Instructions/Parts List
High Sanitation Pumps
For use in sanitary applications.
Models 1590 & 3150 SA__ Sanitary Diaphragm Pump
Models 1590 & 3150 SB__ Sanitary Ball Check Pump
Model 3150 SF__ Sanitary Flapper Check Pump
120 psi (0.8 MPa, 8 bar) Maximum Fluid Working Pressure
120 psi (0.8 MPa, 8 bar) Maximum Air Input Pressure
Important Safety Instructions.
Read all warnings and instructions in
this manual. Save these instructions.
See page 2 for Table of Contents.
US and Foreign Patents Pending
US Patent No. 5,368,452
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2004, Graco Inc. is registered to I.S. EN ISO 9001
II 2 G c T6
Model SA3AAA Shown
310622L
44-03
II 2 G c T6
TI8760a

Advertisement

Table of Contents
loading

Related Manuals for Graco 1590 SA

Summary of Contents for Graco 1590 SA

  • Page 1 Instructions/Parts List High Sanitation Pumps For use in sanitary applications. Models 1590 & 3150 SA__ Sanitary Diaphragm Pump Models 1590 & 3150 SB__ Sanitary Ball Check Pump Model 3150 SF__ Sanitary Flapper Check Pump 120 psi (0.8 MPa, 8 bar) Maximum Fluid Working Pressure 120 psi (0.8 MPa, 8 bar) Maximum Air Input Pressure Important Safety Instructions.

  • Page 2: Table Of Contents

    Contents Contents Warning ........3 Installation ....... . 5 Operation .

  • Page 3: Warning

    Warnings The following general warnings are for the safe setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbols alert you to general warnings and the hazard symbols refer to procedure-specific risks. Refer back to these Warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
  • Page 4 Warning BURN HAZARD Equipment surfaces and fluids that are heated can become very hot during operation. To avoid severe burns, do not touch hot fluid or equipment. Wait until equipment/fluid has cooled completely. PERSONAL PROTECTIVE EQUIPMENT You must wear appropriate protective equipment when operating, servicing, or when in the operating area of the equipment to help protect you from serious injury, including eye injury, inhalation of toxic fumes, burns, and hearing loss.

  • Page 5: Installation

    Installation General Information • The typical installation shown in F guide for selecting and installing system compo- nents. Contact your Graco distributor for assistance in planning a system to suit your needs. • Always use genuine Graco parts and accessories. •...
  • Page 6 Installation Ground Wire Connection • Air and fluid hoses: Use only grounded hoses with a maximum of 500 ft (150 m) combined hose length to ensure grounding continuity. • Air compressor: Follow the manufacturer’s recom- mendations. • Fluid supply container: Follow the local code. Mountings CAUTION The pump exhaust air may contain contaminants.
  • Page 7 4. At inlet fluid pressures greater than 15 psi (0.1 MPa, 1 bar), diaphragm life will be shortened. Fluid Outlet Line A fluid drain valve (J) is required to relieve pressure in the hose if it is plugged. The drain valve reduces the risk of serious injury, including splashing in the eyes or on the skin, or contamination from hazardous fluids when relieving pressure.
  • Page 8 Installation Changing the Orientation of the Fluid Inlet and Outlet Ports The pump is shipped with the ports facing the same direction. To re-orientate the ports into any position: 1. Remove the clamps (130) holding the inlet and/or outlet tee to the elbows. 2.
  • Page 9 . 5 Venting Exhaust Air 310622L Installation Key: Air supply line Bleed-type master air valve (required for pump) Air regulator Air line quick disconnect Master air valve (for accessories) Air line filter Muffler Grounded air exhaust hose Container for remote air exhaust TI8767a...

  • Page 10: Operation

    Operation Operation Pressure Relief Procedure 1. Shut off the air to the pump. 2. Open any available outbound fluid valve to relieve fluid pressure from the pump. 3. If fluid is still in the outbound fluid lines, isolate this fluid as follows: a.

  • Page 11: Maintenance

    Maintenance Lubrication The air valve is designed to operate unlubricated, how- ever if lubrication is desired, every 500 hours of opera- tion (or monthly) remove the hose from the pump air inlet and add two drops of machine oil to the air inlet. CAUTION Do not over-lubricate the pump.
  • Page 12 Maintenance Preventive Maintenance Schedule Establish a preventive maintenance schedule based on the pump’s service history. This is especially important for prevention of spills or leakage due to diaphragm failure. Operator Task Inspect system for leaks Depressurize fluid, after operation Remove heat from system, after operation Inspect diaphragm for wear Inspect check valve compo-...
  • Page 13 Maintenance 310622L...

