Gefen EXT-USB-MIDI User Manual

Optional USB MIDI Extender
Accessories
Extends any USB device up to 150 feet away from the computer.
The USB MIDI extender extends any USB device up to 150 feet from the location of your computer,
eliminating the 16 feet distance limitation of USB. The USB MIDI sender and receiver units use one
CAT-5 cable for extension. It is optimized for applications where two devices, such as the keyboard
and mouse, must be operated remotely. The USB MIDI extender can even be used to extend
surveillance cameras for security purposes. The USB MIDI Extender extends any MIDI device.
CAT-5 Cables
How It Works
The USB MIDI extender sender unit is connected to the computer using the supplied USB cable.
The remote peripheral(s) are connected to the receiver unit. A category-5 (CAT-5) cable is used to
link the sender to the receiver.
Features:
Extends any USB device up to 150 feet (45 meters) using CAT-5 cable
Requires no external power adapter
Provides support for any full-speed 12 Mb/s or low-speed 1.5Mb/s USB device
Use either PC or Mac with USB keyboard/mouse
Ideal for USB MIDI interface devices

Specifications:

USB device support: full-speed 12 Mb/s Low-speed 1.5 Mb/s
USB Input Connectors: type B
USB Output Connectors: type A
Link Connector: RJ-45
Shipping Weight: 2 lbs.
Package Includes:
USB MIDI extender send unit
USB MIDI extender receive unit
6.6' USB cable (A-B)
User Manual
