Important: Read and save these instructions. This guide to be left with equipment.
2522381-H | 09 JUN 2010
NH
Series
Installation and
Operation Manual
Includes installation, operation
maintenance and troubleshooting
information for your NHTC / NHPC
Electric Steam humidifier

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NHTC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nortec NHTC

Summary of Contents for Nortec NHTC

  • Page 1 Important: Read and save these instructions. This guide to be left with equipment. Series Installation and Operation Manual Includes installation, operation maintenance and troubleshooting information for your NHTC / NHPC Electric Steam humidifier 2522381-H | 09 JUN 2010...
  • Page 2 WALTER MEIER LTD., except to the extent required for installation or maintenance of recipient’s equipment. All references to the NORTEC name should be taken as referring to WALTER MEIER LTD. Liability Notice NORTEC does not accept any liability for installations of humidity equipment installed by unqualified personnel or the use of parts/components/equipment that are not authorized or approved by NORTEC.

  • Page 3: Table Of Contents

    Humidifier Components Extended Shutdown NHTC/PC Models Maintenance Checklist Options and Accessories 67 Troubleshooting 9 Installation General Troubleshooting Typical Humidifier Installation NHTC/PC Warnings and Faults Location Wiring Diagrams Mounting with Keyholes 81 Spare Parts Plumbing 92 Warranty Steam Lines and Condensate Returns...

  • Page 4: Introduction

     Do not mount on vibrating surface  Do not mount on floor  The NHTC produces steam at atmospheric pressure no devices which could block steam output should be connected to the steam outlet.  Steam lines must be installed so that no restriction can produce backpressure in the humidifier.

  • Page 5: Receiving And Unpacking

    Receiving and Unpacking 1 Check packing slip to ensure ALL material has been delivered. 2 All material shortages are to be reported to NORTEC within 48 hours from receipt of goods. NORTEC assumes no responsibility for any material shortages beyond this period.

  • Page 6: Humidifier Components

    Cylinder Strap Display and Keypad Manual Drain Switch Drain Valve Door Interlock Switch On/Off Switch Drain Canal Auxiliaryl Drain Switch Fill Valve Control Terminal Strip Contactor Total Controller High Voltage Terminal Block Transformer Figure 2: NHTC Humidifier Components 3 | Introduction...

  • Page 7: Description Of Components

    Description of Components Table 1: Humidifier Components Component Function of Component Auxiliary Drain Drains water from cylinder by activating drain valve without software. Condensate Return Provides a connection to return condensate to humidifier. Contactor Turns On/Off power to cylinder electrodes based on a signal from the humidifier’s controller.

  • Page 8: Nhtc/Pc Models

    NHTC/PC Models shows the configuration and relative size of the three different cabinets. Both the NHTC and NHPC models up to 100 lb/hr (45 kg/hr) are also available with a built on blower pack. Table 2 provides specifications for the NHTC/PC product line.
  • Page 9 Outdoor Model The outdoor model of the NHTC provides a weatherproof enclosure that allows the NHTC to be installed on rooftops in moderately cool climates. Refer to the installation addendum that is provided with the outdoor model to insure proper installation.
  • Page 10 Table 3: NHTC/PC Specifications Phase Capacity Volts NHTC Part NHPC Part Amps Max Ext Standard Net/Full Fuse Cylinder Weight lb (kg) lb (kg) 110-120 1509620 2521984 15.9 5 (2.3) 1509621 2521985 18.3 220-240 1509622 2521986 15.9 1509623 2521987 13.7 10 (4.5)
  • Page 11 Introduction | 8...

