- Page 1 4K Ultra HD 600 MHz Extender for HDMI over one Fiber-Optic Cable EXT-UHD600-1SC Version A1...
- Page 2 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
- Page 3 Warranty Information For the latest warranty coverage information, refer to the Warranty and Return Policy under the Connect section of the Gefen Web site at http://www.gefen.com/connect/warranty-and- return-policy...
- Page 4 Contact Us Technical Support (707) 283-5900 (800) 472-5555 8:00 AM to 5:00 PM Monday - Friday, Pacific Time Email support@gefen.com http://www.gefen.com Mailing Address Gefen Core Brands, LLC c/o Customer Service 1800 S McDowell Blvd Petaluma, CA 94954 USA...
- Page 5 600 MHz and reliably transport the full 18.2 Gbps throughput of HDMI 2.0. © 2017 Gefen, LLC. All Rights Reserved. All trademarks are the property of their respective owners. Gefen and Core Brands, LLC reserve the right to make changes in the hardware, packaging, and any accompanying documentation without prior notice.
- Page 6 Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™ • Supports the use of DVI sources and DVI displays up to 1080p Full HD and WUXGA (1920x1200), with Gefen CAB-DVI2-HDMI-LCK DVI-to-HDMI cables (not included) • Sturdy metal construction of the enclosures help provide immunity against Electro- Magnetic Interference (EMI) and radiated noise (RFI).
-
Page 7: Table Of Contents
Table of Contents Connectors and Indicators ....................8 Sender Unit ..........................8 Receiver Unit ...........................9 Installation ........................10 Connection Instructions......................10 Sample Wiring Diagram ......................11 Specifications ........................ 12... -
Page 8: Connectors And Indicators
EXT-UHD600-1SC Connectors & Indicators Sender Unit Sender 5V DC Link EXT-UHD600-1SC-TX Link Input ® Name Description Link Connect an SC-terminated OM3 or better multimode fiber optic cable between this connector and the Link connector on the 4K 600 MHz Receiver unit. -
Page 9: Receiver Unit
Introduction Receiver Unit Receiver 5V DC Link EXT-UHD600-1SC-RX Link Output ® Name Description Link Connect an SC-terminated OM3 or better multimode fiber optic cable between this connector and the Link connector on the 4K 600 MHz Sender unit. Extender for HDMI... -
Page 10: Installation
Installation Connection Instructions ► Video Connect the included HDMI cable between the 4K source and the Input port on the Sender unit. Connect a 4K display to the Output port on the Receiver unit, using the included HDMI cable. ► Fiber Connect a single SC-terminated OM3 or better (50/125 μm) multimode fiber optic cable, up to 660 feet (200 meters), between the Link port on the Sender unit and the Link port on the Receiver unit. -
Page 11: Sample Wiring Diagram
OM3 (or better) 50/120µm SC-SC Fiber Optic Cable Back Back Link 5V DC Link 5V DC Sender Receiver Unit Unit Front Front EXT-UHD600-1SC-TX EXT-UHD600-1SC-RX Link Link Input Output 4K Ultra HD 600 MHz 4K Ultra HD 600 MHz Display Source EXT-UHD600-1SC... -
Page 12: Specifications
Specifications Supported Formats Video • 4K Cinema-DCI (4096 x 2160 to 60 Hz, 4:4:4) • 4K Ultra HD (3860 x 2160 to 60 Hz, 4:4:4) w/ HDR-10 and Dolby Vision™ • 1080p Full HD (1920 x 1080 to 60 Hz, 4:4:4, 12 bit) •... - Page 13 This page left blank intentionally...
- Page 14 *Preferred Core Brands, LLC 1800 S McDowell Blvd. Petaluma CA 94954, USA (707) 283-5900 (800) 472-5555...
