Page 1: Electric Start
41513 Rev 41513-20100224 10006 Santa Fe Springs Road Santa Fe Springs, CA 90670 USA Made in China Owner’s Manual and Operating Instructions SAVE THESE INSTRUCTIONS Important Safety Instructions are included in this manual 9000 Peak Watts / 7000 Running Watts... -
Page 3: Table Of Contents
Table of Contents Introduction ........1 Storage ........... 16 Portable Power Generator ......1 Engine Storage ........16 Accessories ..........1 Generator Storage ........16 This Booklet ..........1 Specifications ......... 17 Manual Conventions ...... -
Page 5: Introduction
Champion Power Equipment manufactures Congratulations on your purchase of a and sells accessories designed to help you Champion Power Equipment generator. CPE get the most from your purchase. To find out designs and builds generators to strict more about our covers, power cables and specifications. -
Page 6: Manual Conventions
NOTE If you have questions regarding your generator, WARNING we can help. Please call our help line at 1-877- 338-0999. WARNING indicates a potentially hazardous could situation which, if not avoided, result in death or serious injury. Rev 41513-20100224 English... -
Page 7: Safety Rules
Maintain at least five feet of clearance from combustible materials. Rotating parts can entangle hands, feet, hair, clothing and/or accessories. Traumatic amputation or severe laceration can result. Keep hands and feet away from rotating parts. Rev 41513-20100224 English... - Page 8 DO NOT use the generator if: When storing the generator: Electrical output is lost Store away from sparks, open flames, pilot lights, Equipment sparks, smokes or emits flames heat and other sources of ignition. Equipment vibrates excessively Rev 41513-20100224 English...
-
Page 9: Controls And Features
(8) Battery – Used to start the engine. (4) Air Cleaner – Protects the engine by filtering dust and debris from the intake air. (9) Power Panel – See “Power Panel” (5) Recoil Starter – Used to start the engine Rev 41513-20100224 English... -
Page 10: Power Panel
60 Hz loads requiring up to 20 A 0r 2400 receptacle powers 120 Volt AC, 60 Hz, single Watts of power. phase loads requiring up to 29 A or 3500 Watts of power. (8) Ground Terminal – Consult an electrician for local grounding regulations. Rev 41513-20100224 English... -
Page 11: Parts Included
Controls and Features Parts Included Your Model 41513 Gasoline Powered Generator ships with the following parts: Wheel Kit 10” Solid Wheel 2 piece Axle Assembly 2 sets Support Leg 1 piece Vibration Mounts 2 piece Support Leg Hardware 1 set... -
Page 12: Assembly
2. Slide the M10x120 wheel bolt through the washer, sleeve and wheel. 3. Slide the bolt through the mount point on the frame. 4. Fasten securely with the 10mm nut. 5. Repeat steps 2-4 to attach the second wheel. Rev 41513-20100224 English... -
Page 13: Install The Spark Arrester
3. Add 1.16 qt (1.1 L) of oil and replace oil fill cap/dipstick. See “Specifications” for oil recommendations based on operating conditions. 4. Check engine oil level daily and add as 6. Screw on the fuel cap and wipe away any needed. spilled fuel. Rev 41513-20100224 English... -
Page 14: Grounding
DO NOT light cigarettes or smoke when filling the electrician to ensure compliance with local fuel tank. electrical codes. Grounding Your generator must be properly connected to an appropriate ground to help prevent electric shock. Rev 41513-20100224 English... -
Page 15: Operation
2. Obtain an Uninterruptible Power Supply (UPS) device. Most UPS devices come with a rechargeable battery between the electronic equipment and power supply source. The device buffers the voltage and protects against virtually all short- duration voltage fluctuations. Rev 41513-20100224 English... -
Page 16: Stopping The Engine
2. Total the running watts of these items. This is the amount of power you need to keep your items running. 3. Identify the highest starting wattage of all devices identified in step 1. Add this Rev 41513-20100224 English... -