  • Page 12: Options And Accessories

    On/Off Control Wiring Modulating Control Wiring Transducer Control Wiring 26 Optional Outdoor Temperature Reset 27 Remote Fault Option Wiring 28 Multi Mode Wiring (NHTC Only) 29 Options and Accessories Built On or Remote Blower Pack Fill Cup Extension Drain Water Cooling...
  • Page 13 5- Limit Signal 6- 5 VDC Controls 7- Ground Pg 20 8- Blower Pack 9- Blower Pack Plumbing Dedicated Pg 13 Circuit NHTC/PC Breaker or EXTERNAL Disconnect ½ in NPT Air Gap Cold potable water 350-670 microsiemens 30-80 psig Electrical Pg 19...
  • Page 14  When possible, mount the NHTC humidifier at a height convenient for servicing. Note: Do not mount on hot surfaces, where freezing can occur, vibrating surface, or floor.
  • Page 15 2 Use #12 x 3 in. (7.5 cm) screws mounted into 2x4 studs or better. 2 screws are needed for a single unit (NHTC 010 to 100). 3 screws are needed for a double unit (NHTC 150 to 200). 3 Keyholes are spaced 16 in. (40.6 cm) apart center to center for large units and 10.7 in.
  • Page 16 Increase size if combining multiple drains as in double unit. *Pipe and water shut-off valve not supplied by NORTEC. Figure 7: Water Supply and Drain Connection Note:  Drain Water is very hot, do not drain to public sink ...
  • Page 17 Part Number 1328810 (7/8”) NORTEC Hose 31-100 (14-45)** <10 <3 Part Number 1328820 (1 3/4”) Note: * These diameters require a reducer at humidifier and steam distributor connection ** Use one steam lines per cylinder for NHTC/PC 150-200 humidifiers. Installation | 14...
  • Page 18 1 This table gives the maximum recommended steam run by unit size. 2 The use of steam line other then copper, stainless steel tube or NORTEC supplied steam line will void the warranty and may adversely effect the operation of the humidifier 3 The NH-150 and NH-200 are dual units.
  • Page 19 Calculated absorption distance to any obstruction or 8-10 ft (2.4 - 3 m) if unknown 2 x duct height min. 2/3 Duct height 12 in. (30 cm) min. Mount distributor to side of duct Figure 10: Distributor Location in Duct Note: Refer to distributor or SAMe installation manuals for detailed installation instructions.
  • Page 20 12 in.(30 cm) min. Radius (Typical) 1 ft (30 cm) 2 in. (5 cm) min. Condensate line ‘P’ Trap 1 ft (30 cm) min. before any bend Figure 12: Steam Distributor Above Humidifier (Hose) Hose will soften Min 12 in. over time (30 cm) proper support...
  • Page 21 Min 12 in . (30 cm) radius Support Brackets Hose will soften over time proper support Is necessary 1ft (30 cm) min. before any bend Obstruction 2 in. (5 cm) 1 ft (30 cm) min. min. 1 ft (30 cm) Use full size condensate tee at low point.
  • Page 22 Electrical Caution: Wiring to be performed by a licensed Electrician. Three Phase NHTC/PC Three Phase Supply Ground Ground Neutral Dedicated Circuit Breaker Fused Disconect Single Phase NHTC/PC Single Phase Supply Ground Ground Note: Optional internal fuses are not a substitute for external fuses.

  • Page 23: Control Wiring

    The NHTC humidifier can be operated with two modulating inputs. The NHPC has one modulating input which can be used for a duct high limit or humidity control. Both the NHTC and NHPC can be operated as On/Off. See Control Setting on page 52 for configuration.

  • Page 24: On/Off Control Wiring

    On/Off Control Wiring Figure 18: On/Off Controls Figure 19: Digital On/Off Humidistat 21 | Installation...
  • Page 25 2520273 - Digital On/Off Duct Humidistat Package Wire remote sensor to digital display as shown below, wire digital display to humidifier as shown above. Air Proving Duct High Digital On/Off Switch Limit Humidistat Duct Sensor Figure 20: Duct Sensor Wiring Installation | 22...

  • Page 26: Modulating Control Wiring

    Ground - 1 1- 24 VAC 2 - On/Off Loop 3 - Ground 4 - Control Signal 5 - Limit Signal (NHTC only) 6 - 5 VDC 7 - Ground 8 - Blower Pack Connect 24 VAC, terminal 9 - Blower Pack 1 of NHTC/PC to terminal 2 of controllers.
  • Page 27 2520261 - Digital Wall W/O Sensor Air Proving Duct High 1509858 - Wall Sensor Switch Limit 2520261 - Digital 1509858 - Wall Wall W/O Sensor Sensor Wire wall sensor to digital display as shown below, wire digital display to humidifier as shown for 1510142 - Digital Wall Humidistat.
  • Page 28 Transducer Control Wiring (NHTC Only) Air Proving Duct High Limit Humidity Control Switch 1509857 - 2-10V Duct 1509858 - 2-10V Wall Humidity Transducer Humidity Transducer Note: 1 Install On/Off controls or jumper between terminal 1 and 2 of humidifier Terminal 1 is 24 VAC Hot, turn unit off to avoid shorting while wiring.

