Cover. new imaging unit with the green labels on the NOTES rails of the copier and position the imaging •...
Page 6 Di200f/Di251f/Di351f I Installing the Manual Holder <For the Copier> 5. With the “UP” making on top, insert and push Mount the Quick Guide Holder as shown. the Bottle into position. NOTE NOTE The mounting location diffes according to Push the Bottle up to the black line on it.
Page 7 Di200f/Di251f/Di351f I Paper Loading for 1st Drawer 6. Touch the 1st Drawer key and then touch 1. Slide out the 1st Drawer. “Mode Change.” 4011U024AA 4011P283CA 2. Press the Paper Lifting Plate down until it 7. Touch the key of the desired paper size.
Page 8 Di200f/Di251f/Di351f I Paper Loading for 2nd Drawer NOTE NOTE If you want to change the paper size, first carry out the “Changing the Paper Size of The paper should be loaded no higher than the M (Max. Level Indicator). the 2nd Drawer” procedure explained in the next page.
Page 9 Di200f/Di251f/Di351f I &KDQJLQJ WKH 3DSHU 6L]H RI WKH 3DSHU )HHG 8QLW (Fixed Cassette) :KLOH SUHVVLQJ WKH VWRSV LQ WKH GLUHFWLRQ RI WKH DUURZV DV VKRZQ LQ WKH ILJXUH SXOO RXW 5HIHU WR WKH IROORZLQJ FKDUW DQG UHSODFH WKH...
Page 10 Di200f/Di251f/Di351f I Paper Size Input for the Fixed Cassette (For the 2nd Drawer only) 6. Touch “END.” 1. Access the service mode screen. (Refer to the service manual.) 2. Touch “System Input.” 4011P272CA 4015P513CB 7. Touch “Panel reset” to display the service 3.
Page 11 Di200f/Di251f/Di351f I Auto Shut OFF Setting (For Switzerland only) 5. Set the time for 30 min 1. Press the “Utility” key. Utility using the 10-key pad. 1171U024CA 6. Touch the “Enter” key. 2. Touch the “User’s Choice” key. 1171U025CA 4015P509CA 7.
Page 12 Di200f/Di251f/Di351f I Time/Date Setting 4. Touch “Service Call Report.” 1. Call the Initial mode to the screen. (Refer to the Service Manual for the procedure.) Then, the list will be produced. 2. Touch “Date Time Set.” • Keep the produced list for later use.
