3-2 Jumper Settings

Page 3-4

JCMOS:

Clear CMOS data Jumper

If the CMOS data becomes corrupted or

you forgot the supervisor or user

password, clear the CMOS data to

reconfigure the system back to the

default values stored in the ROM BIOS.

To CMOS Clear data, please follow the steps below.

1. Turn off the system.

2. Change the jumper from "1-2" to "2-3" position for

a few seconds.

3. Replace the jumper back to the "1-2" position.

4. Turn on the system and hold down the <Del> key

to enter BIOS setup.

Settings:

1-2: Normal (Default)

2-3: Clear CMOS
