Operation

The Sphinx Remote is used for several different
models and can therefore transmit different control
codes, depending on which model has been
selected with the select buttons (3.).
Important: Always press the AMP button before you
send a command (even if you only have one Sphinx
component).
Otherwise it is possible that although the Remote
will send a signal (LED blinks) nothing happens
because the transmitted signal is not 'recognised' by
the component.
Indoors the Remote may be used up to a distance of
7 meter, provided there is no strong sunlight in the
room and if you aim the Remote at the component.
Always aim the Remote straight at the front panel of
the component, the maximum offset angle is 30°.

Selecting without switching

Suppose for instance that you would like to select
the Tuner to Radio 4 without interrupting the CD
playback.
In that case you momentarily depress (not longer
than 0.5 sec) the 'TUNER' button and the '4' button.
The same procedure is used for the other system
components (TV, VCR).
Only when you depress the select button longer than
0.5 sec the system will select a different signal
source (in our example you will then hear the Tuner
playback).

Batteries

The two batteries have a life span of approx. one
year during normal use, but shorter when used more
intensely.
Replacement batteries: 1.5 V, model micro or penlite
or LR03 or AAA or AM4 (one of these codes is
indicated on the packaging and the batteries). You
may also use rechargeable 1.5 V batteries.
Note: Position the new batteries exactly as shown in
the illustration at the bottom of the battery
compartment, otherwise the Remote will not
function!
SPHINX

When encountering problems...

Remote Control does not work
Wrong component selected
Distance to component
exceeds 7 m
Angle between Remote and
component exceeds ±30°
Sensor window on front dirty
Batteries empty or incorrectly
placed
Strong (sun)light in room
Component is not switched on
(!)
Component reacts differently than expected or
not at all
Wrong component selected
Component or Remote does
not function
Batteries of remote empty
Myth 5
Select the correct one
Use Remote at closer
range
Decrease angle
Clean window
use new batteries or
replace the old
correctly
Shade off
Switch it on
Select the correct one
Check component with
it's original remote
Use new batteries
10
