Nortec NHTC Series Installation Manual

Nortec humidifier installation manual
Hide thumbs Also See for NHTC Series:
Table of Contents

Advertisement

Quick Links

Manual No. H-502
2008-02-18
NHTC NORTEC
LINKS 2 OPTIONS
Installation Manual
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NHTC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nortec NHTC Series

Summary of Contents for Nortec NHTC Series

  • Page 1 Manual No. H-502 2008-02-18 NHTC NORTEC LINKS 2 OPTIONS Installation Manual...

  • Page 2: Proprietary Notice

    PROPRIETARY NOTICE This document and the information disclosed herein are proprietary data of WALTER MEIER LTD. Neither this document nor the information contained herein shall be reproduced used, or disclosed to others without the written authorization of WALTER MEIER LTD., except to the extent required for installation or maintenance of recipient’s equipment.

  • Page 3: Table Of Contents

    Subject 10-00 INTRODUCTION OVERVIEW ................2 10-10 INSTALLATION PROCEDURES NETWORKING .
  • Page 4 Sample Humidification Applications - Control Feedback (0-100%) with Duct Hi-Limit Sensing ..16 Figure 3. Sample Humidification Applications - 0-10V Signal Directly to Humidifier) ....17 10-30 TROUBLESHOOTING Figure 1.
  • Page 5 THIS PAGE INTENTIONALLY LEFT BLANK 2008-02-18...

  • Page 6: Introduction

    10-00 INTRODUCTION 10-00 Page 1 2008-02-18...

  • Page 7: Overview

    (1) OVERVIEW (1) The NHTC Nortec LINKS 2 Option allows for the integration of a NHTC Series humidifier within a BACnet, Johnson N2 or LonWorks network and allows those units to concurrently be monitored via the Nortec OnLine interface. This option features a...

  • Page 8: Installation

    10-10 INSTALLATION 10-10 Page 1 2008-02-18...

  • Page 9: Networking

    (1) NETWORKING (1) It is possible to network up to a maximum of 8 units to a single LINKS 2. Since each unit is separately addressed, it is possible to monitor and control each unit individually. Different networking configurations may be achieved and are mostly dependant on the type of network present at the site.

  • Page 10: Wiring

    A and B. To network multiple units to a single Gateway, the units may be daisy-chained to each other using the network link terminals at the TB3 connection jack on the humidifier logic board. Refer to wiring diagram in section 10-50.

  • Page 11: Gateway Configuration

    LonWorks device possesses. The .xif file allows a network integrator to simulate the presence of a networked humidifier even if it is not yet physically connected to the network. In fact, if the integrator has the .xif files of all network devices, a complete system could be simulated and...

  • Page 12: Variable Definition

    (5) VARIABLE DEFINITION In the variable name, “_x” denotes the humidifier number. If there is only one GSTC humidifier, all variable names will end in “_1”. If two units are networked together (see Figure 4), the second unit’s variable names will end in “_2”. For 3 networked units, “_3”...

