Overview

The Kramer VS-3232Vxl is a very high performance, superior
interval matrix switcher for composite video signals on BNC connectors. It
features a video bandwidth of over 500MHz that ensures transparent
performance even in the most critical applications. Three SYNC switching
options make the VS-3232Vxl appropriate for a wide range of glitch-free
transition applications. The VS-3232Vxl can be used as a standalone unit, or
configured as a part of a multi-signal Kramer switcher system, in which all
units switch simultaneously.
The VS-3232Vxl features:
Full 32x32 non-blocking matrix array to switch any of the 32 input video
signals to any or all outputs
A video bandwidth of over 500MHz at 3dB along with 0.1dB flatness to
50MHz
Four switching options, one for immediate switching and three for SYNC
switching
59 preset memory locations for quick access to user-defined special
configurations
Fast access to a preprogrammed default preset configuration (UNITY setting)
Two communication protocols – the Kramer 2000 and the limited Sierra
ASCII
Easy upgrading of the firmware via the Internet
An 80x2 symbol LCD panel with user-friendly information and a
configuration menu
Optional connection to several switchers in one multi-signal video-audio
control system
A LOCK button/remote function to prevent tampering with the front panel
Control the VS-3232Vxl via the front panel buttons, or:
Remotely, by RS-232 or RS-485 serial commands transmitted by a touch
screen system, PC, or other serial controller
Via the ETHERNET
Via the infra-red remote control transmitter
Via an external remote IR Receiver (optional), see section 4.1
The VS-3232Vxl is housed in a 19" 2U rack mountable enclosure.
