This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you're unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Built-In Heated Wells
HWB Series
Installation &
Operating Manual
I&W #07.05.167.00
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
Advertisement
Table of Contents
Related Manuals for Hatco HWB Series
Summary of Contents for Hatco HWB Series
- Page 1 Built-In Heated Wells HWB Series Installation & Operating Manual I&W #07.05.167.00 Este manual contiene importante información sobre This manual contains important safety information seguridad concerniente al mantenimiento, uso y concerning the maintenance, use and operation of this operación de este producto. Cualquier falla en el product.
-
Page 2: Table Of Contents
All units are equipped with EZ lock mounting hardware. Controls include individual lighted power Hatco Built-In Heated Wells are a product of switches and thermostat controls which retain extensive research and field testing. The materials settings. One year parts and on-site labor warranty used were selected for maximum durability, is standard. -
Page 3: Important Safety Information
Risk of fire, install Built-In Heated Well not have the characteristics that will allow a minimum of 3-1/2" (89 mm) from all com- them to operate safely in Hatco equipment. It bustible surfaces per assembly instructions. is essential to use Hatco Replacement Parts when repairing Hatco equipment. -
Page 4: Specifications
The remote mounted control panel should be and similar products caused by heat generated installed outside of the heat zone. Locating the from Hatco equipment is not covered under the control panel inside the heat zone will cause the Hatco warranty. Contact the manufacturer of the control(s) to overheat, malfunction, and fail. - Page 5 SPECIFICATIONS ELECTRICAL RATING CHART (CONTINUED) Model Voltage Watts Amps Phase Shipping Weights HWBL-43 30 lbs. (14 kg) HWBL-43D 30 lbs. (14 kg) HWB-7QT 10 lbs. (5 kg) 10 lbs. (5 kg) 10 lbs. (5 kg) 10 lbs. (5 kg) HWB-7QTD 10 lbs.
-
Page 6: Dimensions
SPECIFICATIONS DIMENSIONS Width Depth Height Model HWB-FUL 13-3/4" 21-3/4" 8-5/8" (349 mm) (552 mm) (219 mm) HWB-FULD 13-3/4" 21-3/4" 8-5/8" (349 mm) (552 mm) (219 mm) HWBH-FUL 13-3/4" 21-3/4" 8-5/8" (349 mm) (552 mm) (219 mm) HWBH-FULD 13-3/4" 21-3/4" 8-5/8" (349 mm) (552 mm) (219 mm) - Page 7 SPECIFICATIONS Diameter Height Model HWB-7QT 10-3/8" 8-3/8" (264 mm) (213 mm) HWB-7QTD 10-3/8" 8-3/8" (264 mm) (213 mm) HWBH-7QT 10-3/8" 8-3/8" (264 mm) (213 mm) HWBH-7QTD 10-3/8" 8-3/8" (264 mm) (213 mm) Figure 3. Dimensions – HWB-7QT, HWB-7QTD, HWBH-7QT & HWBH-7QTD Diameter Height Model...
-
Page 8: Model Designation
• Four 1/3 size pans with Adapter bars. countertops using optional Hatco mounting kits. Built-In Heated Wells are designed, manufactured, • Two 1/2 size pans and one 1/3 size pan with and tested to maintain safe food holding Adapter bars. - Page 9 3/4" NPT drain fitting and flat drain screen that allows for pans to stay level for consistent that allows for pans to stay level for consistent temperatures. temperatures. HEA TED WE HEA TED WE HATCO CORP. MILWA HATCO CORP. MILWA UKEE , WI U.S.A. UKEE , WI U.S.A.
-
Page 10: Installation
LOCATION and similar products caused by heat generated NOTE: A qualified electrician is recommended for from Hatco equipment is not covered under the connecting the Built-In Heated Well units to a power Hatco warranty. Contact the manufacturer of the source. - Page 11 INSTALLATION Installing Unit into Combustible Countertop WARNING To avoid any injury or damage Hatco mounting kits must be used when mounting unit in a combustible countertop. Mounting Flange Tabs NOTE: Cut opening for both the unit and control panel before placing unit into countertop opening.
- Page 12 INSTALLATION Installing Unit into Non-Combustible Countertop Countertop NOTE: Mounting flange kit is not required for installation into non-combustible material. NOTE: Cut opening for both the unit and control panel before placing unit into countertop opening. 1. Cut appropriate opening in countertop. (See Figure 11 for size requirements.) 2.
- Page 13 INSTALLATION Combustible Countertop Cutout Model Minimum Width Maximum Width Minimum Depth Maximum Depth HWB-FUL 14" 14-1/4" 22" 22-1/4" HWB-FULD (356 mm) (362 mm) (559 mm) (565 mm) HWBH-FUL HWBH-FULD HWBL-FUL HWBL-FULD HWB-43 14" 14-1/4" 29" 29-1/4" HWB-43D (356 mm) (362 mm) (737 mm) (743 mm) HWBH-43...
- Page 14 INSTALLATION Non-Combustible Countertop Cutout Model Minimum Width Maximum Width Minimum Depth Maximum Depth HWB-FUL 12-5/8" 12-7/8" 20-5/8" 20-7/8" HWB-FULD (321 mm) (327 mm) (524 mm) (530 mm) HWBH-FUL HWBH-FULD HWBL-FUL HWBL-FULD HWB-43 12-3/4" 13" 27-7/8" 28-1/8" HWB-43D (324 mm) (330 mm) (708 mm) (714 mm) HWBH-43...
- Page 15 INSTALLATION Remote Mounted Control Panel 1. Remove trim cover from control panel assembly. 2. Position control panel into opening through the WARNING backside. For proper and safe operation the remote control panel location must be mounted on a 3. Secure control panel to surface using screws vertical wall.
- Page 16 INSTALLATION TOP VIEW Cutout Screw Hole Dimension Dimension 5-7/8" 3-7/8" (149 mm) (98 mm) 6-3/8" 6-13/16" (162 mm) (173 mm) Control Panel Mounting Figure 12. Remote Mounted Control Panel Form No. HWBM-0206...
-
Page 17: Drain Assembly Models
INSTALLATION DRAIN ASSEMBLY MODELS WARNING The drain water may reach temperatures in excess of 200° (93°C). To avoid any injury or damage to the unit use appropriate plumbing materials when installing drain. Drain Assembly (See Figure 13) After installing unit in countertop, install the drain assembly as follows: Note: For proper drain plumbing installation to Drain... -
Page 18: Maintenance
Hard to reach areas should characteristics that will allow them to operate be cleaned with a small brush and mild soap. safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco CAUTION equipment. Failure to use Hatco Replacement Use only non-abrasive cleaners. -
Page 19: Hatco Limited Warranty
One (1) Year Parts and Labor PLUS Four accept or reject any such claim in whole or in part. (4) Years Parts-Only Warranty on Hatco will not accept the return of any Product pro-rated terms that Hatco will explain without prior written approval from Hatco, and all at Buyer’s request:... -
Page 20: Authorized Parts Distributors
HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK TEXAS ALABAMA INDIANA Acme American Repairs, Inc. Stove Parts Supply Jones McLeod Appl. Svc. GCS Service Fort Worth 817-831-0381 Birmingham 205-251-0159 Indianapolis 317-545-9655 Brooklyn 718-456-6544 Armstrong Repair Service IOWA Alpro Service Co. ARIZONA Houston...
