Configuring Grandstream IP Phones
Abstract:
configuration of the Grandstream IP phones on Quadro LAN.
Please Note:
This document contains confidential and proprietary information owned by Epygi Technologies Ltd. Any copying, use or disclosure of
the document or the information contained herein without the written permission of Epygi Technologies Ltd. is strictly prohibited.
on Quadro LAN
Revision
Split form Configuring Tested IP
Phones on Quadro LAN document
Quadro variants:
Filename:
Version:
Template:
NEWsupportTemplate.dot
Last saved:
9/27/2007 6:08:00 PM by Liana Badalyan
Revision: 1.0
This document describes the steps required for Auto-
Configuring Grandstream IP Phones on Quadro LAN
Revised By
Date
Sona Grigoryan
26-09-2007
Advertisement
Table of Contents
Related Manuals for Grandstream Networks BT100
Summary of Contents for Grandstream Networks BT100
- Page 1 Revision: 1.0 Abstract: This document describes the steps required for Auto- configuration of the Grandstream IP phones on Quadro LAN. Please Note: This document contains confidential and proprietary information owned by Epygi Technologies Ltd. Any copying, use or disclosure of...
-
Page 2: Table Of Contents
Epygi Technologies Configuring Grandstream IP Phones on Quadro LAN Table of Contents Introduction ................4 Requirements and Preparations..........4 Auto-Configuration on Grandstream IP Phones ...... 5 Completing Grandstream IP Phones Configuration ....7 4.1 Grandstream BT100/200..............8 4.2 Grandstream GXP2000 ..............9 Verifying Configuration ............ - Page 3 Epygi Technologies Configuring Grandstream IP Phones on Quadro LAN Document Revision History Revision Date Revision Valid for SW Valid for models 27-09-07 Initial version 4.1.x IP PBXs PAGE 3 27-Sep-07...
-
Page 4: Introduction
Quadro LAN interface via Ethernet and serve as additional extensions similar to onboard FXS extensions (see Figure 1). This document describes how to configure the Grandstream SIP phones connected to the Quadro LAN using Auto-configuration option of the Quadro. -
Page 5: Auto-Configuration On Grandstream Ip Phones
Epygi Technologies Configuring Grandstream IP Phones on Quadro LAN 3 Auto-Configuration on Grandstream IP Phones The following step-by-step instructions describe how to configure an IP line to allow Grandstream SIP phones to be auto-configured. Log into the Quadro as an administrator. - Page 6 Check the Use Session Timer checkbox to enable SIP Session Timer for this line. Click Save to submit the changes. Once a corresponding IP line is configured, factory reset the phone to complete Auto- configuration. For instructions on how to reset a Grandstream SIP phone, please refer to Section PAGE 6 27-Sep-07...
-
Page 7: Completing Grandstream Ip Phones Configuration
Figure 4-Configuring an IP line 4 Completing Grandstream IP Phones Configuration To complete Grandstream IP phone configuration using Auto-configuration option, reset the phone to factory default settings. Please see the instructions below that describe how to restore the default configuration on the Grandstream SIP phones. -
Page 8: Grandstream Bt100/200
Configuring Grandstream IP Phones on Quadro LAN 4.1 Grandstream BT100/200 To complete the automatic configuration on Grandstream BT100/200, reset the phone to factory default settings as detailed below: Press the Menu button on the phone for Key Pad Menu options. -
Page 9: Grandstream Gxp2000
Configuring Grandstream IP Phones on Quadro LAN 4.2 Grandstream GXP2000 To complete the automatic configuration on Grandstream GXP2000, reset the phone to factory default settings as detailed below: Press the OK key to bring up the key pad configuration UI menu, select the Config, Press the OK key to enter the submenu and select Factory Reset. -
Page 10: Troubleshooting
If there is a problem with auto configuration of Grandstream BT100 phones, after resetting the phone there is a need to set the configuration server by hand from the GUI of the phone. -
Page 11: Configuration Changes To A Dhcp Server
Epygi Technologies Configuring Grandstream IP Phones on Quadro LAN Figure 6- SIP Phone uses dedicated DHCP server Please note: If your company’s LAN configuration is similar to the one shown in Figure 6 make sure the DHCP server is disabled on the Quadro LAN. If it is not, unpredictable network behaviour may occur. -
Page 12: References
Epygi Technologies Configuring Grandstream IP Phones on Quadro LAN 8 References • Quadro Manual-II: Administrator’s Guide for the corresponding release. • Quadro Features on Epygi Tested IP Phones List. • IP Phones and IP Lines Configuration Guide. PAGE 12 27-Sep-07...
