Instructions
15H883 Crank Arm
Rebuild Kit
To replace crank arm on E-Flo

Important Safety Instructions

Read all warnings and instructions in this manual
and in E-Flo Plus Repair-Parts manual 311594.
Save these instructions.
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001
Plus Electric Circulation Pumps.
311604 rev.A
ti8715a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15H883 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Graco 15H883

  • Page 1 Important Safety Instructions Read all warnings and instructions in this manual and in E-Flo Plus Repair-Parts manual 311594. Save these instructions. ti8715a Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001...
  • Page 2 (3). tion before pressurizing system again. Kit Parts Crank Arm Rebuild Kit 15H883 includes parts to rebuild one crank arm assembly. Order two kits to rebuild both crank arm assemblies. Parts included in the kit are marked with an asterisk, for example (4*).
  • Page 3 Kit Installation 5. Place a clean rag over the top of the slider cylinder (2) to prevent debris from falling into the slider assembly during disassembly. 6. Place a 3/4 in. wrench on the slider piston (9) flats (just above the coupling nut), to keep the slider pis- ton/connecting rod from turning when you are loos- ening the coupling nut (14).
  • Page 4 Kit Installation Reassembly 5. See F . 6. Place a clean rag over the top of the slider cylinder (2) to prevent debris from falling into the slider assembly during reassembly. 1. Assemble the crank arm (4*) to the connecting rod (7) with two retaining rings (6*), oriented as shown.
  • Page 5 Kit Installation Notes 311604A...
  • Page 6 With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
