Billy Goat F902S Owner's Manual

Force blower push
Hide thumbs Also See for F902S:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Accessories
HOLD DOWN KIT
To secure blower for
transportation on
trailer floors.
P/N 440120
Part No 440270
FORCE BLOWER PUSH Owner's Manual
Patent #6,253,416 and other patents pending
F902S, F902H, F1302H, F1802V
BILLY GOAT FORCE BLOWER
Owner's Manual
SOLID FRONT TIRE
Solid flat-free front tire.
P/N 440279
PARKING BRAKE
Effective and Easy to
use to prevent blower
from rolling.
P/N 440140
1
CASTER KIT
For greater
maneuverability on
hard surfaces.
P/N 440293
Form No F041510A

Advertisement

Table of Contents
loading

Related Manuals for Billy Goat F902S

Summary of Contents for Billy Goat F902S

  • Page 1 FORCE BLOWER PUSH Owner’s Manual Patent #6,253,416 and other patents pending F902S, F902H, F1302H, F1802V BILLY GOAT FORCE BLOWER Owner's Manual Accessories HOLD DOWN KIT CASTER KIT SOLID FRONT TIRE PARKING BRAKE To secure blower for For greater Solid flat-free front tire.

  • Page 2: Table Of Contents

    FORCE BLOWER PUSH Owner’s Manual ABOUT THIS MANUAL ® THANK YOU for purchasing a BILLY GOAT FORCE Blower. Your new machine has been carefully designed and manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your FORCE Blower in top running order.

  • Page 3: Serial Plate Data And Specifications

    FORCE BLOWER PUSH Owner’s Manual SERIAL PLATE DATA Record the model number, serial number, date of purchase, and where purchased. Purchase Date: Purchased From: Specifications F902S F902H F1302H F1802V Engine: HP 9.0 HP (6.6kW) 9.0 HP (6.6kW) 13.0 HP (9.6kW) 18 HP (13.42kW)

  • Page 4: General Safety

    This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. ® This symbol indicates important information that will prevent damage to your BILLY GOAT FORCE Blower. This symbol indicates the engine oil level should be checked before operating this equipment.
  • Page 5 FORCE BLOWER PUSH Owner’s Manual DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling. DO NOT store gasoline near an open flame.

  • Page 6: Sound And Vibration

    FORCE BLOWER PUSH Owner’s Manual SOUND SOUND LEVEL 97 Db(a) at Operators Position 117 dB Sound tests were conducted in accordance with 2000/14/EC, as well as ISO 11094, and were performed on 12-12- 2006 under the conditions listed below. Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for the sound power level for your model.

  • Page 7: Instruction Labels

    FORCE BLOWER PUSH Owner’s Manual INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT FORCE Blower. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels.

  • Page 8: Packing Checklist

    Warranty card P/N- 400972, Owner’s Manual P/N-440270, Declaration of Conformity P/N-440022, Handle Hardware-Items #10, #11, #74, #71 and #36 Boxing Parts Checklist Front Air Diverter (For F902S, F902H, and F1302H models only) Item#38 P/N-440045 Handle Upper Assembly Item #30 P/N-440035 Parts Bag &...

  • Page 9: Assembly

    FORCE BLOWER PUSH Owner’s Manual ASSEMBLY 1.Follow the steps in figures A and B, then securely tighten all hardware shown. 2.Connect spark plug wire. Figure A Figure B The hardware for attaching the upper handle to the lower The throttle control will be attached to the throttle arm on is in the parts bag.

  • Page 10: Operation

    Never lift the machine while the engine is running. BLOWING OPERATION Your Billy Goat Force blower is equipped with an air director cone and the patented Aim-N-Shoot control lever to allow the operator to direct the air stream up or down as required to assist in moving debris. This feature is extremely useful when debris has piled up to the point that it cannot be blown any farther.

  • Page 11: Operation

    FORCE BLOWER PUSH Owner’s Manual ADJUSTING AIR DIRECTOR To adjust air direction, squeeze Aim-N-Shoot control lever. When you want to blow debris at the same angle for an extended period, choose a suitable position and use the finger controlled push button lock to lock the cone in position. For operations that do not require the use of the Aim-N-Shoot feature the manual adjustment knob, pictured below, can be used to permanently lock the cone into position.

  • Page 12: Maintenance

    FORCE BLOWER PUSH Owner’s Manual MAINTENANCE ERIODIC AINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Daily or Every Every 25 Every 50 Every 5 Hours Hours Hours 100-150 Hours Inspect for worn or damaged parts. Check for excessive vibration Inspect Impeller for cracks or damage Inspect for loose parts.

  • Page 13: Troubleshooting And Warranty Procedure

    The machine must be taken to the dealer from whom it was purchased or to an authorized Servicing BILLY GOAT Dealer.

This manual is also suitable for:

F1302hF902hF1802v
