Godex C-650Plus II User Manual page 30

User Manual
Setup Parameter
CODE PAGE
OLIVETTI C-SET
OLIVETTI COMPRES
VERT. RESOLUTION
CUT SHEET EJECT
PRINT DIRECTION
LINE MODE
WRAP MODE
REFERENCE EDGE
Values
CP437*, CP437G, 96GREEK,
CP850, CP851, CP852, CP853,
CP855, CP857, CP858, CP860,
CP862, CP863, CP864, CP865,
CP866, CP867, CP876, CP877,
CP1098, CP1250, CP1251,
CP1252, CP1257, GOST, TASS,
MAZOWIA, CP437SL, UKRAIN,
KOI8-U, 8859/1, 8859/2, 8859/3,
8859/4, 8859/5, 8859/6, 8859/7,
8859/8, 8859/9, 8859/15,
ROMAN-8, ID 12, CP874, ID 14,
ID 17, SANYO, KU, PHILIP
CODE PAGE, INTERN.*,
GERMANY, PORTUGAL,
SPAIN1, DEN/NORW, FRANCE,
ITALY, SWE/FIN, SWISS,
G. BRITAIN, USA ASCII,
GREECE, ISRAEL, SPAIN 2,
JUGOSLAVIA, TCV 370,
CANADA, SDC, TURKEY, CIBC,
PC-DEN/NORW, PC-DEN OPE,
PC-210, PC-220, OLI-UNIX
17.1 cpi*, 16.6 cpi
1/216 inch, 1/240 inch*
on front*, on rear
unidir., bidir., sw control*
LF=LF, CR=CR*
CR=LF+CR
LF=LF+CR
LF&CR=LF+CR
truncate, autowrap*
Left*, right
25
Description
Selects the code page for both the IBM
and the EPSON emulations.
Selects the character sets for the
OLIVETTI protocol.
Selecting CODE PAGE, it is possible to
select one of the above Code Pages to
be used with the OLIVETTI protocol.
Selects the compressed pitch in
OLIVETTI protocol.
Sets the vertical character resolution.
Setting used for the OLIVETTI
protocols.
Selects whether the cut sheet loaded
into the printer is ejected towards the
front or the rear of the printer.
Selects the printing direction of the print
head: unidirectional (unidir.),
bidirectional (bidir.) or selected via
software (sw control).
If the printer receives a LF code (LF), it
only performs a line feed. If the printer
receives a CR code (CR), it only
performs a carriage return.
If the printer receives a CR code (CR), it
performs a carriage return followed by a
line feed. If the printer receives a LF
code (LF), it performs a line feed.
If the printer receives a LF code (LF), it
performs a line feed followed by a
carriage return. If the printer receives a
CR code (CR), it only performs a
carriage return.
If the printer receives a LF code (LF) or
a CR code (CR), it performs both a line
feed and a carriage return.
The data exceeding the line length are
truncated (truncate) or printed on the
following line (autowrap).
Document reference on left or right, for
software compatibility.
