  • Page 1 TRIKE 20 (TILTING) TRIKE-R (RIGID) Owner Manual Tricycle Range...
  • Page 2 DATATAG ETCH NUMBER:- IMPORTANT PLEASE READ THIS MANUAL FULLY BEFORE USE For your safety and to ensure a long and trouble free life of your Batribike bicycle, check the operation of brakes, lights, bell and gears, and check tyre pressures are correct.

  • Page 3: Table Of Contents

    Thank you for purchasing a BATRIBIKE Electric Tricycle With care and correct usage your tricycle will give many years of service. Important PLEASE CHARGE THE BATTERY BEFORE FIRST USING THE TRICYCLE Even though the battery indicator will show charge this cannot be relied upon until the battery has had the initial full charge.

  • Page 4: Parts Identification

    PARTS IDENTIFICATION We continually strive to ensure that we provide you with the best possible products, therefore SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Display Front Mesh Basket Thumb Throttle Front LED Light Rear Brake Lever Front Vee Brake Front Brake Lever Front Tyre 20"...
  • Page 5 BOTTOM OF SEAT TUBE...

  • Page 6: Battery Care & Charging

    BATTERY CARE & CHARGING Your Batribike Electric Tricycle uses a Lithium battery for it's power and the following points will directly affect battery life and performance. Storage Batteries do not like to be stored in very hot or very cold conditions or to be subject to conditions of high moisture.
  • Page 7 Using the Charger Two types of battery charger are used by BATRIBIKE. (Only one will be supplied). Both have a charge light which will display RED when charging and change to GREEN when the battery is charged. The alternative type charger also has a second light which shows RED when mains power is applied.

  • Page 8: Switching Off

    Usage Your BATRIBIKE Electric Tricycle can be used as a normal pedal tricycle by simply not switching on the battery. ELECTRIC TRICYCLE FUNCTIONS Switching On To use under electric power, switch on at the key operated switch on the side of the battery.
  • Page 9 Battery Meter The LED shows the charge remaining in the battery in the lower right of the display. The indicators will gradually go out as the battery power is used up. Refer to the table below for details. BATTERY METER DISPLAYS THE CHARGE REMAINING IN THE BATTERY SYMBOL CHARGE SYMBOL...
  • Page 10 Pedal Assistance There are 3 levels of pedal assistance from the motor. Using the ASSIST button you can select from LOW, MED (Medium) and HIGH. Pressing the button will scroll through the levels. Pressing the MODE button when in HIGH mode will return to LOW assist. The motor will then be activated upon pedalling.
  • Page 11 If you switch on the battery but do not press the power button on the display your Batribike Trike will now act and feel like a normal tricycle. This is useful when you are feeling fit at the start of a journey or using your trike for exercise purposes.
  • Page 12 Using the Throttle - Country Specific The throttle is available all the time the power is switched on at the handlebar display. The throttle can be used whilst pedalling in any of the assist modes to give extra help as required. The throttle is not limited by the assistance level selected and is available to give up to maximum power at all times.
  • Page 13 BS EN15194 Compliance The BATRIBIKE Trike conforms to BS EN15194. For the British market, the addition of a throttle control has rendered this not compliant in some countries. ● You are recommended to seek advice from the relevant authorities in the country you are visiting before travelling.

  • Page 14: Standard Tricycle Functions

    To stop, release the throttle and pull the brake levers. Parking Brake The Trike 20 and Trike-R are fitted with parking brakes. This allows the rider to leave the Trike with confidence, knowing that it will not roll away. To operate the parking brake, pull the brake lever towards the handlebar and click the small parking brake lever into position.
  • Page 15 Tilting Mechanism (Not fitted to Trike-R) The Batribike Trike 20 is fitted with a tilting mechanism which aids the rider to corner more easily. Using the tilting facility also allows for greater stability when cornering, reducing the risk of lifting a rear wheel.