  • Page 13: Table 3. Variable Definitions

    Analogue Value nviSet2_x Analogue Value Table 3. Variable Definitions Description Indicates the number of hours the humidifier cylinder has been in operation. Reads to capacity limitation applied to the unit output. (50-100%) Reads Ch.1 input signal in %RH or demand to humidifier.
  • Page 14 Page 7 2008-02-18 Description Indicates unit fault status. 0=no fault, 1=fault. Indicates if a high-water level condition exists in the humidifier cylinder. 0=normal, 1=high water condition Reads configuration status for network-enabled sensing or control. 0=%RH or %demand input is not...
  • Page 15 Table 4. Humidifier Variable Addresses NHTC LINKS 2 Variable Listing Default BACnet/IP Address: 192.168.10.11; Subnet: 255.255.255.0 Default BACnet/MSTP Address: 78 Default Johnson N2 Address: 174 Unit #1 BACnet Variable Name Type Instance nvoHourOpt_1 nvoCapLimit_1 nvoRHDem1_1 nvoSet1_1 nvoRHDem2_1 nvoSet2_1 nvoSysDemand_1 nviCapLimit_1...
  • Page 16 Table 5. Humidifier Variable Addresses Unit #2 BACnet Variable Name Type Instance nvoHourOpt_2 nvoCapLimit_2 nvoRHDem1_2 nvoSet1_2 nvoRHDem1_2 nvoSet2_2 nvoSysDemand_2 nviCapLimit_2 nviSet1_2 nviSet2_2 nviRHDem1_2 nviRHDem2_2 nviDisable_1 Expansion_2 Expansion_2 nvoFault_2 nvoHWSensor_2 nvoNetSensor_2 nvoDisable_2 nvoSecurity_2 nvoService_2 nvoStatus_2 Expansion_2 nviNetSensor_2 nvoConnection_2 Expansion_2 Expansion_2 Expansion_2...
  • Page 17 Table 6. Humidifier Variable Addresses Unit #3 BACnet Variable Name Type Instance nvoHourOpt_3 nvoCapLimit_3 nvoRHDem1_3 nvoSet1_3 nvoRHDem1_3 nvoSet2_3 nvoSysDemand_3 nviCapLimit_3 nviSet1_3 nviSet2_3 nviRHDem1_3 nviRHDem2_3 nviDisable_3 Expansion_3 Expansion_3 nvoFault_3 nvoHWSensor_3 nvoNetSensor_3 nvoDisable_3 nvoSecurity_3 nvoService_3 nvoStatus_3 Expansion_2 nviNetSensor_3 nvoConnection_3 Expansion_3 Expansion_3 Expansion_3...
  • Page 18 Table 7. Humidifier Variable Addresses Unit #4 BACnet Variable Name Type Instance nvoHourOpt_4 nvoCapLimit_4 nvoRHDem1_4 nvoSet1_4 nvoRHDem1_4 nvoSet2_4 nvoSysDemand_4 nviCapLimit_4 nviSet1_4 nviSet2_4 nviRHDem1_4 nviRHDem2_4 nviDisable_4 Expansion_4 Expansion_4 nvoFault_4 nvoHWSensor_4 nvoNetSensor_4 nvoDisable_4 nvoSecurity_4 nvoService_4 nvoStatus_4 Expansion_2 nviNetSensor_4 nvoConnection_4 Expansion_4 Expansion_4 Expansion_4...
  • Page 19 Table 8. Humidifier Variable Addresses Unit #5 BACnet Variable Name Type Instance nvoHourOpt_5 nvoCapLimit_5 nvoRHDem1_5 nvoSet1_5 nvoRHDem1_5 nvoSet2_5 nvoSysDemand_5 nviCapLimit_5 nviSet1_5 nviSet2_5 nviRHDem1_5 nviRHDem2_5 nviDisable_5 Expansion_5 Expansion_5 nvoFault_5 nvoHWSensor_5 nvoNetSensor_5 nvoDisable_5 nvoSecurity_5 nvoService_5 nvoStatus_5 Expansion_2 nviNetSensor_5 nvoConnection_5 Expansion_5 Expansion_5 Expansion_5...
  • Page 20 Table 9. Humidifier Variable Addresses Unit #6 BACnet Variable Name Type Instance nvoHourOpt_6 nvoCapLimit_6 nvoRHDem1_6 nvoSet1_6 nvoRHDem1_6 nvoSet2_6 nvoSysDemand_6 nviCapLimit_6 nviSet1_6 nviSet2_6 nviRHDem1_6 nviRHDem2_6 nviDisable_6 Expansion_6 Expansion_6 nvoFault_6 nvoHWSensor_6 nvoNetSensor_6 nvoDisable_6 nvoSecurity_6 nvoService_6 nvoStatus_6 Expansion_6 nviNetSensor_6 nvoConnection_6 Expansion_6 Expansion_6 Expansion_6...
  • Page 21 Table 10. Humidifier Variable Addresses Unit #7 BACnet Variable Name Type Instance nvoHourOpt_7 nvoCapLimit_7 nvoRHDem1_7 nvoSet1_7 nvoRHDem1_7 nvoSet2_7 nvoSysDemand_7 nviCapLimit_7 nviSet1_7 nviSet2_7 nviRHDem1_7 nviRHDem2_7 nviDisable_7 Expansion_7 Expansion_7 nvoFault_7 nvoHWSensor_7 nvoNetSensor_7 nvoDisable_7 nvoSecurity_7 nvoService_7 nvoStatus_7 Expansion_7 nviNetSensor_7 nvoConnection_7 Expansion_7 Expansion_7 Expansion_7...
  • Page 22 Table 11. Humidifier Variable Addresses Unit #8 BACnet Variable Name Type Instance nvoHourOpt_8 nvoCapLimit_8 nvoRHDem1_8 nvoSet1_8 nvoRHDem1_8 nvoSet2_8 nvoSysDemand_8 nviCapLimit_8 nviSet1_8 nviSet2_8 nviRHDem1_8 nviRHDem2_8 nviDisable_8 Expansion_8 Expansion_8 nvoFault_8 nvoHWSensor_8 nvoNetSensor_8 nvoDisable_8 nvoSecurity_8 nvoService_8 nvoStatus_8 Expansion_8 nviNetSensor_8 nvoConnection_8 Expansion_8 Expansion_8 Expansion_8...

