Dishwasher
Installation
STEP 18: CONNECT
POWER SUPPLY
If a power cord with plug is already installed proceed to
Step19_
kWARNING:
If house wiring is not 2-wire with ground, o ground must be
providedby the installe_Whenhousewiringis aluminum be sure
to useUL-Listed anti-oxidantcompoundand aluminum-to-copper
connectors
ADVERTENCIA:
Si el cableado dom6stico no cuenta con un cable de 2 hilos con
conexiOn a tierra un insta_ador debe realizar una conexi6n a tierra
Cuando el cableado dom6stico es de aluminio, asegurese de usar
un compuesto
antioxidante
g conectores de aluminio a cobre
aprobados par UL
In this step you will need the junction box cover and the
#10 He× head screw from the screw kit set aside in Step 1
STEP 19: PRETEST CHECKLIST
Review this list after installing gour dishwasher' to avoid
charges for a service call that is not covered by gour
warrantg,
[] Check to be sure power is OFF
[]
[]
[]
[]
[]
• Secure house wiring to the back of the junction
box with a
strain relie[
• Locate the three dishwasher
wires {white. block and green}
with stripped ends Insert dishwasher
wires through the small
[]
hole in the junction
box bracket
Use UL listed wire nuts of
appropriate
size to connect incoming ground to green, white
to white and black to block
[]
° Install the junction
box cover using #10 hex head screw
Check to be sure that wires are not pinched under the cover:
[]
Figure AA
[]
[]
Note: Check That Harness
LeadsAre Threaded Thru
_Ground
Small
Hob
in Bracket
/
Open door and remove all foam and paper packaging
Locate the Owner's Manual set aside in Step 1
Readthe Owner's Manual for operating instructions
Check door opening and closing If door does not open and
close freelg, check for proper routing of spring cable over
pulleg If door-drops or closes when released, adjust spring
tension. See Step 2.
Check to be sure that wiring is secure under the dishwasher:
not pinched or in contact with door springs or other
components
See Step :10
Check door alignment
with tub If door hits tub. level
dishwasher
See Steps 14 and 15
Pull lower rack out, about halfwag Check to be sure it does
not roll back or forward on the door:,if the rack moves,
adjust leveling legs See Step :14.
Check door alignment with cabinet if door hits cabinet,
reposition dishwasher, See Step 15
Check that door spring does not contact water line, fill hose.
wiring or other components See Step 16
Verifg water supplg and drain lines are not kinked or in
contact with other components Contact with motor or
dishwasher frame could cause noise
[]
[]
[]
Turn on the sink hot water faucet and verifg water
temperature
Incoming water- temperature
must
be between 120°F and 150"F A minimum
of 120°F
temperature
is required for best wash performance
See
"Prepare Hot Water Line" page 5
Add 2 quarts of water to the bottom of the dishwasher to
lubricate the pump seal
Turn on water supplg Check for leaks Tighten connections
if needed
[] Remove protective fifm if present from the control panel
and door,
12