Page 17: Wattage Reference Chart
Belt Sander 3" 1000 1500 Bench Grinder 6" 1500 Circular Saw 1500 1500 Compressor 1 1/2 HP 2500 2500 Edge Trimmer Hand Drill 1/2" 1000 1000 Lawn Mower 1200 1800 Paint Sprayer 1200 Table Saw 2000 2000 Rev 41513-20100224 English... -
Page 18: Maintenance
6. Place the filter in the assembly. 7. Reattach the air filter cover and snap in Engine Maintenance place. To prevent accidental starting, remove and ground spark plug wire before performing any service. Rev 41513-20100224 English... -
Page 19: Spark Arrester
Spark Arrester Contact our help line at 1-877-338-0999 to Allow the engine to cool completely locate the nearest Champion Power before servicing the spark arrester. Equipment certified service dealer for your 2. Remove the two screws holding the generator or engine maintenance needs. -
Page 20: Storage
4. Add a fuel stabilizer into the fuel tank. 5. Change the oil. 6. Remove the spark plug and pour about ½ ounce of oil into the cylinder. Crank the engine slowly to distribute the oil and lubricate the cylinder. 7. Reattach the spark plug. Rev 41513-20100224 English... -
Page 21: Specifications
Fuel capacity is 6.5 gallons (25 L). Use Intake 0.13-0.17mm (0.005 – 0.007 in.) regular unleaded gasoline with a minimum Exhaust 0.18-0.22mm (0.007 – 0.009 in.) octane rating of 85. Oil capacity is 1.16 qt (1.1 L). Rev 41513-20100224 English... -
Page 22: Parts Diagram
Specifications Parts Diagram Rev 41513-20100224 English... -
Page 23: Parts List
GB5789 M8×20 Flange Bolt M8×20 ST190FD-II-1731000 Muffler ST188FD-1732200-A Muffler outer protector ST188FD-1180121 Spark arrester assy ST188FD-1100010-88 Spark arrester cover GB818 M5X14 Flange Bolt M5×14 ST188FD-1730100 Muffler gasket GB16674 M8×25 Flange Bolt M8×25 ST188FD-1730001-G Ex pipe ST188FD-1100001-G Muffler gasket Rev 41513-20100224 English... - Page 24 Battery guard(B) ST168FD-1750002-C6 Battery red wire（+） ST168FD-1750002-C7 Battery black wire(-) ST05FD-03011112 Jacket GB5789 M8×25 Flange Bolt M8×25 ST188FD-1743002-C Vibration mount ST05FD-03020301-84 Support leg GB5789 M8×16 Flange Bolt M8×16 ST07FD-02010003 Flange bolt M5×229 GB6175 M5 Nut M5 OV01-00000000 Transition Rev 41513-20100224 English...
-
Page 25: Wiring Diagram
Specifications Wiring Diagram Rev 41513-20100224 English... -
Page 26: Troubleshooting
Contact the help line. Generator gallops Engine governor defective Contact the help line Repeated circuit breaker tripping Overload Review load and adjust. See “Power Management” Faulty cords or device Check for damaged, bare or frayed wires. Replace defective device Rev 41513-20100224 English... -
Page 27: Warranty
Wear items such as filter elements, o-rings, etc. Accessory parts such as starting batteries, and Warranty Qualifications storage covers. Champion Power Equipment (CPE) will register Failures due to acts of God and other force this warranty upon receipt of your Warranty majeure events beyond the manufacturer’s Registration Card and a copy of your sales receipt control. - Page 28 United States Environment Protection Agency (U.S. EPA.) Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with U.S. EPA emission regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: The US EPA AND CPE are pleased to explain the Federal Emission Control Systems Warranty on your 2010 small off-road engine.
- Page 29 Such use voids this ECS Warranty and shall be sufficient grounds for disallowing an ECS Warranty claim. CPE shall not be liable hereunder for failures of any warranted parts of a CPE engine caused by the use of such an unapproved add-on or modified part. Rev 41513-20100224 English...
- Page 30 You must take your CPE engine or the product on which it is installed, along with your warranty registration card or other proof of original purchase date, at your expense, to any Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc. to sell and service that CPE product during his normal business hours.
-
Page 31: Notes
Notes Notes Rev 41513-20100224 English...
