Installation
CUSB3
CUSB5
CUSB4
If you purchased a separate USB cable make sure it has the same pin assignment.
A different pin assignment may damage the system. If you need the USB cable,
please contact our retailer.
Page 3-10
CUSB3/CUSB4/CUSB5: Six USB 2.0 ports
This mainboard includes additional USB2.0 ports,
identified by 10-pin connector.
If you wish to use the additional USB ports, install
the card-edge bracket to the system chassis then
insert its cables to this 10-pin connector.
CAUTION !