  • Page 29: Optional Outdoor Temperature Reset

    2 - On/Off Loop of the outdoor air temperature. 3 - Ground 4 - Control Signal 5 - Limit Signal (NHTC only) Connect 24 VAC, terminal 1 of NHTC/PC to terminal 6 - 5 VDC 7 - Ground 2 of controllers.

  • Page 30: Remote Fault Option Wiring

    Remote Fault Option Wiring The NHTC (not NHPC) remote fault option includes 4 relays that can provide remote status indication. The relays are mounted to a remote fault board which is located as shown in Figure 28: Remote Fault Wiring. The PCB with the relays includes markings which indicate the function of each terminal on the board.

  • Page 31: Multi Mode Wiring (Nhtc Only)

    Multi Mode Wiring (NHTC Only)  Connect up to 16 units (equivalent of 1600 lb/hr) using 18-24 AWG multi-strand, twisted pair, shielded cable.  Connect humidistats/transducers and On/Off safety loop to master unit only.  When connecting double units connect only to driver board A.

  • Page 32: Options And Accessories

    “P” Trap Figure 30: Remote Mounted Blower Pack Installation of an NHTC/PC with a built on blower pack is identical to installation of an NHTC/PC without a blower pack. The steam line, condensate return and wiring connections to the blower pack have been done at the factory.

  • Page 33: Drain Water Cooling

    Outdoor Model The outdoor model of the NHTC performs in the same way as the indoor model except as noted in the manual addendum that is supplied with it. Refer to additional installation instructions for the outdoor model in the addendum.

  • Page 34: Start Up

    Manual Drain Switch Door Interlock Switch 34 Start Up Procedure 35 Status Screens 36 NORTEC Digital Controls 38 Multi Mode 38 NORTEC LINKS 2 38 NORTEC ONLINE 39 NHTC/PC Pre-Start Up Checklist 40 NHTC/PC Start Up Checklist 31 | Start Up...
  • Page 35 Installation Check Before turning on power to the NHTC, inspect the installation to insure that it was carried out correctly. Refer to Figure 31: Installation Check, to the NHTC/PC Pre-Start Up Checklist on page 39, and to the chapter on Installation that starts on page 9.
  • Page 36 Figure 32: NHTC/PC User Interface Manual Drain Switch In addition to software controlled draining of the cylinder the NHTC/PC has a manual drain switch which can be used to drain the cylinder even if software is not functioning. To drain the cylinder put the switch into the drain position.
  • Page 37 Menu submerged and drawing current. Note: If operated on low conductivity water it may take several hours for the NHTC/PC to reach full output capacity. This is normal. During this time the humidifier will periodically indicate high water level, not perform any drains and will concentrate the cylinder water.
  • Page 38 Status Screens In addition to the main status screen the NHTC/PC includes several status screens which provide additional information about the humidifier. The additional screens can be reached by pressing the buttons corresponding to the left and right arrow key on the LCD display.
  • Page 39 Menu NORTEC Digital Controls NORTEC provides optional On/Off, Modulating Control, or Transducer digital controls. Figure 31 and 32 show the function and meaning of the Digital Control’s display and buttons. All controls are available either wall mounted or with a remote sensor for duct mounting.
  • Page 40 Humidity setpoint is not set at the transducer. The setpoint is set on the NHTC/PC’s display and keypad. Note: It is possible to field calibrate NORTEC Digital controls if the displayed humidity is found to be different than a known trusted source. See Digital Humidistat on page 71 of chapter on Troubleshooting.
  • Page 41 NORTEC ONLINE (NHTC Only) NORTEC ONLINE is an option that can be integrated with the NHTC. It allows a user to log onto the Internet, go to www.norteconline.com and log in to allow them to monitor their unit from any computer with an internet connection.

