Page 1: Operators Guide
FlatJet Printer C-680 Operators Guide Godex Europe GmbH Arnzhäuschen 36 . 42929 Wermelskirchen Tel.: +49 (0) 2193 – 53396-0 E-mail:info@outputsolutions.de http://www.outputsolutions.de Fax: +49 (0) 2193 – 53396-... - Page 2 Godex Europe GmbH FlatJet Printer C-680 1. Revision, Oktober 2004 Copyright 2004 Godex Europe GmbH Notices The information contained in this document is subject to change without notice. Godex Europe makes no warranty of any kind with regards to: •...
-
Page 3: Table Of Contents
First Stepps Document printing Troubleshooting Printer is not printing Check the printer-LED’s If the printer does not turn on Check the printer cable connection If the printer still does not print Paper problems Print quality is poor Document is misprinted... -
Page 4: Packaging Includes Following Accessories
Accessories of the Godex Europe GmbH FlatJet Printer C-680 Make sure that the following accessories were included with your printer: Printer (Packed in a plastic bag and foam) Packaging includes following accessories 1. External power supply (the appearance can deviate from... -
Page 5: Terms And Conventions
Terms and conventions The following terms and word conventions are used in the onscreen User’s Guide. Terms The Godex Europe GmbH FlatJet Printer C-680 is referred to as FlatJet Printer or simply Printer. Format conventions • marks a listing □... -
Page 6: Network Connection (Optional)
The cable should not be longer than 3 Meter. Network connection (optional) The printer can be connected (optionally and against surcharge) to a network using a Fast Ethernet Print Server. Attach the Fast Ethernet Print Server to the parallel interface and connect the Print Server using an Ethernet-cable to the LAN. -
Page 7: Sheet Plain Paper Tray Accessory (Optional)
1. Mount the document input tray to the front of the printer, using the two slots. 2. Push the document output tray into its storage slot at he back of the printer. 3. Connect the low voltage plug of the external power supply to the printer as shown in figure 3. - Page 8 4. Connect the power cable of the external PS to the wall outlet as shown in figure 4. 5. Push the power-on switch. 6. Check if the printer is powered on. 7. Open the top cover as shown in figure 7.
- Page 9 15. plug the parallel-cable into the parallel connector of the printer and connect the other end of the cable to a computer as shown in figure 14 and 15.
- Page 10 First steps The printer buttons let you turn the printer on and off, cancel a print job, select the print quality or resume printing. The lights give you visual cues about the status of the printer. [1] Power button and light The Power button turns the printer on and off.
-
Page 11: Document Printing
[3] Resume button and -LED The Resume-LED flashes when an action is required such as loading paper or clearing a paper jam. When new paper is loaded or the problem is solved, press the Resume button to continue printing. [4] Print cartridge status symbol and -LED The Print Cartridge Status light turns on or flashes when a print cartridge needs Service or must be replaced. -
Page 12: Printer Is Not Printing
Paper or other media is correctly loaded in the input tray. • Printer's top cover is closed. Check the printer-LEDs The printer lights indicate printer status and alert you to potential problems. • Power-LED is flashing The printer is preparing to print . - Page 13 All lights are flashing he printer may need to be restarted 1. Press the Power button to turn off the printer, then press the Power button to restart the printer. Proceed to step 2 if the lights continue to flash 2.
-
Page 14: Check The Printer Cable Connection
Check the printer cable connection • If you are using a USB printer cable and the cable is attached to a USB hub, there may be a printing conflict. There are two methods for solving the conflict: 1. Attach the printer's USB cable directly to your computer, or 2. -
Page 15: Print Quality Is Poor
• Too much or too little ink appears on the page Adjust the ink volume and dry time: 1. Open the printer properties dialog box. 2. Select the PAPIERART/QUALITÄT control field 3. Click on the Ink 4. Move the Ink Volume slider toward Light or Heavy. -
Page 16: Document Is Misprinted
Document is misprinted • If the text and images on your printouts are misaligned, then calibrate the printer. • Text and images are misaligned document is printed off-centre or at an angle 1. Verify that the paper is correctly placed in the In tray or optional lower tray. -
Page 17: If You Continue To Have Problems
Documents containing graphics or photographs print slower than text documents. • Best or maximum dpi print mode is selected The printer prints slower when Best or Maximum dpi is selected as the print quality. To increase the printer speed, select a different print quality mode. •... - Page 18 < 40dB(A) 32V/1A (external power supply) Printer: 447 (W) x 145 (H) x 235 (D) mm / 7 kg Printer with sheet feeder: 447 (W) x 207 (H) x 382 (D) mm / 10 kg Windows 2000, XP 2 years (bring-in)
