One Serial port
One RJ45 LAN connector
Four USB2.0 ports
Three Audio jacks
Onboard connector and pin-header
One floppy drive connector
Two ATA-100/133 IDE connector
Six extra USB2.0 ports
One CD-IN and AUX-IN connector
One IR connector
Four S-ATA connectors
Three Fan connectors
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
Supports Front Panel Audio connector
Special Features
Support KBPO function – Keyboard power on, turn on the computer from
keyboard
Support Wake-On-LAN by PME
PowerBIOS for excellent overclocking capabilities through
- Programmable FSB and PCI-E Clock output frequency with 1MHz fine
tuning
- Support BIOS adjustable CPU Core voltage, Chipset voltage, DIMM
frequency and voltage settings
Form Factor
305mm x 210 mm ATX size
Specification
Page 2-3