  • Page 42: Start Up Checklists

    NHTC/PC Pre-Start Up Checklist Unit Serial #: _________________ Tag: _______________ Unit type: _______ __________ Voltage: ________V/_____ph Steam output: ______lb/hr Cylinder type: Customer/Job: Address: Water Quality:  Well water  City water  Softened water  Humidifier Mounting: (Clearances around the unit Acceptable Obstruction) ...

  • Page 43: Nhtc/Pc Start Up Checklist

    NHTC/PC Start Up Checklist Unit Serial #: _________________ Tag: _______________ Unit type: _______ __________ Voltage: ______V/____ph Steam output: ______ lb/hr Cylinder Type: Customer/Job: Address: Preliminary:  Pre-start-up checklist completed? yes  no  If no, perform Pre-Start-up Checklist before starting humidifier.

  • Page 44: Operation

    3 Humidifier Components 4 Description of Components 44 How the Humidifier Works Steam Generation Drains Steam Distribution 45 Selecting an RH Setpoint 47 NHTC Humidifier Configuration Navigating the NHTC Software Main Menu (NHTC Password) Service Level User Defined Settings Control Setting Setting Multi Unit Op.

  • Page 45: Common Warnings

    LED Status Lights The keypad and display panel includes 3 LED’s which provide information about the humidifier’s current status. Fault LED On Indicates the controller has detected a fault condition and stopped humidifier. Check display for fault information. Service LED On Indicates that service may be required or that the water level is high.

  • Page 46: Humidifier Schematic

    Humidifier Schematic Steam Line Steam Distributor Condensate Return Fill Cup Control Board Cylinder Overflow Current Sensor High Water Sensor Electrodes Fill Valve Drain Valve External Air Internal Air Air Gap Figure 36: Humidifier Schematic 43 | Operation...

  • Page 47: Steam Generation

    The unit continues to fill until the current matches demand or the high water sensor detects a high water level.  The NHTC/PC repeats the fill and boil down cycle repeatedly to match output to demand.  Over time minerals in the water will adhere to the cylinder’s electrodes. The humidifier will automatically fill to a higher water level to maintain full capacity during the life of the cylinder.

  • Page 48: Selecting An Rh Setpoint

    Duct High Limit – The duct high limit is intended to prevent saturation and wetting in duct work at high load conditions. NORTEC recommends a setting of 85% for the duct high limit. It may be necessary to reduce this setting If the duct work is very cold or in contact with exterior cold surfaces.
  • Page 49 Steam Line SAM-e Manifold Condensate Drain “P” Trap Figure 37: SAM-e Manifold Blower Pack Steam Line Condensate Drain “P” Trap Figure 38: Remote Blower Pack Operation | 46...

  • Page 50: Navigating The Nhtc Software

    NHTC Humidifier Configuration Navigating the NHTC Software The four input buttons below the digital display are used to navigate in the NHTC’s software and to enter values. The function of the four buttons changes depending on what is being displayed on the screen.

  • Page 51: Service Level

    User Defined Settings The selections in User Defined Settings allow you to configure most user configurable features available with the NHTC. Press Set while highlighting User Defined Settings in the Main Menu. Multi Mode Use Multi Mode to configure the...
  • Page 52 (User Defined Settings Continued) Double Mode (NHTC 150-200 only) User Defined Settings Double Mode Parallel = cylinders operate in Multi Mode :Standalone Parallel parallel from one set of control Parallel Double Mode : Parallel Double Mode : Parallel Parallel signals. Sequenced = cylinders...
  • Page 53 (User Defined Settings Continued) Ground FI User Defined Settings Ground FI When on the contactor will be Drain Cool : On disengaged whenever the drain Dfactor : 1.0 valve is activated to prevent Foam Mode : Off current leakage to the drain. Rapid Modu : Off ShortCyc...
  • Page 54 (User Defined Settings Continued) Overcurr Adjust only if instructed by NORTEC Representative. (Default = 0.00) Date Sets the date. Highlight month/day/year and use the up arrow button to change the value and the right arrow button to move to the next field. Press Set when correct to save changes.

  • Page 55: Control Setting

    Control Settings allow you to set the type of external controls the humidifier is connected to. In most cases the NHTC humidifier is factory configured to operate with the external controls that were specified for the site. Press Set while highlighting Control Settings in the Main Menu.
  • Page 56 Setting The Setting submenu is used to set a manual capacity limit. It is also used to adjust setpoint, the proportional band, and the integral time if REG Mode is set to RH (P) or RH (PI) and wired to humidity sensors.

