FORCE BLOWER Owner's Manual
Patent #6,253,416 and other patents pending
F901S, F901H, and F1301H
BILLY GOAT FORCE BLOWER
Owner's Manual
HOLD DOWN KIT
To secure blower for
transportation on
trailer floors.
P/N 440120
PARKING BRAKE
Effective and Easy to
use to prevent blower
from rolling.
P/N 440140
1
Form No F071307B

Advertisement

Table of Contents
loading

Related Manuals for Billy Goat F1301H

Summary of Contents for Billy Goat F1301H

  • Page 1 HOLD DOWN KIT To secure blower for transportation on trailer floors. P/N 440120 Part No 440021 FORCE BLOWER Owner’s Manual F901S, F901H, and F1301H Owner's Manual PARKING BRAKE Effective and Easy to use to prevent blower from rolling. P/N 440140...

  • Page 2: Table Of Contents

    ABOUT THIS MANUAL THANK YOU for purchasing a BILLY GOAT manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your FORCE Blower in top running order. Read this manual carefully before assembling, operating, or servicing your equipment.

  • Page 3: Serial Plate Data And Specifications

    45" (1.14m) 107dB(a) @3340 rpm 109dB(a) @ 3660 rpm 87dB(a) @ 3340 rpm 89dB(a) @ 3660 rpm .96 g (9.44 m/s 1.05 g (10.30 m/s F1301H 13.0 HP (9.6kW) GX390K1QAA2 HONDA OHV 6.5 qt. (6.1L) 1.16 qt. (1.1L) 160 # (72.6Kg) 58"(1.43m)

  • Page 4: General Safety

    This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. This symbol indicates important information that will prevent damage to your BILLY GOAT FORCE Blower. This symbol indicates the engine oil level should be checked before operating this equipment.
  • Page 5 FORCE BLOWER Owner’s Manual DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling. DO NOT store gasoline near an open flame.

  • Page 6: Sound And Vibration

    SOUND Sound tests were conducted in accordance with 2000/14/EC, as well as ISO 11094, and were performed on 5-17- 2006 under the conditions listed below. Sound power level listed is the highest value for any model covered in this manual. Please refer to serial plate on the unit for the sound power level for your model.

  • Page 7: Instruction Labels

    INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the Figure and Item numbers shown.

  • Page 8: Packing Checklist

    These items should be included in your carton. If any of these parts are missing, contact your dealer. ® Your BILLY GOAT FORCE Blower was shipped in one carton, completely assembled except for the Upper Handle Assembly and Front Diverter. Mounting hardware for the Upper Handle Assembly can be found in the parts bag.

  • Page 9: Assembly

    ASSEMBLY 1.Follow the steps in figures A and B, then securely tighten all hardware shown. 2.Connect spark plug wire. Figure A The hardware for attaching the upper handle to the lower is in the parts bag. Install upper handle (item 30), to preassembled lower handle (item 28) by sliding the upper over and down the outside of the lower handle.

  • Page 10: Operation

    Never lift the machine while the engine is running. BLOWING OPERATION Your Billy Goat Force blower is equipped with an air director cone and the patented Aim-N-Shoot control lever to allow the operator to direct the air stream up or down as required to assist in moving debris. This feature is extremely useful when debris has piled up to the point that it cannot be blown any farther.

  • Page 11: Operation

    ADJUSTING AIR DIRECTOR To adjust air direction, squeeze Aim-N-Shoot extended period, choose a suitable position and use the finger controlled push button lock to lock the cone in position. For operations that do not require the use of the Aim-N-Shoot be used to permanently lock the cone into position.

  • Page 12: Maintenance

    (step 6). 5. If the impeller does not loosen, obtain a 3/4-16x3” (Billy Goat part #440192) or longer bolt. Thread bolt by hand into nut until bolt rests against the shaft. Tighten the bolt slowly, which will pull the impeller away from the shaft, remove impeller from shaft.

  • Page 13: Troubleshooting And Warranty Procedure

    • The machine must be taken to the dealer from whom it was purchased or to an authorized Servicing BILLY GOAT Dealer. •...

  • Page 14: Illustrated Parts List

    FORCE BLOWER Owner’s Manual ILLUSTRATED PARTS LIST Part No 440021 Form No F071307B...

  • Page 15: Parts List

    SCREW TCS #12-24 X 5/8 TYPE ADAPTOR MOUNT WA GRIP 1-1/4" ID x 9.5" LONG TY-WRAP VIBRATION LABEL Part No 440021 FORCE BLOWER Owner’s Manual F1301H F901H PART NUMBER QTY. PART NUMBER QTY. PART NUMBER QTY. 440018 430287 440011 440011...

  • Page 16: Maintenance Record

    FORCE BLOWER Owner’s Manual MAINTENANCE RECORD Date Service Performed Part No 440021 Form No F071307B...
