S
PECIFICATIONS
Applicable
Standards
Fixed Ports
Speed
Forwarding
rate
LED Indicators
Cable
Dimensions
Weight
Power
Power
Consumption
Temperature
Humidity
Emissions
IEEE 802.3 10BASE-T
IEEE802.3u 100BASE-TX & 100BASE-FX
1 TX port, 1 FX port
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
148,800pps
Per Unit- (2 LEDs): Power; Speed( 100 )
Per Port- (2 LEDs): FDX/COL, LINK/ACT
10BASE-T –
2-pair UTP Cat. 3,4,5, up to 100 m (328 ft)
100BASE-TX --
2-pair UTP Cat. 5, up to 100 m (328 ft)
100BASE-FX --
62.5/125um multi-mode fiber optic cable,
up to 2 km
10/125um single-mode fiber optic cable, up
to 75 km
L120 × W88 × H25 mm
305 g
External power adaptor 7.5V 1.5A
7.2W Max.
Operating:0°C ~ 40°C (32°F ~ 104°F)
Storage: -25°C ~ 70°C (-13°F ~ 158°F)
10 ~ 90%, non-condensing
FCC part 15 Class B, CISPR ClassB, VCCI
Class B, CE Mark
8