  • Page 16: Adjusting The Handlebars

    Do not use the Trike with the markings showing. Carrying Capacity The Batribike Trikes are fitted with useful load carrying baskets front and rear. Please note the maximum load for the rear basket is 40kg and the maximum combined weight for Rider and load is 130kg.
  • Page 17 Lights Lights are provided on your BATRIBIKE tricycle. These are power efficient LED units which are powered from the main battery. To turn on the front and rear lights, ensure that the power is on and momentarily press the LIGHT button.
  • Page 18 ® The Datatag UV “Stealth” PRO Cycle System is ideal for BATRIBIKE Electric Tricycles and is a Police Preferred Crime Prevention Product. The system protects your tricycle frame, forks and battery, plus the Datadots® are used to mark many of your electric and non-electric cycle components.

  • Page 19: Datatag

    Number, found on the label attached to your frame, and the Datatag Stealth Etch Code marked on the frame, forks and battery. (Only visible in UV light). You also need the bike Serial Number. This is a separate registration system to our Batribike Warranty Registration.

  • Page 20: Maintenance Schedule

    Beyond this manual, it is good to consult your BATRIBIKE dealer for advice if you are at all unsure about any of the procedures described. Normal maintenance is not covered under the warranty and this service may be chargeable.

  • Page 21: Removing The Front Wheel

    ● Hub motor and general inspection We recommend you arrange to have a thorough inspection of your tricycle by a BATRIBIKE dealer. This includes opening up the hub motor to inspect and lubricate the gears. Tyre Pressures The tyres should be pumped up to within the range stated on the sidewall.

  • Page 22: Special Battery Features

    SPECIAL BATTERY FEATURES Battery Meter The battery has a useful meter located on the top surface. This is handy when the battery is not fitted to the tricycle as it gives an indication of resting charge level. To operate the meter, press and hold the power button and the LEDs will light to show an approximation of the remaining charge in the battery.
  • Page 23 Your Local Authority should have the necessary facilities in place. If you prefer you may take your original battery to BATRIBIKE for recycling. Never dispose of batteries in a fire or subject to puncture or crushing.
  • Page 24 Cost incurred by loss of the tricycle’s usage. Brake blocks/pads, tyres, lights and cables etc. are considered as consumables and replacements are available from BATRIBIKE or may be obtained from your local cycle shop. In the event of a Warranty claim ●...

  • Page 25: Warranty

    6. In the unlikely event of a battery failure, the battery must be returned to Batribike for testing. If upon testing it is found that the above conditions have not been met then the warranty will not apply and the cost of replacement and carriage will be payable by the Customer.

  • Page 26: Specifications

    TRIKE 20 Technical Specification...
  • Page 27 TRIKE 20 16 (High Capacity) Technical Specification...
  • Page 28 TRIKE-R Technical Specification...
  • Page 29 TRIKE-R 16 (High Capacity) Technical Specification...

  • Page 30: Certificate Of Compliance

    Mark: Type European Conformity Approved Product: Electric Trike Model(s): Batribike Trike R, Batribike Trike 20 Verification to: Standard: EN 15194:2009+A1:2011, EN 14764:2005 related to CE Directive(s): 2006/42/EC (Machinery) 2014/35/EU (Low Voltage) 2014/30/EU (Electromagnetic Compatibility) Remark: The product(s) has been verified on a voluntary basis. The product(s) satisfies the requirements of the Certification Mark of ECM, in reference to the above listed Standard(s).
  • Page 32 BATRIBIKE Electric Bicycles are exclusive to:- Fallowgate Limited Kellaway House Marton Road Sturton-by-Stow Lincoln BATRIBIKE are LN1 2AH Members of the Bicycle Association Phone: 01427 787774 of Great Britain E-mail: support@batribike.com ----- USER MANUAL TRIKE RANGE - ISSUE 8 - ©2015 Fallowgate Limited -----...