  • Page 14: Troubleshooting

    Troubleshooting Troubleshooting • Relieve the pressure before checking or servicing the equipment. • Check all possible problems and causes before disassembling the pump. PROBLEM Pump cycles at stall or fails to hold pressure at stall. Pump will not cycle, or cycles once and stops.
  • Page 15 PROBLEM Leak in inlet or outlet sanitary fit- ting. Fluid in exhaust air. Pump exhausts excessive air at stall. Pump leaks air externally. Pump leaks fluid externally from ball check valves. Chattering. 310622L CAUSE Loose sanitary clamp. Damaged or worn gasket. Misalignment of inlet/outlet hose or pipe.

  • Page 16: Service

    Service Service Repairing the Air Valve Tool Required • Torque wrench • Torx (T20) screwdriver or 7 mm (9/32 in.) socket wrench • Needle-nose pliers • O-ring pick • Lithium base grease Air Valve Repair Kit 255122 is available. Refer to Parts on page 31.
  • Page 17 5. Inspect the valve plate (108) in place. If damaged, use a Torx (T20) screwdriver or 7 mm (9/32 in.) socket wrench to remove the three screws (103). Remove the valve plate (108). See F 6. Inspect the bearings (112, 117) in place. See Parts on page 31.
  • Page 18 Service 8. Install the valve carriage (105) so its tabs slip into the grooves on the narrow end of the actuator pis- tons (111). See F . 11. ◆ . 11 9. Align the valve gasket (104) and cover (102) with the six holes in the center housing (101).
  • Page 19 Check Valve Repair Disassembly Reference numbers with an asterisk (*) are replacement parts. For a complete list of replace- ment parts see Parts, page 26. 1. Relieve the pressure. Disconnect all hoses. 2. Remove the pump from its mounting. Drain. 3.
  • Page 20 Service For Sanitary Ball Check pumps: remove ball gasket (242) and ball (541). Remove lower clamp (132b), seat (233), and gasket (240). Clean all parts and inspect for wear or damage. Replace parts as needed. 132a *242 129* *541 339* *240 132b Sanitary Ball Check Assembly...
  • Page 21 7. Repeat for inlet manifold. Reassembly Lubricate clamps, clamping surfaces, and gaskets with waterproof, sanitary lubricant. 1. Reassemble inlet and outlet fluid manifolds in reverse order. See step 6. Tighten clamps handtight. 2. Reassemble ball or flapper check assembly in reverse order.
  • Page 22 Service 446* Sanitary Pump 446* 3A Pump . 17 7. Pull the other diaphragm assembly and the dia- phragm shaft (121) out of the center housing (101). Hold the shaft flats with a 19 mm open end wrench, and remove the diaphragm assembly from the shaft. Disassemble the remaining diaphragm assembly.
  • Page 23 4. Grease the length of the diaphragm shaft (121), and slide it through the housing (101). 5. Assemble the other diaphragm assembly to the shaft as explained in step 2. 6. Non 3A approved diaphragms: Using a 5/8 in. wrench hold the wrench flats of one diaphragm assembly and torque the other diaphragm to 60-70 ft-lb (81-94 N •...
  • Page 24 Service 110* . 22 8. If you removed the diaphragm shaft bearings (117) reach into the center housing (101) with an o-ring pick and hook the u-cups (110), then pull them out of the housing. Inspect the u-cups. See F Replace parts as needed.

  • Page 25: Pump Matrix

    Pump Matrix 3150 Stainless Steel Sanitary Pumps Your Model No. is marked on the pump’s serial plate. To determine the Model No. of your pump from the follow- ing matrix, select the six digits which describe your pump, working from left to right. The first digit is always S, designating Graco Sanitary diaphragm pumps.

  • Page 26: Parts

    Parts Drawing Parts Drawing 3A Pump Shown 129* *240 Sanitary Ball Check Valve Assembly *242 *240 *541 *240 *240 *240 Flapper Check Valve *240 *240 *129 130 339* TI7644a 446* Assembly *240 *250 *253 Apply a high strength thread locker to *240 TI4683a diaphragm plate side of screw threads.

