Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video, audio
and presentation professional on a daily basis. In recent years, we have redesigned
and upgraded most of our line, making the best even better! Our 500-plus different
models now appear in 8 Groups
Congratulations on purchasing your Kramer VS-3232Vxl 32x32 Video Matrix
Switcher. This product is ideal for the following typical applications:
Professional display systems requiring video signal routing
Broadcast, presentation and production facilities, as well as monitoring in
large duplication systems
Rental/staging applications
The package includes the following items:
VS-3232Vxl 32x32 Video Matrix Switcher
Power cord and null-modem adapter
Windows®-based Kramer control software
Windows®-based Ethernet Configuration Manager and Virtual Serial Port
Manager
Kramer RC-IR2 Infra-red remote control transmitter (including the
required batteries and a separate user manual
2

Getting Started

We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.
