Instructions - Parts List
SaniForce
Diaphragm Pumps
1040, 1590, and 2150 Models
For use in sanitary applications. For professional use only.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
120 psi (0.8 MPa, 8 bar) Maximum Fluid Working Pressure
120 psi (0.8 MPa, 8 bar) Maximum Air Input Pressure
1040 Models
™
TI8924a
1590 Models
Refer to the appropriate Pump Matrix on page 26, 34,
or 42 to determine the model number of your pump.
See page 3 for approval information.
TI8926a
2150 Models
311879ZAC
EN
TI8928a