  • Page 27: Parts List

    Parts List Pump Configuration Parts List Digit Ref. Part No. Description Model 3150 3A Approved Ball Check 510490 CLAMP, 4 in. 15H406 SEAT 249533 COVER, fluid 240* 15H460 GASKET, 4 in., EPDM 15H407 STOP, ball Ball Check 15D026 SEAT 234530 COVER, fluid 240* 15H460...
  • Page 28 Parts List Diaphragm Material Parts List Digit Ref. Part Description Model 3150 253224 3A Approved, EPDM, Overmolded; includes 110 and 446 112181 U-CUP 446*† DIAPHRAGM ASSY 2 189298 PLATE, diaphragm (air side) 253225 Santoprene; includes 110, 446 112181 U-CUP 446*† DIAPHRAGM 15D021 BOLT...
  • Page 29 Check Ball Material Parts List Digit Ref. Part Model 3150 3A Approved, PTFE 541*† 112359 Flapper check NONE Santoprene 541*† 112361 BUNA-N 541*† 15B492 fluoroelastomer 541*† 15B491 Model 1590 3A Approved PTFE SABAAA SBBAAA 541*† 112419 SBBA11 Santoprene SBBA22 541*† 112421 * Indicates replacement parts.
  • Page 30 Parts Drawing Parts Drawing Apply medium strength adhesive to outside surface of piston bearing and inside surface of center housing bore. Apply a medium strength thread locker to screw threads and torque to 130-150 in-lbs (14.6-16.9 N•m). Torque to 50-60 in-lb (5.7-6.8 N•m). ◆...
  • Page 31 Parts List Air Section Parts Ref. Part Description 15K010 HOUSING, center 15K697 HOUSING, cover 116344 SCREW, mach, torx 104◆ 188618 GASKET, cover 105◆ 248904 CARRIAGE, manifold assy 108◆ 15H178 VALVE, plate 110◆ 112181 U-CUP, packing 188612 PISTON, actuator 188613 BEARING, piston 188611 BEARING, pin 188610...

  • Page 32: Accessories

    Accessories Accessories 15D990 Leak Detector Sensor and control package that monitors the dia- phragm condition. In case of diaphragm failure, the con- trol will provide an audible alarm and relay contacts for remote alarms or solenoids. See Leak Detector manual 311200.

  • Page 33: Model 1590

    Model 1590 Model 1590 Dimensional Drawing 24.9 in. (632.5 mm) 35.8 in. (909.3 mm) 8.6 in. (218.4 mm) 22.0 in. (558.8 mm) 23.5 in. TI8778a (596.9 mm) TI8777a 310622L...

  • Page 34: Technical Data

    Model 1590 Model 1590 Technical Data Maximum fluid working pressure ....120 psi (0.8 MPa, 8 bar) Air pressure operating range ..... . 20-120 psi (0.14-0.8 MPa, 1.4-8 bar) Maximum air consumption .

  • Page 35: Performance Chart

    Model 1590 Performance Chart Test Conditions: Pump tested in water with inlet submerged To find Fluid Outlet Pressure (psi/MPa/bar) at a specific fluid flow (gpm/lpm) and operating air pressure (psi/MPa/bar): 1. Locate fluid flow rate along bottom of chart. 2. Follow vertical line up to intersection with selected fluid outlet pressure curve.

  • Page 36: Model 3150

    Model 3150 Model 3150 Dimensional Drawing 22.0 in (558.8 mm) Sanitary Ball Check Valve Pumps 28.3 in. (718.8 mm) 6.5 in. (165.1 mm) 19.3 in. (490.2 mm) 3A Ball Check Valve Pumps 28.4 in. (721.4 mm) 6.5 in. (165.1 mm) TI4929d Flapper Check Valve Pumps 29.5 in.

  • Page 37: Technical Data

    Model 3150 Technical Data Maximum fluid working pressure ....120 psi (0.8 MPa, 8 bar) Air pressure operating range ..... . 20-120 psi (0.14-0.8 MPa, 1.4-8 bar) Maximum air consumption .

  • Page 38: Performance Chart

    Model 3150 Model 3150 Performance Chart Test Conditions: Pump tested in water with inlet submerged To find Fluid Outlet Pressure (psi/MPa/bar) at a specific fluid flow (gpm/lpm) and operating air pressure (psi/MPa/bar): 1. Locate fluid flow rate along bottom of chart. 2.
  • Page 39 Model 3150 310622L...

  • Page 40: Graco Warranties

    Graco Warranties Graco Standard Pump Warranty Graco warrants all equipment manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of five years from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
