Magnum 4K220 Switches Installation and User Guide
Operating Environment
Ambient Temperature: 32° to 120° F (0° to 50°C)
Storage Temperature: -40°to 160°F (-40°to 70°C)
Ambient Relative Humidity: 5% to 95% (non-condensing)
Altitude: -200 to 13000ft (-60 to 4000m)
Conformal coating option: Request quote
Packaging
Enclosure: Rugged High strength metal. Suitable for stand-alone or
Dimensions: 1.75 in H x 17.0 in W x 9.0 in D
Weight:
Cooling method: Fan cooled, @ 7 cfm
Power Supply (Internal)
AC Power Connector: IEC-type, male recessed at rear of chassis,
with adjacent manual ON-OFF switch (on AC models only)
Input Voltage:
Input Frequency: 47 to 63 Hz (auto-ranging)
Power Consumption: 28 watts typical
Power Supply Rating: 3Amps at 5VDC
DC Power Supply (Options)
-48VDC Power Input Voltage : 36 to 72 VDC (auto ranging)
24VDC Power Input Voltage : 20 to 40VDC
125VDC Power Input Voltage : 120 to 160VDC
Std. Terminal Block : " -, GND, + "
Power Consumption: same as for AC models, see above
For Dual Source and Redundant DC for –48VDC, 24VDC Power &
125VDC supply options (Optional), see Appendices
Agency Approvals
UL listed (UL1950), cUL, CE
Emissions meet FCC Part 15 Class A
Warranty
Three years, return to factory
www GarrettCom com . .
rack-mounting
4.45cm H x 43.2cm W x 22.9cm D
7.1 lb. (3.2 Kg) rack-mount models
110 to 240 VAC (auto-ranging)
35 watts max
2
.
Made in USA
(10/04)
