Summary of Contents for Billy Goat F6
- Page 1 Force Blower Operator's Manual Models F602X F602V Billy Goat F6 Force Blower Operator's Manual 27441502EN_B...
-
Page 2: Table Of Contents
Table of Contents: Identifying Your Unit ............3 Operating Safely..............3 Preparation............... 3 Decals................4 Initial Setup................6 Install the Front Wheel............. 6 Install the Upper Handle..........6 Secure the Aim-N-Shoot Cable........7 Operation................7 Before Operation.............. 7 Controls................8 Directing Air Flow............. 8 Maintenance Procedures............. -
Page 3: Identifying Your Unit
Identifying Your Unit Operating Safely Thank you for purchasing this quality piece of outdoor power Congratulations on purchasing a superior-quality piece of equipment. Please note that throughout this manual, all lawn and garden equipment. Our products are designed and instances of LEFT and RIGHT are referenced from the manufactured to meet or exceed all industry standards for operator's position. -
Page 4: Decals
Decals 100443 440332 Pull up on the control to direct air flow upwards. Push down on the control to direct air flow downwards. 5110550 Thrown Objects A. 100443 B. 440332 C. 5110550 D. 80133770 Warning: Thrown objects hazard. Do not use without a chute E. -
Page 5: Breathing Protection
Keep Distance Eye Protection Warning Thrown Objects Hazard: This unit is capable of Damage to the eyes hazard. Always wear personal protective throwing objects and debris. Keep bystanders away. equipment when operating. 80133770 Breathing Protection Dust inhalation hazard: Always wear personal protective equipment when operating. -
Page 6: Initial Setup
80133778 Training Required Do not operate this machine unless you are trained. Consult technical literature before performing technical repairs or maintenance. Avoidance Look behind while moving unit in reverse. Be aware of your 3. Place the wheel into the front wheel bracket. Line up the surroundings at all times. -
Page 7: Secure The Aim-N-Shoot Cable
Secure the Aim-N-Shoot Cable 1. Unroll the Aim-N-Shoot cable. Thread the cable to the outside of the machine and up to the handle. Manually push down on the air director cone (See Figure 5) to release extra length on the ball end of the cable (A, Figure 6). -
Page 8: Controls
Note: Do not direct air flow towards people, vehicles or other 1. Check the unit for loose hardware. objects in vicinity. Always clear the area of large obstacles 2. Check the engine oil level. Add oil if necessary. and be aware of surroundings. Flying debris may harm or cause injury to people. -
Page 9: Maintenance Procedures
Do not reuse the old impeller hardware. Note: Torque the impeller bolt to the required specification: • F6 models: 24-28 ft-lbs. 5. Reinstall the front housing cover. Reconnect the spark plug wire. -
Page 10: Troubleshooting
Troubleshooting Problem Cause Solution Abnormal vibration. Loose or out of balance Check impeller impeller. Debris in and replace if impeller. Loose engine. required. Clear debris with compressed air. Check engine. Engine will not start. Engine has not been Choke the engine in choked. No fuel. Fuel is cold conditions. -
Page 11: Specifications
Specifications Dimensions and Weights Dimensions Length 43.5" (1.1m) Width: 22” (0.56m) Height: 45" (1.14m) Maximum Operating Slope: 20° Weights Model Weights F602X 83 lb (38kg) F602V 89 lb (40.3 kg) F602X - Engine Manufacturer Briggs and Stratton Model 130G320231F1 Fuel Capacity 3.2 qt (3.03 L) Oil Capacity 0.19 qt (0.18 L)