  • Page 57: Multi Unit Op. Range

    Multi Unit Op. Range The NHTC can be configured to network up to sixteen (16) humidifiers (or equivalent of 1600 lb/hr) using a master slave configuration. To operate the NHTC in multi mode;  ·The humidifiers must be connected in parallel (daisy chained) using the linkup terminal (J2) on the NHTC driver board (See Multi Mode Wiring on page 28).

  • Page 58: Diagnostic Menu

    (Multi Unit Op Range Continued) Full Out Set the system demand at which the humidifier should output its full capacity. Zero Out Set the system demand at which the humidifier should shut off. Diagnostic Menu The Diagnostic Menu provides a historical list of errors and service recorded by the humidifier’s software as well as providing the ability to manually activate humidifier components for troubleshooting purposes.
  • Page 59 (Diagnostic Menu Continued) Remote Test Provides a means for testing of remote fault relays to confirm they are operating correctly. Relays can be activated one at a time. Scroll between relays with up/down arrow buttons and press Set once to turn on relay, press again to turn it off.

  • Page 60: Navigating The Nhpc

    NHPC Humidifier Configuration Navigating the NHPC The four input buttons below the digital display are used to navigate in the NHPC’s software and to enter values. The function of the four buttons changes depending on what is being displayed on the screen. In all cases 4 icons representing the functions of the buttons are shown at the bottom of the screen.
  • Page 61 Dfactor Increases or decreases the drain time used to control cylinder water conductivity. It should not normally need to be adjusted. A NORTEC representative will provide instructions if it should need o be adjusted. (Default = 1.0) Contrast Increases or decreases the...

  • Page 62: Maintenance And Servicing

    Maintenance and Servicing 60 Required Maintenance Cylinder Spent Warning / Fault Replacement Cylinder Removing the Cylinder Drain Valve Cleaning Installing the New Cylinder 65 Extended Shutdown Starting After Extended Shutdown 66 NHTC/PC Maintenance Checklist 59 | Maintenance and Servicing...

  • Page 63: Cylinder Spent Warning / Fault

    Failure to replace the cylinder at the end of cylinder life will cause the unit to lock out. NORTEC is not responsible for any damages resulting from, or attributed to, the failure to replace a spent cylinder (see Manufacturer’s Warranty).

  • Page 64: Replacement Cylinder

    Figure 42: NHTC/PC Cylinder Note: NORTEC recommends keeping several replacement cylinders in stock throughout the humidification season. This will prevent possible downtime when the humidifier reports cylinder end of life. 61 | Maintenance and Servicing...

  • Page 65: Removing The Cylinder

    Removing the Cylinder Warning  Disconnect main power at the external disconnect before any servicing.  The plumbing and electrical compartments contain high voltage components and wiring. Access should be limited to authorized personnel.  Cylinder may be hot, take care when handling. 1 Drain the existing cylinder.

  • Page 66: Drain Valve Cleaning

    Drain Valve Cleaning Always clean the drain valve before installing a new cylinder. Scale from the spent cylinder may have fallen into the drain valve and could prevent its proper operation. To properly clean the drain valve it must be removed and disassembled. Note: Be sure to reattach the green ground wire to reduce the risk of electrical shock.

  • Page 67: Installing The New Cylinder

    Plunger Spring (Note Orientation) Sleeve Solenoid Figure 45: Drain Valve Actuator Assembly Installing the New Cylinder CAUTION: Make sure the new cylinder is the same model as the one that was removed. Model number is on top left corner of cylinder label. 1 Insert cylinder into drain valve.

  • Page 68: Starting After Extended Shutdown

    4 Shut off power to the humidifier with the external disconnect. 5 Close the supply water shut-off valve. Note: As long as the NHTC/PC is powered, it will automatically drain the cylinder when there has not been a call for humidity for an extended period of time. This feature will reduce or prevent the possibility of corrosion of the electrodes and the accumulation of algae and bacteria growing in the cylinder.