  • Page 23: Figure 1. Sample Humidification Applications Room-Sensed %Rh Feedback With Duct Hi-Limit Sensing

    Configuration Variables nviInputType_x = 1 nviNetSensor_x = 1 Control Variables nviSet1_x = Room Setpoint (0-100%) nviSet2_x = Hi-Limit Setpoint (0-100%) nviRHDem1_x = Room %RH (0-100%) nviRHDem2_x = Hi-Limit %RH (0-100%) nviDisable_x = 1 Unit Disabled = 0 Unit Enabled Readable Variables nvoStatus_x = 1 Humidifying = 0 Standby nvoService_x = 1 Service Required...
  • Page 24 = 1 Fault = 0 No Fault nvoSysDemand_x = System Demand(0-100%) nvoDisable_x = 1 Unit Disabled = 0 Unit Enabled Figure 3. Sample Humidification Applications Room-Sensed %RH Feedback with Duct Hi-Limit Sensing (0-10V Signal Directly to 10-10 Page 17 2008-02-18 NHTC Humidifier)
  • Page 25 THIS PAGE INTENTIONALLY LEFT BLANK 10-10 Page 18 2008-02-18...

  • Page 26: Start-Up

    10-20 START-UP 10-20 Page 1 2008-02-18...

  • Page 27: Nortec Links 2 Start-Up Checklist

    Directly to humidifiers or through BMS network. (2) START-UP PROCEDURE (1) Ensure power is being supplied to the humidifier, Nortec Links Module and Nortec OnLine module. For BACnet/IP adjust network IP settings. (If this information is provided, factory will perform necessary IP assignment).

  • Page 28: Troubleshooting

    10-30 TROUBLESHOOTING 10-30 Page 1 2008-02-18...

  • Page 29: Indicator Lights

    (1) TROUBLESHOOTING (1) When troubleshooting the communication process for OnLine and/or LINKS 2 modules should be kept in mind. Humidifier data is first received by the Nortec OnLine module using the modbus protocol over the serial port connection. It then forwards this data, via modbus/TCP, to the LINKS 2 module over an Ethernet link.

  • Page 30: Figure 1. Online Diagnostic Led Locations

    Figure 1. OnLine Diagnostic LED Locations Lon Device Status RX – Receive LED TX – Transmit LED Figure 3. LonWorks Module LED 10-30 Page 3 2008-02-18 Module RX – Receive LED Status Serial Port Activity Ethernet Activity Ethernet TX – Transmit LED Link Figure 2.

