Table 1: Front Panel VS-3232Vxl 32x32 Video Matrix Switcher Features

# Feature
1 ESC
2 STO
1
3 ALL
4 OFF
5 RCL
6 ENT
7 (Forward)
8 (Backward)
9 Digits from
0 to 9
10 FOLLOW Button
11 BREAKAWAY Button
12 DEFAULT SETUP Button
13 INPUTS/OUTPUTS LCD
Display
14 LOCK Button
15 MENU Button
16 TAKE Button
17 Power Switch
18 IR Receiver
1 This button is enabled and illuminated after pressing the MENU button
2 For example, to enter input 5, you can either press 0, 5 or 5, ENT
3 Since the LCD display is large enough to show only 13 cross-points out of a total of 32
4 Press and hold the LOCK button for about two seconds to toggle
6
Your Video Matrix Switcher
Press to exit the current operation
1
Press to store the current setting in the non-volatile memory
Press ALL followed by an input number to connect that input to all the
outputs
1
Press OFF followed by an output number to disconnect that output
1
Press to recall a setup from the non-volatile memory
Press to complete the input-output setup when using a one-digit number
instead of two digits
Press to enter the options in a setup menu
Press to shift the content of the display to the left
Press to shift the content of the display to the right
Select the output to which the input is switched and select the input to
switch to the output
Press to enter the Follow mode in the multi-switcher configuration
Press to enter the Stand-Alone mode in the multi-switcher configuration
Press to recall the default setup (UNITY setting), see section 8.5
Displays the outputs (in the upper row, below the OUTPUTS label)
switched to the selected inputs (in the lower row, above the INPUTS
label).
Displays user interface messages and configuration menu items
4
Toggle to lock/unlock the front panel buttons
Press once to enable the ALL, OFF STO and RCL buttons
Press twice to enter the configuration menu
When in the configuration menu, press to browse through the menu items
Used to confirm and complete setup and switching
Illuminated switch for turning the unit ON or OFF
The red LED is illuminated when receiving signals from the Kramer Infra-
red remote control transmitter
Function
2
.