  • Page 69: Nhtc/Pc Maintenance Checklist

    NHTC/PC Maintenance Checklist Model #: _________________ Serial #: _________________ Tag: ________ Cylinder #: Cylinder / System Check    W19 Cylinder Spent E19 Cylinder Spent (If software displays W19 or E19 then cylinder must be replaced)   Yellow LED On with W12- Sensor On Warning.

  • Page 70: Troubleshooting

    68 Organization of Troubleshooting Chapter Troubleshooting Requirements 69 General Troubleshooting Humidifier Steam Distributors SAM-e Blower Pack Digital Humidistat 72 NHTC/PC Warnings and Faults Warnings Faults Clearing a Fault 79 NHTC/PC Wiring Diagram (Cylinder A) 80 NHTC/PC Wiring Diagram (Cylinder B) 67 | Troubleshooting...

  • Page 71: Organization Of Troubleshooting Chapter

     Wiring diagram for specific for your humidifier is installed on the inside of the humidifier door. A generic copy of the NHTC/PC wiring diagram is also included at the end of this chapter for reference purposes.  When contacting your local representative or NORTEC for troubleshooting assistance, please ensure the serial number has been obtained for reference purposes.
  • Page 72 The following section provides general guidelines for troubleshooting the NHTC/PC humidifier and auxiliary components. For detailed troubleshooting information refer to the manuals that were provided with the auxiliary equipment and to Table 8: Troubleshooting NHTC/PC Warnings and Faults later in this chapter.

  • Page 73: Steam Distributors

    If operated on low conductivity water it may take several hours for the NHTC/PC to reach full output capacity. This is normal. During this time the humidifier will not perform any drains and the conductivity of the water in the cylinder will increase.

  • Page 74: Blower Pack

    SAM-e Symptom Cause Corrective Action(s) SAM-e spitting out water 1 “P” Trap too close to SAM-e 1 “P” trap must be at least 12 in (30 cm) below header. Relocate if required. 2 Condensate line not sloped 2 Ensure line is sloped sufficiently to sufficiently carry condensate produced.
  • Page 75 NHTC/PC Warnings and Faults The self-diagnostic system built into the NHTC/PC is continually monitoring the operation of the humidifier. Warnings  When problem symptoms are detected, the NHTC/PC will attempt to take self-corrective actions to try to correct the problem. A warning is displayed on the screen for information purposes and the humidifier continues to operate.
  • Page 76 Display System Detected Cause Corrective Action(s) Message 4 Incorrect wire type used 4 Use 18-24 AWG multi- Cont strand, twisted pair, shielded cable 1 Software has detected 1 Restart humidifier, if a hardware problem error occurs within 1 with main control board minute replace main control board.
  • Page 77 Over Current exceeded 115% model as the one of max removed. 5b Check water conductivity and check with Nortec representative for alternate cylinder. 6 Condensate from Other 6 Remove any condensate source feeding to lines that are not from humidifier the humidifier’s steam...
  • Page 78 Display System Detected Cause Corrective Action(s) Message 5 Water supply too 5a Contact NORTEC conductive representative for recommendation on alternate cylinder 5b Change the water Current has Excess Current supply exceeded 130% of max 6 Wrong cylinder installed 6 Install correct cylinder...
  • Page 79 3 Check if sensor is outputting corresponding to RH. If not replace the sensor. 4 RH less than 5% 4 RH less than 5% are interpreted as a broken sensor. Contact NORTEC Limit Sensor Representative for Broken No signal from recommendation. RH Limit sensor...
  • Page 80 Display System Detected Cause Corrective Action(s) Message 1 Improper Proportional 1 Adjust proportional and and Integral settings in integral settings to control reduce swings in demand signal. Demand swinging Demand signal 2 Control humidistat 2 Install humidistat so that from low to high instability installed too close to it senses air...
  • Page 81 Display System Detected Cause Corrective Action(s) Message 1 Setpoint higher than 1 If the humidifier is still RH higher than RH High Warning RH alarm setting operating then check and high RH setpoint adjust setpoints. 1 Humidifier not running 1 Check why humidifier is not running and put it RH Lower than into operation.