  • Page 31: Table 1. Online Diagnostic Led Description

    Table 1. OnLine Diagnostic LED Description LED Name Module Status Serial Port Activity Ethernet Activity/Collision Ethernet Link Color Indicates that the Online module is not receiving power. Green Indicates the Online module is operating normally. Orange Indicates that the Online module is loading the firmware installed on the module.

  • Page 32: Table 2. Links 2 Module Diagnostic Leds

    Table 2. LINKS 2 Module Diagnostic LEDs LED Name Module Power Receive LED (marked as Rx on processor board) Transmit LED (marked as Tx on processor board) Ethernet LINK Ethernet Activity 10-30 Page 5 2008-02-18 Color Function Indicates that the Online module is not receiving power.

  • Page 33: Table 3. Troubleshooting Communication Problems

    When a BMS network demand/RH signal is being used the network must refresh the nviRHDem signal at least every 5 minutes otherwise the humidifier will revert to a 0 demand state. This is a safety precaution in case the BMS network connection is lost.

  • Page 34: Spare Parts

    10-40 SPARE PARTS 10-40 Page 1 2008-02-18...

  • Page 35: Table 1. Replacement Parts

    Part Number Description LINKS 2 Replacement Module, 2527101 BACnet/IP LINKS 2 Replacement Module, 2527102 BACnet/MSTP LINKS 2 Replacement Module, 2527103 LonWorks 2527104 LINKS 2 Replacement Module, N2 1509604 OnLine Replacement Module, Static/IP 2528126 LINKS 2 Replacement Router 2531455 LINKS 2 Ethernet Switch 24VAV to 9VDC Power Supply (for 2530087 switch or router)

  • Page 36: Figure 1. Bacnet Or N2 Module

    Figure 1. BACnet or N2 Module Figure 2. LonWorks Module Figure 3. OnLine Module Figure 4. Ethernet Router 10-40 Page 3 2008-02-18...
  • Page 37 Figure 5. Ethernet Switch 10-40 Page 4 2008-02-18...
  • Page 38 10-50 TECHNICAL 10-50 Page 1 2008-02-18...
  • Page 39 External wiring ‘by others’ - 18 to 24 AWG stranded - Twisted pair, shielded Nortec LINKS 2 Terminal Strip (Unit 1) NHTC Processor Board DC Power Supply 24 VAC HOT 9 VDC OUT Note: Use open LAN port when employing an internet connection for BACnet/IP and/or Nortec OnLine.
  • Page 40 External wiring ‘by others’ - 18 to 24 AWG stranded - Twisted pair, shielded To BMS Network Nortec LINKS 2 Terminal Strip (Unit 1) NHTC Processor Board DC Power Supply Note: Use Router WAN port when employing an internet connection for OnLine. Use A and B terminals for LonWorks feedback.
  • Page 41 External wiring ‘by others’ - 18 to 24 AWG stranded - Twisted pair, shielded To BMS Network Nortec LINKS 2 Terminal Strip (Unit 1) NHTC Processor Board DC Power Supply 24 VAC HOT 9 VDC OUT Note: Use Router WAN port when employing an internet connection for OnLine.
  • Page 42 THIS PAGE INTENTIONALLY LEFT BLANK 10-50 Page 5 2008-02-18...

  • Page 43: Warranty

    F.O.B. THE COMPANY’s factory, providing the defective part(s) is returned freight prepaid by the customer. Parts used for repairs are warranted for the balance of the term of the warranty on the original humidifier or 90 days, whichever is longer.

  • Page 44: Installation

    INSTALLATION DATE (MM/DD/YYYY) MODEL # SERIAL # U.S.A. Walter Meier (Climate USA) Inc. 826 Proctor Avenue Ogdensburg, NY 13669 TEL: 1-866-NORTEC-1 EMAIL: northamerica.climate@waltermeier.com WEBSITE: www.humidity.com CANADA Walter Meier (Climate Canada) Ltd. 2740 Fenton Road Ottawa, ON K1T 3T7 TEL: 1-866-NORTEC-1 FAX: (613) 822-7964 Authorized Agent:...
