1-3. Contents

The contents comprise of the following:
<1>Printer
<4> Roll of Labels
*This printer model user primarily the power supply:SPN-270-24,if a different power supply is used
with the printer which has caused damages to the printer itself ,than this is not covered as part of
the product warranty.

1-4. Printer Parts

Part Description
1 Front Cover
2 Front Locking Tenon (2 EA, left/right)
3 Dust Cover for Interface Panel
4 Fan-Fold Media Entry
5 Back Locking Tenon (2 EA, left/right)
6 Back Cover
7 Ribbon Rewind Spindle
8 Ribbon Supply Spindle
9 Core Guide
10 Label Roll Stand (2 EA)
11 Printhead Pressure Adjusting Screws
12 Printer Lock (2 EA, left/right)
13 Tear Bar
14 Label Roll Core
15 LED Indicator
16 Paper Feed Button
17 Parallel Port
18 Serial Port
19 Power Jack
20 Power Switch
21 Label Guide (Adjustable Horizontally)
22 Gap Sensor Assembly
23 Rubber Roller
24 Printhead Assembly
<2>Switching Power Supply
<5> CD (Software/Manual/Driver/DLL) <6> Quick Start
4
EZ-4TK Plus
<3> Ribbon
