Summary of Contents for Batribike Diamond
- Page 1 Diamond Granite Owner Manual LS Models...
- Page 2 IMPORTANT PLEASE READ THIS MANUAL FULLY PRIOR TO ASSEMBLY AND USE For your safety and to ensure a long and trouble free life of your Batribike bicycle, check the operation of brakes, lights, bell and gears, and check tyre pressures are correct.
-
Page 3: Table Of Contents
Thank you for purchasing a BATRIBIKE Electric Bicycle With care and correct usage your bicycle will give many years of service. Important PLEASE CHARGE THE BATTERY BEFORE FIRST USING THE BICYCLE Even though the battery indicator will show charge this cannot be relied upon until the battery has had the initial full charge. -
Page 4: Parts Identification
PARTS IDENTIFICATION We continually strive to ensure that we provide you with the best possible products, therefore SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE LED Display Battery Chain Guard Thumb Throttle Battery Power Plug Seat Height Adjuster Rear Brake Lever Charging Socket Suspension Seat Post Front Brake Lever... -
Page 6: Battery Charging
CHARGING THE BATTERY The battery can be charged on or off the bike. Securing Tab To remove the battery, unplug the battery from the bike. (Blue Plug). (To remove the Blue Plug slide the silver locking tab backwards and rotate the plug anti-clockwise, then pull out of the socket). - Page 7 It is perfectly acceptable to recharge the battery after a short ride so that the battery is fully charged before the next ride. If your BATRIBIKE is not in use for an extended period it is imperative that you charge the battery before storage and then charge the battery once a month to prevent deterioration.
-
Page 8: Using The Power Assistance
Usage Your BATRIBIKE Electric Bicycle can be used as a normal pedal bicycle by simply not switching on the battery. ELECTRIC BICYCLE FUNCTIONS Switching On To use under electric power, plug in the battery with the blue plug located on the end of the battery beneath the rear of the seat. - Page 9 Battery Meter The LED shows the charge remaining in the battery in the upper right of the display. The indicators will gradually go out as the battery power is used up. Refer to the table below for details. BATTERY METER DISPLAYS THE CHARGE REMAINING IN THE BATTERY SYMBOL CHARGE SYMBOL...
- Page 10 Pedal Assistance There are 3 levels of pedal assistance from the motor. Using the ASSIST button you can select from ASSIST L (Low) M (Medium) and H (High). Pressing the button will scroll through the levels. Pressing the ASSIST button when in H (High) mode will return to L (Low) assist. The motor will then be activated upon pedalling.
- Page 11 If you plug in the battery but do not press the power button on the display your Batribike will now act and feel like a normal bicycle. This is useful when you are feeling fit at the start of a journey or using your bike for exercise purposes.
- Page 12 Using the Throttle - Country Specific The throttle is available all the time the power is switched on at the handlebar display. The throttle can be used whilst pedalling in any of the assist modes to give extra help as required. The throttle is not limited by the assistance level selected and is available to give up to maximum power at all times.
-
Page 13: Standard Bicycle Functions
BS EN15194 Compliance The BATRIBIKE LS range conforms to BS EN15194. For the British market, the addition of a throttle control has rendered this not compliant in some countries. ● You are recommended to seek advice from the relevant authorities in the country you are visiting before travelling. - Page 14 Lights Lights are provided on your BATRIBIKE bicycle. These are power efficient LED units which achieve a long life on each set of batteries. SAFETY FEATURE - The power for the front and rear lights is kept separate from the main power supply so that in the event that the battery is exhausted you will still have lights for safety.
- Page 15 Centre Stand (where fitted) To put the bicycle on its stand:- 1) While holding the bicycle upright, place your foot behind the stand. 2) Pull the bicycle backwards until the stand is in place. Make sure bicycle is on solid ground. Side Stand (where fitted) To put the bicycle on its stand:- 1) While holding the bicycle upright, push the stand to its full...
-
Page 16: Adjusting The Handlebars
Quick Release fittings for Seat Height Adjustment With the locking lever in the loose position, tighten the nut until finger tight. The final tightening is done by moving the lever to the locked position. To undo move the lever to the loose position to enable height adjustment. Loose Locked Adjusting the Handlebars... - Page 17 The luggage rack provided is designed to carry a maximum load of 25kg. Make sure that any items carried are securely strapped and nothing is able to get caught in the rear wheel. All other operation of your BATRIBIKE Electric Bicycle is as per a normal pedal cycle. Battery Fuse If the battery will not operate or charge correctly, firstly check the battery fuse (rated 30A) located on the side of the battery beneath the screw cover.
-
Page 18: Maintenance Schedule
Beyond this manual, it is good to consult your BATRIBIKE dealer for advice if you are at all unsure about any of the procedures described. Normal maintenance is not covered under the warranty and this service may be chargeable. -
Page 19: Removing The Front Wheel
● Hub motor and general inspection We recommend you arrange to have a thorough inspection of your bicycle by a BATRIBIKE dealer. This includes opening up the hub motor to inspect and lubricate the gears. Tyre Pressures The tyres should be pumped up to within the range stated on the sidewall. -
Page 20: Warranty
Compensatory costs arising from damages or accidents. ● Cost incurred by loss of the bicycle’s usage. Brake blocks/pads, tyres, lights and cables etc. are considered as consumables and replacements are available from BATRIBIKE or may be obtained from your local cycle shop. - Page 21 Your Local Authority should have the necessary facilities in place. If you prefer you may take your original battery to BATRIBIKE for recycling. Never dispose of batteries in a fire or subject to puncture or crushing.
- Page 22 DIAMOND LS Technical Specifictaion...
- Page 23 GRANITE LS Technical Specifictaion...
- Page 24 BATRIBIKE Electric Bicycles are exclusive to:- Fallowgate Limited Kellaway House Marton Road Sturton-by-Stow BATRIBIKE are Lincoln Full Members of LN1 2AH the British Electric Phone: 01427 787774 Bicycle Association E-mail: support@batribike.com ----- USER MANUAL LS Models 2012 - ISSUE 1 - ©2012 Fallowgate Limited -----...