  • Page 84: Spare Parts

    Spare Parts 82 Distributor Spare Parts 83 NHTC/PC 005-030 Plumbing Parts 85 NHTC/PC 050-200 Plumbing Parts 87 NHTC/PC 005-030 Electrical Parts 89 NHTC./PC 050-200 Electrical Parts 92 Warranty 81 | Spare Parts...

  • Page 85: Distributor Spare Parts

    Distributor Spare Parts ASD & BSD 1506162 - Distributor End Cap Assembly 1506164 - Distributor End Cap Assembly Distributor Core ASD & BSD 1506161 - Distributor Inlet Assembly 1506163 - Distributor Inlet Assembly Figure 46: Distributor Exploded View and Spare Parts Spare Parts| 82...

  • Page 86: Nhtc/Pc 005-030 Plumbing Parts

    NHTC/PC 005-030 Plumbing Parts Figure 47: NHTC/PC 005-030 Plumbing Parts 83 | Spare Parts...
  • Page 87 Table 9: NHTC/PC 005-030 Plumbing Parts List SINGLE PHASE THREE PHASE MODEL Volts/Ph NORTEC PART NO. DESCRIPTION 1519001 CYLINDER 201 CYLINDER 202 1519002 CYLINDER 203 1519003 CYLINDER 204 1519004 1519020 CYLINDER 321 1519025 CYLINDER 305 1519029 CYLINDER 309 1519031 CYLINDER 311...

  • Page 88: Nhtc/Pc 050-200 Plumbing Parts

    NHTC/PC 050-200 Plumbing Parts Figure 48: NHTC/PC 050-200 Plumbing Parts 85 | Spare Parts...
  • Page 89 Table 10: NHTC/PC 050-200 Plumbing Parts List THREE PHASE MODEL Volts/Ph NORTEC PART NO. DESCRIPTION CYLINDER 621 1519080 CYLINDER 603 1519083 CYLINDER 607 1519087 CYLINDER 605 1519085 CYLINDER 609 1559089 CYLINDER 617 1519097 CYLINDER 631 1519191 CYLINDER 636 1519196 CLAMP FOR LARGE STEAM...

  • Page 90: Nhtc/Pc 005-030 Electrical Parts

    NHTC/PC 005-030 Electrical Parts Figure 49: NHTC/PC 005-030 Electrical Parts 87 | Spare Parts...
  • Page 91 Table 11: NHTC/PC 005-030 Electrical Parts List SINGLE PHASE THREE PHASE MODEL Volts/Ph NORTEC ITEM PART NO. DESCRIPTION CONTACTOR 30 AMP 1PH 1453013 CONTACTOR 30 AMP 3PH 1323013 CONTACTOR 40 AMP 3PH 1323014 TERMINAL BLOCK 2 POLE 1323001 TERMINAL BLOCK 3 POLE...

  • Page 92: Nhtc./Pc 050-200 Electrical Parts

    NHTC./PC 050-200 Electrical Parts Figure 50: NHTC/PC 050-200 Electrical Parts 89 | Spare Parts...
  • Page 93 Table 12: NHTC/PC 050-200 Electrical Parts THREE PHASE MODEL Volts/Ph NORTEC ITEM PART NO. DESCRIPTION 1323013 CONTACTOR 30 AMP 3PH 1323014 CONTACTOR 40 AMP 3PH 1323015 CONTACTOR 62 AMP 3PH TERMINAL BLOCK 3 POLE 1323027 95 AMP TERMINAL BLOCK 3 POLE...
  • Page 94 91 | Warranty...

  • Page 95: Warranty

    Warranty Walter Meier Inc. and/or Walter Meier Ltd. (hereinafter collectively referred to as THE COMPANY), warrant for a period of two years after installation or 30 months from manufacturer’s ship date, whichever date is earlier, that THE COMPANY’s manufactured and assembled products, not otherwise expressly warranted (with the exception of the cylinder), are free from defects in material and workmanship.
  • Page 96 U.S.A. Walter Meier (Climate USA) Inc. 826 Proctor Avenue Ogdensburg, NY 13669 CANADA Walter Meier (Climate Canada) Ltd. 2740 Fenton Road Ottawa, Ontario K1T 3T7 TEL: 1.866.NORTEC1 FAX: 613.822.7964 EMAIL: nortec@waltermeier.com WEBSITE: www.humidity.com Certificate No. 002419...
