Part No 440021
FORCE BLOWER Owner's Manual
Patent Pending
BILLY GOAT FORCE BLOWER
Owner's Manual
HOLD DOWN KIT
To secure blower for
transportation on
trailer floors.
P/N 440120
PARKING BRAKE
Effective and Easy to
use to prevent blower
from rolling.
P/N 440140
1
Form No F072706C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Force Blower and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat Force Blower

Summary of Contents for Billy Goat Force Blower

  • Page 1 FORCE BLOWER Owner’s Manual Patent Pending BILLY GOAT FORCE BLOWER Owner's Manual Accessories PARKING BRAKE HOLD DOWN KIT Effective and Easy to To secure blower for transportation on use to prevent blower from rolling. trailer floors. P/N 440140 P/N 440120...

  • Page 2: Table Of Contents

    This manual provides complete operating and maintenance instructions that will help to maintain your FORCE Blower in top running order. Read this manual carefully before assembling, operating, or servicing your equipment.

  • Page 3: Specifications

    FORCE BLOWER Owner’s Manual SERIAL PLATE DATA Record the model number, serial number, date of purchase, and where purchased. Purchase Date: Purchased From: Specifications F900S F900H F1300H Engine: HP 9.0 HP (6.6kW) 9.0 HP (6.6kW) 13.0 HP (9.6kW) Engine: Model...

  • Page 4: General Safety

    This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. ® This symbol indicates important information that will prevent damage to your BILLY GOAT FORCE Blower. This symbol indicates the engine oil level should be checked before operating this equipment.
  • Page 5 FORCE BLOWER Owner’s Manual DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling.
  • Page 6 FORCE BLOWER Owner’s Manual SOUND SOUND LEVEL 110 Db(a) at Operator Position Sound tests were conducted in accordance with 2000/14/EC, as well as ISO 11094, and were performed on 5-17- 2006 under the conditions listed below. Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for the sound power level for your model.

  • Page 7: Instruction Labels

    FORCE BLOWER Owner’s Manual INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT FORCE Blower. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels.
  • Page 8 ® Your BILLY GOAT FORCE Blower was shipped in one carton, completely assembled except for the Upper Handle Assembly and Front Diverter. Mounting hardware for the Upper Handle Assembly can be found in the parts bag. READ all safety instructions before assembling unit.

  • Page 9: Assembly

    FORCE BLOWER Owner’s Manual ASSEMBLY 1.Follow the steps in figures A and B, then securely tighten all hardware shown. 2.Connect spark plug wire. Figure A Figure B The hardware for attaching the upper handle to the lower The throttle control will be attached to the throttle arm on is in the parts bag.

  • Page 10: Operation

    BLOWING OPERATION Your Billy Goat Force blower is equipped with an air director cone to allow the operator to direct the air stream up or down as required to assist in moving debris. This feature is extremely useful when debris has piled up to the point that it cannot be blown any farther.

  • Page 11: Maintenance

    FORCE BLOWER Owner’s Manual Adjustment knob FRONT DIVERTER POSITIONING The removable front diverter adapter can be slipped on to direct the air stream forward. First turn off engine, and then simply slide diverter onto cone following guide points and twist till locked in position. This option is extremely useful for cleaning out long cracks in pavement or for cleaning under bushes, building overhangs or along curbs.

  • Page 12: Troubleshooting

    FORCE BLOWER Owner’s Manual Maintenance Operation Every Daily or Every Every 25 Every 50 Every 5 Hours Hours Hours 100-150 Hours Inspect for worn or damaged parts. Check for excessive vibration Inspect Impeller for cracks or damage Inspect for loose parts.

  • Page 13: Illustrated Parts List

    Warranty Claim. • The distributor service manager will sign off on the claim and submit it to BILLY GOAT for consideration. • The Technical Service Department at BILLY GOAT will study the claim and may request parts to be returned for examination.

  • Page 14: Parts List

    FORCE BLOWER Owner’s Manual PARTS LIST Part No 440021 Form No F072706C...

  • Page 15: Maintenance Record

    FORCE BLOWER Owner’s Manual F1300H F900H F900S ITEM NO. DESCRIPTION PART NUMBER QTY. PART NUMBER QTY. PART NUMBER QTY. ENGINE 13 HP HONDA GX390 440018 ENGINE 9 HP HONDA GX270 430287 ENGINE 9 HP HORZ SUBARU OHC 430413 BASE ENGINE W A...
  • Page 16 FORCE BLOWER Owner’s Manual Date Service Performed Part No 440021 Form No F072706C...
