- Page 1 Manual No. H-504 2008-02-15 RETROFIT INSTRUCTIONS FOR GSTC / SETC / NHTC / NHDI / NHSC Installation Manual...
-
Page 2: Proprietary Notice
PROPRIETARY NOTICE This document and the information disclosed herein are proprietary data of WALTER MEIER LTD. Neither this document nor the information contained herein shall be reproduced used, or disclosed to others without the written authorization of WALTER MEIER LTD., except to the extent required for installation or maintenance of recipient’s equipment. -
Page 3: Table Of Contents
NHDI LINKS 2 Slave Installation ........ - Page 4 10-00 LINKS 2 - FIELD INSTALLATION OF A SE-50 10-00 Page 1 2008-02-02...
-
Page 5: Step 1 - Installation
(1) Since Nortec LINKS 2 can connect to a maximum of 8 units, it will be necessary to set the unit address for each humidifier. The lead unit can be determined by the presence of the LINKS 2 module. The slave humidifiers can be given a unit address according to the number the unit will have on the networked chain. - Page 6 10-10 LINKS 2 - FIELD CONVERSION OF A GSTC/SETC 10-10 Page 1 2008-02-15...
-
Page 7: Wiring The Nortec Links 2 Module
(1) Most of the wiring connections for the new Nortec LINKS 2 module will have already been finished at the factory, however, there are a few connections that will need to be made to connect the unit the GS/SE series humidifier. Refer the LINKs 2 wiring diagram included in the package for details. -
Page 8: Mounting The Links 2 Assembly
Refer to Figure 2 for the mounting location of the Nortec LINKS 2 Bracket on the GS or SE unit. If pilot holes for the mounting screws are not already present on the humidifier frame follow steps 2 and 3. If pilot holes are present then disregard steps 2 and 3. -
Page 9: Configuring The Humidifiers
Since Nortec LINKS 2 can connect to a maximum of 8 units, it will be necessary to set the unit address for each humidifier. The lead unit can be determined by the presence of the Links module. The slave humidifiers can be given a unit address according to the number the unit will have on the networked chain. - Page 10 10-20 LINKS 2 - FIELD CONVERSION OF A NHTC 10-20 Page 1 2008-02-15...
-
Page 11: Bacnet, Lonworks And N2 Modules
(2) Ensure that the rear, upwards facing hook engages the proper cooling louver at the back of the humidifier cabinet. Fasten the bracket assembly to the humidifier ‘top’ using the 3 8-32 X ½” self- tapping screws provided with the kit. -
Page 12: Figure 3. Assembly Mounting Location
Figure 3. Assembly Mounting Location 10-20 Page 3 2008-02-15 Figure 2. Hook Position Hook Position Hook Position... - Page 13 Since Nortec LINKS 2 can connect to a maximum of 8 units, it will be necessary to set the unit address for each humidifier. The lead unit can be determined by the presence of the Links module. The slave humidifiers can be given a unit address according to the number the unit will have on the networked chain.
- Page 14 10-30 LINKS 2 - FIELD CONVERSION OF A NHDI/SC 10-30 Page 1 2008-02-15...
-
Page 15: Mount The Links 2 Assembly
(1) Refer to Figure 2 for the mounting location of the Nortec LINKS 2 Bracket on the NHDI or NHSC unit. If pilot holes for the mounting screws are not already present on the humidifier frame follow steps 2 and 3. If pilot holes are present then disregard steps 2 and 3. -
Page 16: Wiring The Nortec Links 2 Module
Most of the wiring connections for the Nortec LINKS 2 module will have already been finished at the factory, however, there are a few connections that will need to be made to connect the module to the NHDI/SC series humidifier. Refer the LINKS 2 wiring diagram included in the package for details. -
Page 17: Figure 3. Nhdi Links 2 Slave Installation
In addition a terminal strip is provided to allow the humidifiers to be wired back to the master module. Mount the LINKS slave option on any humidifier that will be connected to the master module. The slave option mounts in the same location as the master LINKS module. - Page 18 Net + terminal on the LINKS module connects to the Net+ terminal of the NHDI/SC slave option. The Net – terminal on the LINKS 2 module should also be connected to the Net- terminal of the slave option.
-
Page 19: Warranty
F.O.B. THE COMPANY’s factory, providing the defective part(s) is returned freight prepaid by the customer. Parts used for repairs are warranted for the balance of the term of the warranty on the original humidifier or 90 days, whichever is longer. - Page 20 INSTALLATION DATE (MM/DD/YYYY) MODEL # SERIAL # CYLINDER # U.S.A. Walter Meier (Climate USA) Inc. 826 Proctor Avenue Ogdensburg, NY 13669 TEL: 1-866-NORTEC-1 EMAIL: nortec@humidity.com WEBSITE: www.humidity.com Authorized Agent: CANADA Walter Meier (Climate Canada) Ltd. 2740 Fenton Road Ottawa, ON K1T 3T7 TEL: 1-866-NORTEC-1 FAX: (613) 822-7964...
